2005 MERCEDES-BENZ SPRINTER Service Repair Manual

8W-61 POWER DOOR LOCKS
Component Page
Central Timer Module....... 8W-61-2, 3, 4, 5, 6, 7
Cylinder Lock Switch- Driver........... 8W-61-8
Daytime Running Lamps Relay......... 8W-61-2
Door Jamb Switch- Left Sliding......... 8W-61-8
Door Jamb Switch- Rear.............. 8W-61-8
Door Jamb Switch- Right Sliding........ 8W-61-8
Door Lock Motor/Ajar Switch Assembly-
Driver........................... 8W-61-4
Door Lock Motor/Ajar Switch
Assembly- Left Sliding.............. 8W-61-6
Door Lock Motor/Ajar Switch
Assembly- Passenger............... 8W-61-5Component Page
Door Lock Motor/Ajar Switch Assembly-
Rear............................ 8W-61-3
Door Lock Motor/Ajar Switch Assembly-
Right Sliding..................... 8W-61-7
G200.............................. 8W-61-8
G203.............................. 8W-61-2
Interior Lamp- Right Side............. 8W-61-8
Master Door Lock Switch.............. 8W-61-2
Security System Module............... 8W-61-8
VA8W-61 POWER DOOR LOCKS 8W - 61 - 1
