(17) Install exhaust heat shield (5) (Fig. 70).
(18) Install retaining bracket (4) (Fig. 70). Bracket
is asymmetric. The slanted side must be installed on
the left side in the direction of travel.
(19) Attach propeller shaft (1) (Fig. 70) to the
transmission (Refer to 3 - DIFFERENTIAL & DRIV-
ELINE/PROPELLER SHAFT/PROPELLER SHAFT -
INSTALLATION).(20) Install oil filler pipe.
(a) Guide oil filler pipe (1) (Fig. 71) down and
into position.
(b) Push lower connection of oil filler pipe (1)
(Fig. 71) into the fill hole in the side of the trans-
mission housing.
(c) Install bolts (2) (Fig. 71) to cylinder head.
Tighten the bolts to 8 N´m (71 in.lbs.).
(d) Install bolt (3) (Fig. 71) to transmission
flange and bolt (2) to transmission housing.
Tighten the bolt to 8 N´m (71 in.lbs.).
Fig. 69 Install Driver's Side Cooler Line
1 - COOLER LINE
Fig. 70 Install Propeller Shaft and Heat Shield
1 - PROPELLER SHAFT
2 - BOLT
3 - BOLT
4 - RETAINING BRACKET
5 - HEAT SHIELD
6 - WASHER
7 - BOLT
Fig. 71 Install the Fill Tube
1 - FILL TUBE
2 - BOLTS TO CYLINDER HEAD AND TRANSMISSION HOUSING
3 - BOLT TO TRANSMISSION FLANGE
VAAUTOMATIC TRANSMISSION - NAG1 21 - 45
AUTOMATIC TRANSMISSION - NAG1 (Continued)

(21) Install the oil drain plug (2) (Fig. 72) with a
new seal into the transmission oil pan. Tighten the
drain plug to 20 N´m (14.5 ft.lbs.).(22) Lower vehicle and fill transmission with cor-
rect automatic transmission fluid (Refer to 21 -
TRANSMISSION/AUTOMATIC - NAG1/FLUID -
STANDARD PROCEDURE).
(23) Road test the vehicle and verify the repair.
Fig. 72 Install the Oil Drain Plug
1 - SEAL
2 - DRAIN PLUG
21 - 46 AUTOMATIC TRANSMISSION - NAG1VA
AUTOMATIC TRANSMISSION - NAG1 (Continued)

SCHEMATICS AND DIAGRAMS
HYDRAULIC FLOW IN PARK
VAAUTOMATIC TRANSMISSION - NAG1 21 - 47
AUTOMATIC TRANSMISSION - NAG1 (Continued)

HYDRAULIC FLOW IN REVERSE - FAILSAFE
21 - 48 AUTOMATIC TRANSMISSION - NAG1VA
AUTOMATIC TRANSMISSION - NAG1 (Continued)

HYDRAULIC FLOW IN REVERSE
VAAUTOMATIC TRANSMISSION - NAG1 21 - 49
AUTOMATIC TRANSMISSION - NAG1 (Continued)

HYDRAULIC FLOW IN NEUTRAL - DEFAULT
21 - 50 AUTOMATIC TRANSMISSION - NAG1VA
AUTOMATIC TRANSMISSION - NAG1 (Continued)

HYDRAULIC FLOW IN NEUTRAL
VAAUTOMATIC TRANSMISSION - NAG1 21 - 51
AUTOMATIC TRANSMISSION - NAG1 (Continued)

HYDRAULIC FLOW IN NEUTRAL TO DRIVE TRANSITION
21 - 52 AUTOMATIC TRANSMISSION - NAG1VA
AUTOMATIC TRANSMISSION - NAG1 (Continued)
