2005 PORSCHE CAYENNE TURBO lights

Practical Tips, Minor Repairs
327
Bulb Chart
Type, rating Type, rating
Exterior lights Interior lights
Xenon low beam and high beam D1S Interior light, front W5W
Side marker light, rear P21/5W Reading light W5W
Side marker light, front W5W Engine compartment light W5W
Turn signal light, rear P21W Footwell light W3W
Turn signal light, front PY21W Glove compartment light W3W
Brake light P21W Center console W3W
License plate light C5W Luggage compartment light K12V10W
Fog light H11 Curb lights (doors) W3W
Rear fog light P21/4W Warning lights (doors) W3W
Back up light P21W Kerb light (rear lid) W5W
Side indicator light W5W Curb lights (rear lid) W5W
Additional high beam H7
Cornering light H3

328
Practical Tips, Minor Repairs
Replacing Bulbs
Warning!
Danger of short circuit.
fAlways switch off the relevant consumer when
changing bulbs.
Danger of injury. The headlights are under
high voltage when installed.
fExercise extreme caution when working in the
area of the headlights.
Risk of damage. Bulbs of a higher wattage
can damage the light housing.
fOnly use the bulbs specified in the bulb chart.
fBulbs must be clean and free from oil, grease
or fingerprints.
fNever touch bulbs with your bare hands.
Use a cloth or soft paper when replacing bulbs.
fAlways carry spare bulbs with you.
In certain countries, the carrying of spare
bulbs is mandatory.
Caution!
Risk of damage to headlights due to exces-
sive temperatures and abrasion.
fAttach no coverings (e.g. films, “stone
guards“) in the area of the headlights.
fUse soapy water only to clean light lenses and
plastic headlight lenses. In no case may chem-
ical cleaners or other volatile cleaning fluids be
used.
fTo prevent scratches, do not rub with a dry or merely moist cloth, tissue or insect sponges.

Practical Tips, Minor Repairs
329
Headlights
Caution!
Risk of damage to headlights due to abrasion
and excessive temperatures.
fDo not affix any coverings (e.g. “stone guards” or films) in the area of the headlights.
Removing Bi-Xenon headlight1. Switch off ignition and withdraw the ignition
key.
2. Push down cover A in the direction of the arrow
and remove.
B- Headlight release
C-Wing
D- Socket wrench3. Take socket wrench D out of the tool kit.
4. Push socket wrench D onto the release B and
turn in the direction of the arrow.
The headlight holder has now been unlocked.
5. Pull headlight forward out of the fender.

330
Practical Tips, Minor Repairs
B- Headlight release
C-Wing
D- Socket wrenchB- Headlight release
C-Wing
D-Socket wrench
Installing Bi-Xenon headlights1. Insert headlight into the guide rails and push
fully into the fender.
2. Push headlight to the rear and simultaneously
turn socket wrench D in the direction of the ar-
row.
The headlight locking device must perceptibly
and audibly engage.
B- Headlight release
C-Wing
D-Socket wrench3. Check whether the headlights are seated se-
curely.
4. Fit cover A and fold it down.

Practical Tips, Minor Repairs
331
Location of bulbs in Bi-Xenon headlightsBi-Xenon headlight
F Bulb for turn signal
G Bulb for additional high beam
H Bulb for cornering light
I Bulb for side light
J Xenon gas discharge lamp for low beam and
high beam
Opening the lid of the headlight housing1. Open both clips A.
2. Remove housing lid B.
Closing lid of headlight housing1. Put housing lid B on and press into place.
2. Close clips A.

Practical Tips, Minor Repairs
337
License Plate LightsChanging bulb for license plate light1. Unscrew both screws A and remove the light.
2. Push the bulb holder apart and pull the bulb
out.
3. Replace defective bulb.
4. Reassemble in reverse order.

338
Practical Tips, Minor Repairs
Headlight AdjustmentfCheck tire pressure and adjust if necessary.
fPlease observe the chapter “TIRE PRESSU-
RES, COLD” on Page 350.
fPlease observe the chapter “REPLACING BUL-
BS” on Page 328.Adjustment
The adjustment is made with the vehicle ready to
drive and the fuel tank completely filled.
The driver's seat must be loaded by a person or a
165lbs. (75kg) weight and the tire pressures must
meet the prescribed values. After being loaded,
the car must be rolled a few meters so that the
suspension can settle.
For checking the headlight adjustment, the verti-
cal position of the cutoff of the lowbeam (see fig.)
has to be projected on a vertical screen (wall) in
distance of 24.6 ft. (7.5 m) from the front lens of
the headlamp.The correct position of the cutoff is
3.0 in. (7.5 cm) at 24.6 ft. or 7.5 m (0.4°) below
a horizontal line, x cm from ground to the center
of the headlamp lens.
Lateral adjustment of the headlights should be
carried out at a specialist workshop with an optical
adjustment unit.
Distance
Visual aim shall be performed at not less than
7.5 m (this value is a rounded down conversion
from the 25-foot distance typical of field aim using
a screen). The 24.6 ft. (7.5 m) distance is mea-
sured from the headlamp lens to the viewing
screen.
Floor
The surface upon which the vehicle rests is flat
and approximately level.
Screen
The screen upon which headlamp beams are pro-
jected is perpendicular to the floor and the vehi-
cle's longitudinal axis, flat, uniformly light in color,
unobstructed, and wide and high enough to ac-
commodate the vehicle beam patterns to be
aimed.
The screen should be wide enough to provide at
least 3.3 ft. (1 m) of space outboard of the vehi-
cle's headlamp spacing.

Practical Tips, Minor Repairs
339
Height adjustment for low beam/
high beam and additional high beam1. Push down cover in the engine compartment
and remove.
2. Switch ignition on.
3. Switch on low beam and/or high beam.
4. Adjust low beam in direction of the arrow.
Changing Headlights from Left to
Right-Hand TrafficIf you travel to a corresponding country where traf-
fic uses the other side of the road, the headlights
must be partially masked with films when you
cross the border.
fYou can obtain the films and a set of instruc-
tions from an authorized Porsche dealer.
