2005 NISSAN 350Z Headlight

corrosive materials, check lubrication frequently.
Lights*:Clean the headlights on a regular basis.
Make sure that the headlights, stop lights, tail
lights, turn signal lights, and other lights are all
operating properly and installed securely. Also
check headlight aim.
Road wheel nuts (lug nuts)*:When checking
the tires, make sure no nuts are missing, and
check for any loose nuts. Tighten if necessary.
Tire rotation*:Tires cannot be rotated in this
vehicle.
Tire, wheel alignment and balance:If the
vehicle pulls to either side while driving on a
straight and level road, or if you detect uneven or
abnormal tire wear, there may be a need for
wheel alignment.
If the steering wheel or seat vibrates at normal
highway speeds, wheel balancing may be
needed.
For additional information regarding tires, refer to
“Important Tire Safety Information” (US) or “Tire
Safety Information” (Canada) in the Warranty
Information Booklet.
Tires*:Check the pressure with a gauge often
and always prior to long distance trips. Adjust
the pressure in all tires, including the spare, to
the pressure specified. Check carefully for dam-age, cuts or excessive wear.
Windshield:Clean the windshield on a regular
basis. Check the windshield at least every six
months for cracks or other damage. Have a
damaged windshield repaired by a qualified re-
pair facility.
Windshield wiper blades*:Check for cracks
or wear if they do not wipe properly.
Inside the vehicleThe maintenance items listed here should be
checked on a regular basis, such as when
performing periodic maintenance, cleaning the
vehicle, etc.
Automatic transmission P (Park) position
mechanism:On a fairly steep hill check that the
vehicle is held securely with the selector lever in
the P (Park) position without applying any
brakes.
Accelerator pedal:Check the pedal for
smooth operation and make sure the pedal does
not catch or require uneven effort. Keep the floor
mat away from the pedal.
Brakes:Check that the brakes do not pull the
vehicle to one side when applied.
Brake pedal and booster*:Check the pedal
for smooth operation and make sure it has the
proper distance under it when depressed fully.Check the brake booster function. Be sure to
keep floor mat away from the pedal.
Clutch pedal*:Make sure the pedal operates
smoothly and check that it has the proper free
play.
Parking brake*:Check that the lever has the
proper travel and make sure that the vehicle is
held securely on a fairly steep hill when only the
parking brake is applied.
Seats:Check seat position controls such as
seat adjusters, seatback recliner, etc. to ensure
they operate smoothly and that all latches lock
securely in every position. Check that the head
restraints move up and down smoothly and that
the locks (if equipped) hold securely in all
latched positions.
Seat belts:Check that all parts of the seat belt
system (for example, buckles, anchors, adjusters
and retractors) operate properly and smoothly,
and are installed securely. Check the belt web-
bing for cuts, fraying, wear or damage.
Steering wheel:Check for changes in the
steering conditions, such as excessive free play,
hard steering or strange noises.
Warning lights and chimes:Make sure that all
warning lights and chimes are operating prop-
erly.
Maintenance and do-it-yourself
8-3


04.8.23/Z33-D/V5.0


ENGINE COMPARTMENT
CAUTION
Never use a fuse of a higher or lower
amperage rating than that specified on
the fuse box cover. This could damage
the electrical system or cause a fire.
If any electrical equipment does not operate,
check for an open fuse.
1. Be sure the ignition switch and headlight
switch are OFF.2. Open the engine hood and remove the cover
on the battery and the fuse/fusible link holder.
3. Remove the fuse/fusible link holder cover by
pushing the tabs
1
and lifting the cover
2.
4. Remove the fuse with the fuse puller.
5. If the fuse is open
A, replace it with a new
fuse
B.
6. If a new fuse also opens, have the electrical
system checked and repaired by a NISSAN
dealer.
Fusible linksIf any electrical equipment does not operate and
fuses are in good condition, check the fusible
links. If any of these fusible links are melted,
replace only with genuine NISSAN parts.
SDI1479B
SDI1753
Type A
SDI1754
Type B
Maintenance and do-it-yourself
8-23


