Practical Tips, Minor Repairs
303
Replacing fusesIn order to prevent damage to the electrical
system due to short circuits and overloads, the in-
dividual circuits are protected by fuses.
One fuse box is in the engine compartment. Two
additional fuse boxes are located in the outer ends
of the dashboard.
1. Switch off the consumer with the defective
fuse. Before replacing a fuse, switch off all
electrical consumers and remove the ignition
key.
2. Open the fuse-box lid.
3. Remove the corresponding fuse from its slot to
check it using the plastic gripper.
A blown fuse can be identified by the melted
metal strip.
4. Replace only with fuses of the same rating.
Note
If a fuse blows repeatedly, please consult an au-
thorized Porsche dealer immediately, so that the
short circuit can be located and corrected.
Never try to “repair“ fuses: you may cause serious
damage to other parts of the electrical system.
Cover of engine-compartment fuse boxOpening fuse-box lid in engine compartment
1. Rotate the turn-locks 90° anti-clockwise with a
screwdriver and remove the cover.
Fuse box in engine compartment2. Rotate the turn-locks of the fuse-box lid
90° anti-clockwise with a screwdriver and re-
move the lid.
f f f

304
Practical Tips, Minor Repairs Opening fuse-box lid in the dashboard
1. Carefully lever off the plastic cover with a
screwdriver (arrow) and remove.
The fuse plan is located on the inside of the
cover.
A- Fuse puller2. Remove the fuses carefully with the fuse puller.

Practical Tips, Minor Repairs
305
Fuse assignment – fuse box in left side of dashboard
No. Designation Rating in A1
Sockets
20
2 Parking heater radio receiver5
3
Sockets
20
4 Parking heater15
5
Sockets
20
6 Porsche Entry & Drive15
7
Diagnosis, rain/light sensor, antenna control
5
8 Windshield wipers30
9
Washer fluid pump
15
10 Power window, rear left25
11
Central locking system
15
12 Interior light20
1314 Power window, front left2515
Tail light, right
15
16 Horn20
17
Turn signal, side light, left
10
18 Headlight washer system20
19
Fog lights
15
20
21
Cornering light
15

308
Practical Tips, Minor Repairs
Fuse assignment – fuse box in left side of dashboard
No. Designation Rating in A1
Socket for towing attachment
15
2 ParkAssist5
3
Towing attachment control unit
15
4 Telephone/telematics control unit5
5
Towing attachment control unit
15
6 Porsche Stability Management (PSM)30
7
Center differential lock
5
8 Additional high beam20
9
CD changer, DVD navigation
5
10 TV tuner, satellite receiver5
11
Radio
10
12 Radio booster30
13
Seat heating
5
14 Tail light, left15
15
Power window, rear right
25
16 Rear guard lights, luggage compartment lights, entry light, rear lid 10
17
Low beam, right; high beam, right
15
18 Heated rear window30
19
Towing attachment motor
30/25
20 Electric seat height adjustment30
21
Alarm system, spare wheel release
10

Practical Tips, Minor Repairs
311
Fuse assignment – fuse box in engine compartmentNote
Use the plastic grippers from the fuse boxes in the dashboard to replace the fuses.No. Designation Rating in A
1
Fan
60
2Fan30
3
Secondary air pump
40
4 Secondary air pump40
567
Fuel injectors, ignition coils
20
8 Fuel injectors, ignition coils20
9
Engine control units
30
10 Engine components: radiator fans, afterrun pump, carbon canister valve, AC pressure sensor, tank leakage diagnosis 10
11
Engine components
15
12 E-box relay, secondary air pumps, afterrun pump relay5
13
Fuel pump
15
14 Fuel pump15
15
Engine control unit, fuel pump
10
16 Vacuum pump30
17
Oxygen sensors
15
18 Oxygen sensors7,5
