2005 MERCEDES-BENZ SLR CLASS fuel consumption

121 Controls in detail
Control system
Menus, submenus and functions
Menu1
Menu2
Menu3
Menu4
Menu5
Menu6
Standard display
AUDIO
Vehicle status
message memory
Settings
Trip computer
Telephone
(page 122)
(page 122)
(page 124)
(page 125)
(page 136)
(page 138)
Commands/submenusDigital speedometer
Select radio station
Call up vehicle mal-
function, warning
and system status
messages stored in
memory
Reset to factory set-
tings
Fuel consumption
statistics after start
Load phone book
Call up maintenance
service display
Operate the
CD player
Instrument cluster
submenu
Fuel consumption
statistics since the
last reset
Search for name in
phone book
Check tire inflation
pressure
Lighting submenu
Call up range
Vehicle submenu

136 Controls in detailControl system
Press button j or k repeatedly
until you see this message in the left
display:
Automatic Door lock
.
The selection marker is on the current
setting.

Press æ or ç to switch Automatic Door lock
On or
Off
.Tire inflation pressure display
Use this function to set the unit for the tire
inflation pressure display.

Move the selection marker with the
æ or ç button to the
Vehicle

submenu.

Press button j or k repeatedly
until you see this message in the left
display:
Tire press. display
.
The selection marker is on the current
setting.

Press æ or ç to select the de-
sired tire inflation pressure unit.
Trip computer menu
Use the trip computer menu to call up
statistical data on your vehicle.
The following information is available:Function
Page
Fuel consumption statistics after
start
137
Fuel consumption statistics since
last reset
137
Call up range (distance to empty)
138
iThe last function called up will reap-
pear the next time you enter the trip
computer menu.


137 Controls in detail
Control system
Fuel consumption statistics after start
Press button ÿ or è repeatedly
until you see the first function of the
Trip computer menu.

Press button j or k repeatedly
until you see this message in the left
display:
After start.
1Distance driven since start
2Average speed since start
3Time elapsed since start
4Average fuel consumption since startFuel consumption since last reset

Press button ÿ or è repeatedly
until you see the first function of the
Trip computer menu.

Press button j or k repeatedly
until you see this message in the left
display:
From reset.
1Distance driven since last reset
2Average speed since last reset
3Time elapsed since last reset
4Average fuel consumption since last re-
set
iAll statistics stored since the last en-
gine start will be reset approximately
four hours after the SmartKey in the
starter switch is turned to position0 or
removed from the starter switch.
Resetting will not occur if you turn the
SmartKey back to position1 or2 with-
in this time period.

138 Controls in detailControl systemResetting fuel consumption statistics
Press button ÿ or è repeatedly
until you see the first function of the
Trip computer menu.

Press button j or k repeatedly
until you see the reading that you want
to reset in the left display.

Press and hold the reset button in the
instrument cluster (
page 29) until
the value is reset to 0.Calling up range (distance to empty)

Press button ÿ or è repeatedly
until you see the first function of the
Trip computer menu.

Press button j or k repeatedly
until you see this message in the left
display:
Range
.
In the right display you will see the cal-
culated range based on the current fuel
tank level. Your driving style will affect
the accuracy of the calculated range.
TEL menuWarning!
G
A driver’s attention to the road must always
be his/her primary focus when driving. For
your safety and the safety of others, we rec-
ommend that you pull over to a safe location
and stop before placing or taking a tele-
phone call. If you choose to use the tele-
phone while driving, please use the
hands-free device and only use the tele-
phone when weather, road, and traffic con-
ditions permit.
Some jurisdictions prohibit the driver from
using a cellular telephone while driving a ve-
hicle.
Bear in mind that at a speed of just 30 mph
(approximately 50 km/h), your vehicle is
covering a distance of 44 feet
(approximately 14 m) every second.

229 Operation
Driving instructions
Driving instructions
Drive sensibly – save fuel
Fuel consumption, to a great extent,
depends on driving habits and operating
conditions.
To save fuel you should:

Keep tires at the recommended tire
inflation pressures.


Remove unnecessary loads.


Allow engine to warm up under low
load use.


Avoid frequent acceleration and decel-
eration.