04.8.23/Z33-D/V5.0


PASSENGER COMPARTMENT
CAUTION
Never use a fuse of a higher or lower
amperage rating than that specified on
the fuse box cover. This could damage
the electrical system or cause a fire.
If any electrical equipment does not operate,
check for an open fuse.
1. Be sure the ignition switch and the headlight
switch are OFF.2. Open the fuse box lid.
3. Pinch the fuse perpendicularly with the fuse
puller and pull it out.
4. If the fuse is open, replace it with a new fuse.
5. If a new fuse also opens, have the electrical
system checked and repaired by a NISSAN
dealer.
Replace the battery as follows:
1. Open the lid using a suitable tool.
2. Replace the battery with a new one.
Recommended battery: CR2025 or equiva-
lent
SDI1393
SDI1608
KEYFOB BATTERY
REPLACEMENT
8-24
Maintenance and do-it-yourself


04.8.23/Z33-D/V5.0


1
Front view
1. Headlight (low-beam, high-beam)
2. Spot light
3. Front park light
4. Front turn signal light
5. Front side marker light2
Rear view (Coupe),
3
Rear view (Roadster)
6. Luggage compartment light (Coupe) or Trunk
light (Roadster)
7. High-mounted stop light
8. Rear combination light
(Side marker, Stop/Tail)
9. License plate lights
10. Rear combination light
(Back-up, Turn signal)
SDI1571
LIGHTS8-26
Maintenance and do-it-yourself


04.8.23/Z33-D/V5.0


HEADLIGHTS
ReplacingIf replacement is required, see a NISSAN dealer.
Xenon headlight bulb:
WARNINGHIGH VOLTAGE
When xenon headlights are on, they
produce a high voltage. To prevent an
electric shock, never attempt to modify
or disassemble. Always have your xe-
non headlights replaced at a NISSAN
dealer. For additional information, see
“Headlight and turn signal switch” in
the “2. Instruments and controls” sec-
tion.
Halogen headlight bulb:
The headlight is a semi-sealed beam type which
uses a replaceable headlight (halogen) bulb. A
bulb can be replaced from under the engine
compartment without removing the headlight
assembly.
CAUTION

High pressure halogen gas is sealed
inside the halogen bulb. The bulb
may break if the glass envelope is
scratched or the bulb is dropped.

When handling the bulb, do not touch
the glass envelope.

Do not touch the bulb.

Use the same number and wattage as
originally installed:
Bulb no. (Wattage)
D2R (35W) - Xenon low-beam
H7 (55W) - High-beam
or
H7 (55W) - Halogen low-beam
H1 (55W) - High-beam

Do not leave the bulb out of the
headlight reflector for a long period
of time as dust, moisture and smoke
may enter the headlight body and
affect the performance of the head-
light.
Maintenance and do-it-yourself
8-27


04.8.23/Z33-D/V5.0


The original tires have built-in tread
wear indicators. When the wear indi-
cators are visible, the tire(s) should
be replaced.

Improper service of the spare tire
may result in serious personal injury.
If it is necessary to repair the spare
tire, contact a NISSAN dealer.

For additional information regarding
tires, refer to “Important Tire Safety
Information” (US) or “Tire Safety In-
formation” (Canada) in the Warranty
Information Booklet.Replacing wheels and tiresWhen replacing a tire, use the same size, speed
rating and load carrying capacity as originally
equipped. See “Specifications” in the “9. Tech-
nical and consumer information” section for rec-
ommended types and sizes of tires and wheels.
WARNING

The use of tires other than those
recommended or the mixed use oftires of different brands, construction
(bias, bias-belted or radial), or tread
patterns can adversely affect the ride,
braking, handling, ground clearance,
body-to-tire clearance, tire chain
clearance, speedometer calibration,
headlight aim and bumper height.
Some of these effects may lead to
accidents and could result in serious
personal injury.

If the wheels are changed for any
reason, always replace with wheels
which have the same off-set dimen-
sion. Wheels of a different off-set
could cause premature tire wear,
possibly degraded vehicle handling
characteristics and/or interference
with the brake discs/drums. Such in-
terference can lead to decreased
braking efficiency and/or early brake
pad/shoe wear.

