2005 MERCEDES-BENZ SPRINTER Service Repair Manual

8W-39 VEHICLE THEFT SECURITY SYSTEM
Component Page
Central Timer Module............. 8W-39-6, 12
Cylinder Lock Switch- Driver........... 8W-39-6
Data Link Connector.............. 8W-39-7, 10
Door Jamb Switch- Left Sliding........ 8W-39-14
Door Jamb Switch- Rear.............. 8W-39-14
Door Jamb Switch- Right Sliding....... 8W-39-14
Fuse 2.......................... 8W-39-3, 13
Fuse 5.......................... 8W-39-4, 11
Fuse 7............................ 8W-39-10
Fuse 8.......................... 8W-39-4, 5
Fuse 10........................ 8W-39-13, 14
Fuse 14........................... 8W-39-13
Fuse Block No. 1................ 8W-39-4, 5, 10
Fuse Block No. 3.................. 8W-39-3, 13
Fuse/Relay Block............ 8W-39-4, 11, 13, 14
G101.............................. 8W-39-6
G200......................... 8W-39-3, 6, 10
G202............................. 8W-39-13
G203.............................. 8W-39-7
Headlamp Assembly- Left.............. 8W-39-8
Headlamp Assembly- Right............ 8W-39-9
Hood Ajar Switch.................... 8W-39-6
Instrument Cluster........... 8W-39-8, 9, 10, 14
Interior Lamp- Right Side............ 8W-39-14
Intrusion Sensor No. 1.............. 8W-39-2, 3Component Page
Intrusion Sensor No. 2.............. 8W-39-2, 3
Intrusion Sensor No. 3.............. 8W-39-2, 3
Optional Equipment Relay............ 8W-39-13
Panic Alarm Switch.................. 8W-39-7
Security System
Module........ 8W-39-2, 3, 6, 7, 8, 9, 12, 13, 14
Sentry Key Remote Entry
Module............ 8W-39-4, 5, 6, 8, 10, 11, 12
Siren............................. 8W-39-3
SKREEM Antenna.................. 8W-39-12
SKREEM Transponder............... 8W-39-12
Tail Lamp Assembly- Left.............. 8W-39-8
Tail Lamp Assembly- Right............ 8W-39-9
Towing/Intrusion Sensor On/Off Switch . . . 8W-39-7
Trailer Tow Control Module.......... 8W-39-8, 9
Turn Signal No. 1- Left Front........... 8W-39-8
Turn Signal No. 1- Right Front......... 8W-39-9
Turn Signal/Anti-Theft Alarm
Relay- Left................ 8W-39-4, 5, 8, 11
Turn Signal/Anti-Theft Alarm Relay-
Right..................... 8W-39-4, 5, 9, 11
Warm Air Auxiliary Heater Assembly.... 8W-39-14
Window Defogger Relay- Left Rear...... 8W-39-14
Window Defogger Relay- Right Rear.... 8W-39-13
VA8W-39 VEHICLE THEFT SECURITY SYSTEM 8W - 39 - 1
