GM Goodwrench®oil meets all the requirements for
your vehicle.
If you are in an area of extreme cold, where the
temperature falls below−20°F (−29°C), it is
recommended that you use either an SAE 5W-30
synthetic oil or an SAE 0W-30 oil. Both will provide
easier cold starting and better protection for your engine
at extremely low temperatures.
Engine Oil Additives
Do not add anything to your oil. The recommended oils
with the starburst symbol that meet GM Standard
GM6094M are all you will need for good performance
and engine protection.
Engine Oil Life System
When to Change Engine Oil
Your vehicle has a computer system that lets you know
when to change the engine oil and filter. This is based on
engine revolutions and engine temperature, and not on
mileage. Based on driving conditions, the mileage at
which an oil change will be indicated can vary
considerably. For the oil life system to work properly, you
must reset the system every time the oil is changed.When the system has calculated that oil life has been
diminished, it will indicate that an oil change is necessary.
A CHANGE OIL light will come on. SeeChange Engine
Oil Light on page 3-34. Change your oil as soon as
possible within the next 600 miles (1 000 km). It is
possible that, if you are driving under the best conditions,
the oil life system may not indicate that an oil change is
necessary for over a year. However, your engine oil and
filter must be changed at least once a year and at this
time the system must be reset. Your dealer has
GM-trained service people who will perform this work
using genuine GM parts and reset the system. It is also
important to check your oil regularly and keep it at the
proper level.
If the system is ever reset accidentally, you must
change your oil at 3,000 miles (5 000 km) since your
last oil change. Remember to reset the oil life system
whenever the oil is changed.
5-18

If you have to add coolant more than four times a year,
have your dealer check your cooling system.
Notice:If you use the proper coolant, you do not
have to add extra inhibitors or additives which claim
to improve the system. These can be harmful.
Checking Coolant
The coolant surge tank is located in the engine
compartment on the passenger’s side of the vehicle. See
Engine Compartment Overview on page 5-12for more
information on location.
{CAUTION:
Turning the surge tank pressure cap when the
engine and radiator are hot can allow steam
and scalding liquids to blow out and burn you
badly. Never turn the surge tank pressure
cap — even a little — when the engine and
radiator are hot.
The vehicle must be on a level surface. When your
engine is cold, the coolant level should be at the hash
mark, or a little higher.
If the LOW COOLANT light
comes on and stays on, it
means you are low on
engine coolant.
SeeLow Coolant Warning Light on page 3-30. 2.2L L4 ECOTEC™ engine shown, 3400 V6 engine
similar
5-23

Owner Checks and Services on page 6-8tells you what
should be checked, when to check it and what you can
easily do to help keep your vehicle in good condition.
The proper replacement parts, fluids and lubricants to
use are listed inRecommended Fluids and Lubricants
on page 6-12andNormal Maintenance Replacement
Parts on page 6-13. When your vehicle is serviced,
make sure these are used. All parts should be replaced
and all necessary repairs done before you or anyone
else drives the vehicle. We recommend the use of
genuine GM parts.
Scheduled Maintenance
When the CHANGE OIL light comes on, it means that
service is required for your vehicle. Have your vehicle
serviced as soon as possible within the next 600 miles
(1 000 km). It is possible that, if you are driving under the
best conditions, the engine oil life system may not
indicate that vehicle service is necessary for over a year.
However, your engine oil and filter must be changed at
least once a year and at this time the system must be
reset. Your GM Goodwrench dealer has GM-trained
service technicians who will perform this work using
genuine GM parts and reset the system.If the engine oil life system is ever reset accidentally,
you must service your vehicle within 3,000 miles
(5 000 km) since your last service. Remember to reset
the oil life system whenever the oil is changed. See
Engine Oil Life System on page 5-18for information on
the Engine Oil Life System and resetting the system.
When the CHANGE OIL light appears, certain services,
checks and inspections are required. Required
services are described in the following for
“MaintenanceI” and “MaintenanceII.” Generally, it is
recommended that your first service be MaintenanceI,
your second service be MaintenanceIIand that you
alternate MaintenanceIand MaintenanceIIthereafter.
However, in some cases, MaintenanceIImay be
required more often.
MaintenanceI— Use MaintenanceIif the CHANGE
OIL light comes on within 10 months since the
vehicle was purchased or MaintenanceIIwas
performed.
MaintenanceII— Use MaintenanceIIif the previous
service performed was MaintenanceI. Always use
MaintenanceIIwhenever the light comes on 10 months
or more since the last service or if the light has not
come on at all for one year.
6-4