When a spare tire is mounted or a
wheel is replaced, tire pressure will
not be indicated and the low tire
pressure warning system will notfunction. Contact a NISSAN dealer as
soon as possible for tire replacement
and/or system resetting. (For models
with the low tire pressure warning
system)

Do not install a deformed wheel or
tire even if it has been repaired. Such
wheels or tires could have structural
damage and could fail without warn-
ing.

The use of retread tire is not recom-
mended.

For additional information regarding
tires, refer to “Important Tire Safety
Information” (US) or “Tire Safety In-
formation” (Canada) in the Warranty
Information Booklet.
Wheel balanceUnbalanced wheels may affect vehicle handling
and tire life. Even with regular use, wheels can
get out of balance. Therefore, they should be
balanced as required.
Wheel balance service should be performed
with the wheels off the vehicle. Spin balancing
Maintenance and do-it-yourself
8-37


04.8.23/Z33-D/V5.0


Filler lid .................................................................. 3-13
Fuel economy ...................................................... 5-17
Fuel octane rating ................................................. 9-3
Fuel recommendation ........................................... 9-3
Gauge ...................................................................... 2-6
Fuses ............................................................................ 8-22
Fusible links ................................................................ 8-23
G
Garage door opener, HomeLink
Universal
Transceiver .................................................................. 2-42
Gas cap ....................................................................... 3-13
Gauge ............................................................................. 2-3
Engine coolant temperature gauge .................. 2-6
Engine oil pressure gauge .................................. 2-7
Fuel gauge .............................................................. 2-6
Odometer ................................................................ 2-4
Speedometer .......................................................... 2-4
Tachometer ............................................................. 2-5
Trip computer ......................................................... 2-8
Volt meter ................................................................ 2-8
General maintenance .................................................. 8-2
Golf bag stowing....................................................... 2-36
H
Hatch, Rear hatch........................................................ 3-9
Hazard warning flasher switch............................... 2-27
Head restraints ............................................................. 1-9
Headlights
Bulbreplacement ............................................... 8-27
Headlight switch ................................................. 2-24Xenon headlights ................................................ 2-24
Heated seats .............................................................. 2-28
Heater
Engine coolant heater ....................................... 5-25
Heater and air conditioner (automatic)............ 4-8
HomeLink
Universal Transceiver ......................... 2-42
Hood release ................................................................ 3-9
Horn .............................................................................. 2-27
How to stop alarm, Vehicle security .................... 2-20
I
Ignition switch ............................................................... 5-6
Automatic transmission models................ 5-6, 5-9
Key positions .......................................................... 5-7
Manual transmission models .................. 5-7, 5-12
Immobilizer system .................................................... 2-20
Indicator lights............................................................ 2-16
Inside
Automatic anti-glare mirror............................... 3-17
Mirror...................................................................... 3-16
Inspection/maintenance (I/M) test ........................ 9-23
Instrument brightness control ................................ 2-26
Instrument panel........................................................... 2-2
Interior light replacement......................................... 8-28
Interior lights ............................................................... 2-40
Interior trunk lid release ........................................... 3-12
J
Jump starting................................................................. 6-7K
Keyless entry (See remote keyless entry
system) ........................................................................... 3-4
Keys................................................................................. 3-2
L
Labels
Air bag warning labels ...................................... 1-40
Air conditioner specification label .................. 9-12
Emission control information label ................. 9-11
Engine serial number ......................................... 9-11
F.M.V.S.S./C.M.V.S.S. certification label ...... 9-11
Tire and loading information label ...... 8-32, 9-12
Vehicle identification number (VIN)................ 9-10
License plate, Installing front license plate......... 9-13
Light
Air bag warning light ......................................... 1-40
Bulbreplacement ............................................... 8-26
Headlight switch ................................................. 2-24
Headlights Bulbreplacement .......................... 8-27
Interior lights ........................................................ 2-40
Replacement ........................................................ 8-26
Vanity mirror light ................................................ 2-41
Warning/indicator lights and audible
reminders .................................................. 2-12, 2-16
Xenon headlights ................................................ 2-24
Lights, Exterior and interior light replacement ... 8-28
Loading information (See vehicle loading
information) ................................................................. 9-14
Lock
Door locks ............................................................... 3-2