Have all maintenance work performed
at the intervals specified in the
Maintenance Booklet and as required
by the maintenance service display.
Contact an authorized Mercedes-Benz
Center.
Fuel consumption is also increased by
driving in cold weather, in stop-and-go
traffic, on short trips and in hilly area.
Drinking and driving
Pedals
Warning!
G
Drinking and driving and/or taking drugs
and driving are very dangerous combina-
tions. Even a small amount of alcohol or
drugs can affect your reflexes, perceptions
and judgement.
The possibility of a serious or even fatal
accident are greatly increased when you
drink or take drugs and drive.
Do not drink or take drugs and drive or allow
anyone to drive who has been drinking or
taking drugs.
Warning!
G
Keep driver’s foot area clear at all times.
Objects stored in this area may impair pedal
movement.

369 Technical data
Rims and tires
Rims and tires
Only use tires and rims which have been
specifically developed for your vehicle and
tested and approved by Mercedes-Benz.
Other tires and rims can have detrimental
effects, such as

Poor handling characteristics


Increased noise


Increased fuel consumption
!Moreover, tires and rims not approved
by Mercedes-Benz may, under load,
exhibit dimensional variations and dif-
ferent tire deformation characteristics
that could cause them to come into
contact with the vehicle body or axle
parts. This may result in damage to the
tires or the vehicle.
iFurther information on tires and rims is
available at any authorized
Mercedes-Benz Center. A placard with
the recommended tire inflation pres-
sures is located on the driver’s door
B-pillar. Some vehicles may have sup-
plemental tire pressure information for
driving at high speeds (
page 263) or
for vehicle loads less than the maxi-
mum loaded vehicle condition. If such
information is provided, it can be found
on the placard located on the inside of
the fuel filler flap. The tire pressure
should be checked regularly and
should only be adjusted on cold tires.
Follow tire manufacturer’s mainte-
nance recommendation included with
vehicle.

398 IndexF
Fahrenheit
Setting temperature units 129
Fastening the seat belts 45
Fine adjustment
Cruise control 199
First aid kit 340
Fitting
Anti-theft wheel nuts 283
Flat tire 349
TIREFIT kit 349
Floormat
Driver’s side 221
Installing 221
Removing 221
Fog lamp, rear 347
Switching on 109
Fog lamps, front 347
Switching on 108
Front airbags 68
Front bulbs 347
Front lamps
Switching on 105Fuel
Additives 379
Gasoline additives 379
Premium unleaded gasoline 376,
378
Requirements 378
Reserve warning 29
Fuel consumption statistics
After start 137
Since last reset 137
Fuel filler flap 240
Locking 240
Unlocking 240
Fuel requirements 378
Fuel reserve
Message in the multifunction
display 339
Warning lamp 301
Fuel system
Message in the multifunction
display 329
Fuel tank
Filler flap 240
Fuels, coolants, lubricants etc. 375
Functions (control system) 119, 121
Fuses 361G
Garage door opener 33, 215
Gasoline 240
GAWR 279
Gear range
Automatic transmission 170
Limiting 170
Shifting into optimal 169
Gear range limit
Canceling 169
Gear selector lever 32, 167
Lock 48, 388
Position 171
Position (automatic
transmission) 167
Gearshift
Indicator lamp 29
Gearshift program
Manual 173, 175
Global
Locking 98
Unlocking 98

405 Index
Q
Quick search
Phone book 141
R
Radio
Selecting stations 123
Station search 123
Station selection setting 135
Radio operation 149
Radio see Radio operation
Radio transmitters, control and
operation 237
Range (distance to empty)
Calling up 138
Reactivating
Automatic climate control 191
Reading lamp 33
Rear
Storage compartment 201
Rear bulbs 347Rear fog lamp
Switching on 109
Rear lamps see Tail lamps
Rear view mirrors see Mirrors
Rear window defroster 181
Rear-view mirror 33
Recommended inflation pressure 280
Redial memory 142
Refueling 240
Refuelling
Unleaded premium grade
gasoline 240
Regular checks 241
Remote control
SmartKey 96
Removing
Anti-theft wheel nuts 283
Replacing
Battery (SmartKey) 344
Wiper blades 348Resetting
All functions (control system) 126
ESP 307
Fuel consumption 138
Maintenance service indicator 288
Trip odometer 115
Residual heat utilization 190
Restraint system see Infant and child re-
straint systems
Restraint systems 62
Airbags 62, 63
Child seat recognition 62
Child seats 62
Emergency Tensioning Device
(ETD) 62, 72
Seat belts 62, 69
Rim 280
RON 240, 388
Roof rack 225
