2005 MERCEDES-BENZ SPRINTER Service Repair Manual

EMISSIONS CONTROL
EXHAUST GAS RECIRCULATION
TABLE OF CONTENTS
page page
VA LV E
DESCRIPTION..........................1
OPERATION............................1REMOVAL.............................2
INSTALLATION..........................2
VA LV E
DESCRIPTION
Exhaust gas recirculation reduces the quantity of
fresh air supplied to the cylinders per stroke without
having to throttle the air supply. As a result, emis-
sions are reduced. If a quantity of exhaust gas is
mixed with the air that is to be used to burn the fuel
in the cylinders, the oxygen content is reduced,
because the exhaust gas is low in oxygen. The result
is that the combustion rate is reduced, as is the com-
bustion temperature. This reduces the quantity of
NOx that are emitted in the exhaust gas (Fig. 1).
OPERATION
The mass of the air supplied to the cylinders per
stroke is the decisive factor for determining the opti-
mum quantity of exhaust gas for the operating con-
dition. This is calculated from the Mass Air Flow
sensor information.
The ECM evaluates this signal as well as that
from the Charge Air Pressure sensor, and outputs a
PWM signal in accordance with one of the maps
stored in it. The signal is sent to the exhaust gas
recirculation valve. The map is formulated to keep
the NOx as low as possible. The EGR valve is actu-
ated by an electric positioning motor.
Fig. 1 EXHAUST GAS RECIRCULATION
1 - E G R VA LV E
2 -CHARGE AIR PRESSURE SENSOR
3 - EXHAUST MANIFOLD
4 - EGR DUCT IN CYLINDER HEAD
5 - INTAKE MANIFOLD
VAEMISSIONS CONTROL 25 - 1

REMOVAL
(1) Disconnect the negative battery cable.
(2) Lift up on the charge air hose retaining clip at
the mixing chamber and disconnect hose with seal
(Fig. 2).
(3) Disconnect the electrical connector at the EGR
positioner (Fig. 2).
(4) Remove mixing chamber support bracket (Fig.
2).
(5) Remove the mixing chamber retaining bolts
and remove chamber (Fig. 2).
INSTALLATION
(1) Clean all gasket mating surfaces.
(2) Position the mixing chamber to the intake
manifold with a new gasket, install bolts and tighten
to 124 lbs.in (14 N´m) (Fig. 2).
(3) Install the mixing chamber support bracket
and tighten the bolts to 124 lbs.in (14 N´m) (Fig. 2).
(4) Connect the EGR positioner electrical connec-
tor (Fig. 2).
(5) Inspect the seal of the charge air inlet tube,
replace as necessary (Fig. 2).
(6) Seat the charge air tube with gasket into the
mixing chamber and push down on the charge air
tube retaining clip (Fig. 2).
(7) Connect negative battery cable.
Fig. 2 MIXING CHAMBER AND EGR POSITIONER
1 - EGR POSITIONER
2 - GASKET
3 - MIXING CHAMBER
4 - CHARGE AIR HOSE RETAINING CLIP
5 - GASKET
6 - CHARGE AIR HOSE
7 - BRACKET
8 - BOLT
25 - 2 EXHAUST GAS RECIRCULATIONVA
VALVE (Continued)

INDEX