04.8.23/Z33-D/V5.0

10-3

Rear parcel box ......................................................... 2-36
Rear power point....................................................... 2-31
Rear window and outside mirror defroster
switch ........................................................................... 2-23
Registering your vehicle in another country ....... 9-10
Remote keyless entry system ................................... 3-4
Reporting safety defects (US only) ...................... 9-22
Rollover........................................................................... 5-5
S
Safety
Child seat belts ................................................... 1-12
Reporting safety defects (US only)................ 9-22
Towing safety....................................................... 9-17
Satellite (SAT) radio ................................................. 4-12
Seat
Belt warning light .................................... 1-10, 2-15
Lever, Tilting passenger’s seat .......................... 1-7
Seat adjustment
Front manual seat adjustment............................ 1-3
Front power seat adjustment .................... 1-4, 1-5
Seatback tilt cancel switch ....................................... 1-9
Seat belt(s)
Child safety .......................................................... 1-12
Injured persons.................................................... 1-14
Larger children .................................................... 1-13
Pre-tensioner seat belt system ....................... 1-39
Precautions on seat belt usage ...................... 1-10
Pregnant women ................................................. 1-14
Seat belt cleaning ................................................. 7-5
Seat belt extenders ............................................ 1-16
Seat belt maintenance ...................................... 1-16
Seat belts ............................................................. 1-10Three-point type with retractor ....................... 1-14
Seat(s)
Heated seats........................................................ 2-28
Seats ........................................................................ 1-2
Ventilated net seats .............................................. 1-6
Secondary rear hatch release ................................ 3-10
Secondary trunk lid release .................................... 3-13
Security system, Vehicle security system ........... 2-19
Security systems (NISSAN Vehicle Immobilizer
System), Engine start ............................................... 2-20
Servicing air conditioner................................. 4-8, 4-11
Shift lock release ....................................................... 5-12
Shifting
Automatic transmission .............................. 5-6, 5-9
Manual transmission ................................. 5-7, 5-12
Side air bag system (See supplemental side air bag
and curtain air bag system) .................................... 1-37
Soft top
Soft top care and cleaning ................................. 7-2
Soft top indicator light ........................... 2-17, 3-23
Soft top operation .............................................. 3-19
Care of the soft top and the vehicle body... 3-28
If the top does not open or close
electrically ............................................................. 3-25
Spark plugs................................................................. 8-17
Speed, Average speed ............................................ 2-10
Speed, Speed indicator ............................................. 2-9
Speedometer ................................................................ 2-4
Starting
Before starting the engine .................................. 5-8
Jump starting .......................................................... 6-7
Precautions when starting and driving ............ 5-2
Push starting .......................................................... 6-9
Starting the engine ............................................... 5-8Steering
Power steering fluid ........................................... 8-13
Power steering system ...................................... 5-19
Tilting steering wheel......................................... 3-15
Stopwatch ................................................................... 2-10
Storage ........................................................................ 2-32
Stowing golf bags ..................................................... 2-36
Sun visor, Extension ................................................. 3-16
Sunglasses holder .................................................... 2-32
Supplemental air bag warning labels................... 1-40
Supplemental air bag warning light .......... 1-40, 2-15
Supplemental restraint system............................... 1-29
Precautions on supplemental restraint
system.................................................................... 1-29
Supplemental side and curtain air bag
system .......................................................................... 1-37
Switch
Hazard warning flasher switch ........................ 2-27
Headlight switch ................................................. 2-24
Ignition switch ........................................................ 5-6
Ignition switch automatic transmission
models ............................................................ 5-6, 5-9
Ignition switch manual transmission
models .......................................................... 5-7, 5-12
Power door lock switch....................................... 3-4
Rear window and outside mirror defroster
switch..................................................................... 2-23
Traction control system (TCS) off switch .... 2-29
Turn signal switch .............................................. 2-26
Vehicle dynamic control (VDC) off switch ... 2-29
T
Tachometer.................................................................... 2-5


04.8.23/Z33-D/V5.0

10-5
