2005 MERCEDES-BENZ SL500 parking sensors

223 Controls in detail
Driving systems
Parktronic* (Parking assist)
The Parktronic system is an electronic aid
designed to assist the driver during park-
ing maneuvers. It visually and audibly indi-
cates the relative distance between the
vehicle and an obstacle.
The Parktronic system is automatically ac-
tivated when you switch on the ignition, re-
lease the parking brake, or place the gear
selector lever in Position D, R, or N. The
Parktronic system deactivates at speeds
above 11 mph (18 km/h). At lower speeds
the Parktronic system turns on again.
The Parktronic system also deactivates
when you place the gear selector lever in
Position P or depress the brake pedal.The Parktronic system monitors the sur-
roundings of your vehicle with six sensors
in the front bumper and four sensors in the
rear bumper.
1Sensors in the front bumperWarning!
G
Parktronic is a supplemental system. It is
not intended to, nor does it replace, the
need for extreme care. The responsibility
during parking and other critical maneuvers
always rests with the driver.
Special attention must be paid to objects
with smooth surfaces or low silhouettes
(e.g. trailer couplings, painted posts, or road
curbs). Such objects may not be detected by
the system and can damage the vehicle.
The operational function of the Parktronic
system can be affected by dirty sensors, es-
pecially at times of snow and ice. See
“Cleaning the Parktronic* system sensors”
(page 318).
Interference caused by other ultrasonic sig-
nals (e.g. working jackhammers, car wash,
or the air brakes of trucks) can cause the
system to send erratic indications, and
should be taken into consideration.
Warning!
G
Make sure no persons or animals are in the
area in which you are maneuvering. Other-
wise you run the risk of causing injury.

224 Controls in detailDriving systemsRange of the sensors
To function properly, the sensors must be
free of dirt, ice snow and slush. Clean the
sensors regularly, being careful not to
scratch or damage the sensors, see
“Cleaning the Parktronic system* sensors”
(page 318).
Front sensors
Rear sensors
Center
approx. 40 in (100 cm)
Corners
approx. 24 in (60 cm)
Center
approx. 48 in (120 cm)
Corners
approx. 32 in (80 cm)
!During parking maneuvers, pay special
attention to objects located above or
below the height of the sensors (e.g.
planters or trailer hitches).
The Parktronic system will not detect
such objects at close range and dam-
age to your vehicle or the object may
result.
Ultrasonic signals from outside sourc-
es (e.g. truck air brakes, car wash, or
jackhammers) may impair the opera-
tion of the Parktronic system.

458 IndexOperating
CD player 141
Navigation system 142
Radio 140
Telephone* 161
Overhead control panel 31
Overspeed range 132, 442
P
Panic alarm 78
Panic button on SmartKey 78
Panorama roof*
Sunshade 203
Sunshade closing 204
Sunshade opening 204
Parcel net in passenger footwell 231
Parcel net in trunk 231
Parktronic* deactivation switch 30
Parking 259
Parking assistance (Parktronic*) 223
Parking brake
Engaging 57
Releasing 50
Parking brake pedal 23Parking lamps 381
Replacing the bulbs 384
Switching on 123
Parking position
Exterior rear view mirrors 121, 158,
179
Parktronic* 30, 223, 442
Activating 226
Cleaning system sensors 318
Deactivating 226
Malfunctioning 227
Minimum distance 225
Range 224
Rear sensors 225
System sensors 318
Warning indicators 23, 225
Parts service 416
Passenger side
Front airbag 68
Head-thorax airbag 69
Parcel net in footwell 231Pedals 255
Phone book* 162
Loading 163
Quick search 163
Phone number*
Dialing 162
Redialing 163
Plastic and rubber parts
Cleaning 321
Poly-V-belt drive 442
Layout 419
Potential problems associated with under-
inflated and overinflated tires 294
Power assistance 256
Power seat
Adjusting backrest tilt 41
Adjusting head restraint height 41
Adjusting head restraint tilt 41
Adjusting seat cushion depth 41
Adjusting seat cushion tilt 41
Adjusting seat height 41