Automatic Headlamp System............................3-15
Automatic Transaxle
Fluid..........................................................5-21
Operation...................................................2-20
B
Battery..........................................................5-36
Run-Down Protection...................................3-18
Before Leaving on a Long Trip.........................4-22
Brake
Anti-Lock Brake System (ABS)........................ 4-6
Emergencies................................................ 4-8
Parking......................................................2-23
System Warning Light..................................3-27
Brakes..........................................................5-33
Braking........................................................... 4-5
Braking in Emergencies..................................... 4-8
Break-In, New Vehicle.....................................2-15
Bulb Replacement...........................................5-42
Center High-Mounted Stoplamp (CHMSL)........5-44
Front Turn Signal and Parking Lamps.............5-43
Halogen Bulbs............................................5-42
Headlamps.................................................5-42
Replacement Bulbs......................................5-45
Taillamps, Turn Signal, and Stoplamps............5-44
Buying New Tires...........................................5-55
C
California Fuel.................................................. 5-5
Canadian Owners................................................ ii
Capacities and Specifications............................5-85
Carbon Monoxide...................2-11, 2-26, 4-25, 4-38
Care of
Safety Belts................................................5-74
Your CD Player...........................................3-69
Your CDs ...................................................3-69
Center Console Storage Area...........................2-30
Center High-Mounted Stoplamp (CHMSL)...........5-44
Center Rear Passenger Position, Safety Belts.......1-26
Chains, Tire...................................................5-59
Charging System Light....................................3-26
Check
Engine Light...............................................3-30
Checking Things Under the Hood......................5-10
Chemical Paint Spotting...................................5-77
Child Restraints
Child Restraint Systems...............................1-36
Infants and Young Children...........................1-32
Lower Anchorages and Top Tethers for
Children (LATCH System)..........................1-41
Older Children.............................................1-30
Securing a Child Restraint Designed for the
LATCH System........................................1-43
2

D
Daytime Running Lamps..................................3-15
Defensive Driving............................................. 4-2
Delayed Headlamps........................................3-15
Delayed Locking............................................... 2-8
Doing Your Own Service Work........................... 5-4
Dome Lamp...................................................3-17
Door
Delayed Locking........................................... 2-8
Locks.......................................................... 2-7
Power Door Locks......................................... 2-8
Programmable Automatic Door Locks............... 2-8
Rear Door Security Locks.............................2-10
Driver
Position, Safety Belt.....................................1-14
Seat Height Adjuster...................................... 1-3
Six-Way Power Seat...................................... 1-3
Driving
At Night.....................................................4-16
City...........................................................4-20
Defensive..................................................... 4-2
Drunken....................................................... 4-2
Freeway.....................................................4-21
Hill and Mountain Roads..............................4-23
In Rain and on Wet Roads...........................4-17
Rocking Your Vehicle to Get it Out.................4-30
Winter........................................................4-25
E
Easy Entry Seat............................................... 1-6
Electrical System
Add-On Equipment......................................5-80
Engine Compartment Fuse Block...................5-83
Fuses and Circuit Breakers...........................5-80
Instrument Panel Fuse Block.........................5-81
Power Windows and Other Power Options......5-80
Windshield Wiper Fuses...............................5-80
Engine
Air Cleaner/Filter.........................................5-20
Battery.......................................................5-36
Change Engine Oil Light...............................3-34
Check and Service Engine Soon Light............3-30
Coolant......................................................5-22
Coolant Heater............................................2-19
Coolant Temperature Gage...........................3-29
Engine Compartment Overview......................5-12
Exhaust.....................................................2-26
Oil .............................................................5-15
Overheating................................................5-24
Starting......................................................2-17
Enhanced Traction System (ETS)........................ 4-8
Active Light................................................3-29
Warning Light.............................................3-28
Entry/Exit Lighting...........................................3-17
Event Data Recorders (EDR)............................. 7-9
Extender, Safety Belt.......................................1-29
4

