2005 MERCEDES-BENZ SPRINTER Service Repair Manual

8W-45 CENTRAL TIMER MODULE
Component Page
Airbag Control Module................ 8W-45-3
Central Timer Module....... 8W-45-2, 3, 4, 5, 6, 7
Data Link Connector................. 8W-45-3
Door Lock Motor/Ajar Switch
Assembly- Driver.................. 8W-45-2
Door Lock Motor/Ajar Switch
Assembly- Left Sliding............ 8W-45-5, 6
Door Lock Motor/Ajar Switch
Assembly- Passenger............... 8W-45-7
Door Lock Motor/Ajar Switch
Assembly- Rear................. 8W-45-4, 6
Door Lock Motor/Ajar Switch
Assembly- Right Sliding........... 8W-45-5, 6Component Page
Fuse 5............................ 8W-45-3
Fuse 15............................ 8W-45-3
Fuse Block No. 1.................... 8W-45-3
Fuse Block No. 2.................... 8W-45-3
G202.............................. 8W-45-3
Master Door Lock Switch.............. 8W-45-4
Security System Module............... 8W-45-2
Sentry Key Remote Entry Module....... 8W-45-2
Window Defogger Module- Rear......... 8W-45-3
VA8W-45 CENTRAL TIMER MODULE 8W - 45 - 1
