2005 NISSAN 350Z navigation system

WARNING

Positioning of the heating or air con-
ditioning controls and display con-
trols should not be done while driv-
ing, in order that full attention may
be given to driving operation.

Do not disassemble or modify this
system. If you do, it may result in
accidents, fire, or electric shock.

Do not use this system if you notice
any abnormality, such as a frozen
screen or lack of sound. Continued
use of the system may result in acci-
dent, fire or electric shock.

In case you notice any foreign object
in the system hardware, spill liquid
on it, or notice smoke or smell com-
ing from it, stop using the system
immediately and contact a NISSAN
dealer. Ignoring such conditions may
lead to accidents, fire, or electric
shock.When you use this system, make sure the engine
is running.
If you use the system with the engine not
running (ignition ONor ACC) for a long
time, it will use up all the battery power,
and the engine will not start.
Reference symbols:
“PUSH ENTER”button
This is a button on the control panel.
“Display”key
This is a select key on the screen. By selecting
this key you can proceed to the next function.
NAMES OF THE COMPONENTS1. “SETTING” button
2. “INFO” button
3. “
” brightness control button
4. “PREVIOUS” button
5. JOYSTICK and PUSH ENTER button
For Navigation system control buttons (other
than above); refer to the separate Navigation
Owner’s Manual.
SAA0932
SAFETY NOTE
CONTROL PANEL BUTTONS —
WITH NAVIGATION SYSTEM4-2
Heater, air conditioner and audio systems


04.8.23/Z33-D/V5.0


HOW TO USE JOYSTICK AND
“ENTER” BUTTONChoose an item on the display using the joystick
and push the PUSH ENTER button for opera-
tion.HOW TO USE “PREVIOUS”
BUTTONThis button has two functions.
To return to the previous screen:
When this button is pressed during setup, setup
will be canceled, and the screen will return to the
previous screen.
To finish the set-up:
When this button is pressed after setup is
completed, the settings will be renewed as
directed, and the screen will return to the map.
INFO:
When the “PREVIOUS” button must be
pressed, (for example, after the setup is finished)
instructions are given in the operation procedure
of each section in this manual. If the “PREVI-
OUS” button is pressed when not finished with
the setup, the setting will be canceled, and the
screen will return to the previous screen.
SETTING UP THE START-UP
SCREENWhen you turn the ignition key to ACC, the
SYSTEM START-UP warning is displayed on
the screen. Read the warning and select the
“I AGREE” (English) or “ENTER” (Franc¸ ais) key
then push the PUSH ENTER button.
If you do not push the PUSH ENTER button, this
system will not proceed to the next step display.
To proceed to the next step, refer to the separate
Navigation system Owner’s Manual.
HOW TO USE THE “INFO” BUTTONWhen the “INFO” button is pushed, the “MAIN-
TENANCE INFO.” screen will be displayed.Maintenance informationTo set the maintenance interval for the Engine
Oil or Oil Filter, choose an item using the joystick
and push the PUSH ENTER button.
You can also set to display a message to remind
you that the maintenance needs to be per-
formed.
The following example shows how to set the
engine oil change interval. Use the same steps
to set the other maintenance information.
SAA0933
Heater, air conditioner and audio systems
4-3


04.8.23/Z33-D/V5.0


The “MAINTENANCE NOTIFICATION” screen
displays each time the ignition switch is turned
ON until one of the following conditions are met:

“Reset” is selected.

“Display Maintenance Notification” is set
OFF.

the maintenance interval is set again.
*: Please refer to the separate Navigation system
Owner’s Manual.
HOW TO USE THE “SETTING”
BUTTONThe SETTINGS screen will appear when the
“SETTING” button is pushed.
“Display” settingsThe DISPLAY SETTINGS screen will appear
when pushing the “SETTING” button, selecting
“Display” key and pushing the PUSH ENTER
button.
Brightness/Contrast/Map Background:
To adjust the brightness and contrast of the
screen, select the “Brightness/Contrast Map
Background” key and push the PUSH ENTER
button. Then you can adjust the brightness to
Darker or Brighter, the contrast to Lower or
Higher using the joystick.
For information on Map Background, refer to the
SAA0934
SAA0935
Heater, air conditioner and audio systems
4-5


04.8.23/Z33-D/V5.0


separate navigation system Owner’s Manual.
Display Off:
To turn off the screen, push the “SETTING”
button and select the “Display” key and “Display
Off” key. The indicator of the “Display Off” will
turn to amber. When any mode button is pushed
with the screen off, the screen turns on for
further operation. The screen will turn off auto-
matically 5 seconds after the operation is fin-
ished on the map display.
To turn on the screen, push the “SETTING”
button and select the “Display” key and “Display
Off” key, then set the screen to on by pushing
the PUSH ENTER button.
Display Duration Settings:
When the “DISPLAY SETTINGS” adjustments
are completed, the display automatically returns
to the map display. You can set the length of
time that the “DISPLAY SETTINGS” screen will
be shown after no additional adjustments are
made.
To set the display duration, select the “Display
Duration Settings” key and move the joystick to
the left (shorter duration) or right (longer dura-
tion).
To set the display duration, select the currenttime setting with the joystick and push the PUSH
ENTER button.
Language/Unit settingsThe LANGUAGE/UNIT screen will appear when
selecting the “Language/Unit” key and pushing
the PUSH ENTER button.
Language: “English” or “French”
Unit: “US” — Mile, °F, MPG
“Metric” — km, °C, L/100 km
You can select the language and unit using the
joystick and PUSH ENTER button.
SAA0506
4-6
Heater, air conditioner and audio systems


04.8.23/Z33-D/V5.0