Height Adjuster, Driver Seat............................... 1-3
Highbeam On Light.........................................3-35
Highway Hypnosis...........................................4-23
Hill and Mountain Roads..................................4-23
Hood
Checking Things Under................................5-10
Release.....................................................5-10
Horn............................................................... 3-7
How to Use This Manual...................................... ii
How to Wear Safety Belts Properly...................1-14
I
Ignition Positions.............................................2-16
Infants and Young Children, Restraints...............1-32
Inflation -- Tire Pressure..................................5-52
Instrument Panel
Brightness..................................................3-17
Cluster.......................................................3-22
Overview..................................................... 3-4
J
Jump Starting.................................................5-37
K
Keyless Entry System....................................... 2-3
Keys............................................................... 2-2
L
Labelling, Tire Sidewall....................................5-47
Lamps
Battery Run-Down Protection.........................3-18
Dome........................................................3-17
Fog ...........................................................3-16
Trunk.........................................................3-18
LATCH System
Child Restraints...........................................1-41
Securing a Child Restraint Designed for the
LATCH System........................................1-43
Latches, Seatback............................................ 1-6
Lift Seat, Power............................................... 1-7
Light
Airbag Readiness........................................3-25
Anti-Lock Brake System Warning...................3-28
Brake System Warning.................................3-27
Change Engine Oil......................................3-34
Charging System.........................................3-26
6

N
New Vehicle Break-In......................................2-15
Normal Maintenance Replacement Parts............6-13
O
Odometer......................................................3-24
Odometer, Trip...............................................3-24
Off-Road Recovery..........................................4-12
Oil
Change Engine Oil Light...............................3-34
Engine.......................................................5-15
Pressure Light.............................................3-34
Older Children, Restraints................................1-30
Online Owner Center........................................ 7-3
Other Warning Devices...................................... 3-7
Outlet Adjustment............................................3-21
Outside
Convex Mirror.............................................2-29
Power Mirrors.............................................2-28
Remote Control Mirror..................................2-28
Owner Checks and Services.............................. 6-8
Owners, Canadian............................................... ii
P
Park (P)
Shifting Into................................................2-24
Shifting Out of............................................2-25
Park (P) Headlamps Off in Park (P)..................3-14
Parking
Brake........................................................2-23
Over Things That Burn.................................2-26
Passing.........................................................4-13
Passlock
®......................................................2-15
Power............................................................. 1-3
Door Locks.................................................. 2-8
Electrical System.........................................5-80
Lift Seat....................................................... 1-7
Retained Accessory (RAP)............................2-17
Steering Fluid.............................................5-31
Windows....................................................2-14
Programmable Automatic Door Locks.................. 2-8
Q
Questions and Answers About Safety Belts.........1-13
8

R
Radios..........................................................3-37
Care of Your CD Player...............................3-69
Care of Your CDs........................................3-69
Radio with CD............................3-38, 3-42, 3-53
Setting the Time for Radios with Radio Data
Systems (RDS)........................................3-37
Setting the Time for Radios without Radio
Data Systems (RDS)................................3-37
Theft-Deterrent............................................3-67
Understanding Reception..............................3-69
Rear Door Security Locks................................2-10
Rear Safety Belt Comfort Guides......................1-27
Rear Seat Operation......................................... 1-8
Rear Seat Passengers, Safety Belts..................1-23
Rearview Mirrors.............................................2-28
Reclining Seatbacks.......................................... 1-4
Recommended Fluids and Lubricants.................6-12
Recreational Vehicle Towing.............................4-35
Remote Keyless Entry System............................ 2-3
Remote Keyless Entry System, Operation............ 2-4
Removing the Flat Tire and Installing the
Spare Tire..................................................5-64
Removing the Spare Tire and Tools...................5-62
Replacement Bulbs.........................................5-45
Reporting Safety Defects
Canadian Government..................................7-10
General Motors...........................................7-11
United States Government............................7-10Restraint System Check
Checking Your Restraint Systems...................1-57
Replacing Restraint System Parts After
a Crash..................................................1-58
Restraint Systems
Checking....................................................1-57
Replacing Parts...........................................1-58
Retained Accessory Power (RAP)......................2-17
Right Front Passenger Position, Safety Belts......1-22
Roadside
Assistance Program....................................... 7-5
Rocking Your Vehicle to Get it Out....................4-30
Running Your Engine While You Are Parked.......2-27
S
Safety Belt
Reminder Light............................................3-25
Safety Belts
Care of......................................................5-74
Center Rear Passenger Position....................1-26
Driver Position............................................1-14
How to Wear Safety Belts Properly................1-14
Questions and Answers About Safety Belts.....1-13
Rear Safety Belt Comfort Guides for Children
and Small Adults......................................1-27
Rear Seat Passengers.................................1-23
Right Front Passenger Position......................1-22
Safety Belt Extender....................................1-29
9
