2005 MERCEDES-BENZ E-Class service reset

Contents
Entering a city. . . . . . . . . . . . . . . . 118
Narrowing of the destination
after selecting city . . . . . . . . . . . . 119
Entering a city center . . . . . . . . . . 120
Entering a street in the
destination city . . . . . . . . . . . . . . . 121
Narrowing of the destination
after selecting street . . . . . . . . . . 122
Entering an intersection . . . . . . . . 123
Entering a house number . . . . . . . 124
Entering a destination using the
map . . . . . . . . . . . . . . . . . . . . . . . 125
Entering a destination via
geo coordinates . . . . . . . . . . . . . . 127
Storing map location . . . . . . . . . . 128
Route guidance . . . . . . . . . . . . . . . . . 130
Start route guidance menu . . . . . . 130
Route calculation . . . . . . . . . . . . . 130
Route re-calculation . . . . . . . . . . . 130
Navigation announcements . . . . . 131
Navigation displays. . . . . . . . . . . . 131
Destination reached . . . . . . . . . . . 134
Cancelling route guidance . . . . . . 134
During route guidance . . . . . . . . . . . . 135
Showing soft key displays . . . . . . 135
Info menu . . . . . . . . . . . . . . . . . . . 135Displaying the route on the map . 136
Displaying the route list . . . . . . . . 137
Detour function . . . . . . . . . . . . . . 137
Stop-over . . . . . . . . . . . . . . . . . . . 139
Defining route guidance displays . 142
Setting symbols displays . . . . . . . 142
Setting map orientation . . . . . . . . 143
Switching GPS position display
ON/OFF . . . . . . . . . . . . . . . . . . . . 144
Automatic map toggling . . . . . . . . 145
Scales for full-screen and
split-screen map display . . . . . . . . 145
Last destinations and
destination memory . . . . . . . . . . . . . . 147
Last destinations memory . . . . . . 147
Destination memory . . . . . . . . . . . 148
POIs (Points of Interest) . . . . . . . . . . . 151
Entering POIs . . . . . . . . . . . . . . . . 151
Selecting POI in the local area of
the current position . . . . . . . . . . . 152
Selecting POI for a selected city. . 153
Selecting POI for a long-distance
destination . . . . . . . . . . . . . . . . . . 153
Selecting a POI using the map . . . 155
Service . . . . . . . . . . . . . . . . . . . . . . . 157
Tele Aid*. . . . . . . . . . . . . . . . . . . . . . . 158
Emergency call system . . . . . . . . . 158
Roadside Assistance . . . . . . . . . . . 158
Information . . . . . . . . . . . . . . . . . . 159System . . . . . . . . . . . . . . . . . . . . . . . 161
System settings . . . . . . . . . . . . . . . . . 162
Calling up the System menu . . . . . 162
Setting the date/time . . . . . . . . . . 162
Setting the language . . . . . . . . . . . 164
Switching confirmation beeps
and acoustic signals ON/OFF. . . . 165
Display settings . . . . . . . . . . . . . . 165
Voice control settings* . . . . . . . . . 166
Reset function. . . . . . . . . . . . . . . . 169Glossary . . . . . . . . . . . . . . . . . . . . . . 171Index . . . . . . . . . . . . . . . . . . . . . . . . . 175

76 Satellite radio*Satellite radio operationMain area, in this example:
ROCK
= selected category (
page 77)

Vault
= name of the selected station
Status bar, in this example:

SAT
(on the left) = the selected mode

SAT5
= location in the program
memory, if the current channel is pre-
stored

Ch16
= number of the current channel
Selectable soft keys

Presets

shows channels pre-stored in the pro-
gram memory (up to 10 channels). You
can store stations (
page 79) and re-
quest stored stations (page 76).

Info

shows additional text information relat-
ed to the current channel.

Scan

is used to start and stop the scan
search (
page 79).

Service

displays a screen showing the tele-
phone number of the Sirius Service
Center and electronic serial number
(ESN) of the particular receiver.
You can also adjust the following:

Bass and treble (
page 32)

Balance and fader (
page 31)

Sound functions (
page 33)

Volume (not on soft keys)
(page 30)
The following options are available:

Tuning via station presets (
page 76)

Tuning via manual channel input
(page 77)

Tuning via the program category list
(page 77)

Tuning a station within the selected
category (
page 78)

Tuning via scan search (
page 79)
Tuning via station presets
Ten Satellite radio station presets are
available.
You can access the presets via number
keys or via the Presets menu.
Selecting a station
iThe Presets memory is empty at first-
time activation of the system.

80 Satellite radio*Satellite radio operationStoring via Presets menu
Press the
Presets
soft key.
The Preset list appears.

Use or  to select a preset loca-
tion.

Press for more than 2 seconds.
The currently selected station is stored
in the corresponding preset location.Resetting Presets menu
The
Presets
soft key is active indicated by
its color changed.

Press the
Presets
soft key.
All channels in the Preset list are delet-
ed.

Press the
Service
soft key.The telephone number of the Sirius
Service Center and the twelve-digit
electronic serial number (ESN) of the
particular receiver appear.
It may be necessary to call the Sirius Ser-
vice Center if, for example:

you want to cancel the subscription or
to re-subscribe at a later date,

you forget to pay the bill, or

you sell the car to another person.
Calling the Sirius Service Center

180 IndexSelecting
CD . . . . . . . . . . . . . . . . . . . . . . . . . . . 67
destination
of destination memory. . . . . . . . . 148
of Last destinations . . . . . . . . . . . 147
folder (MP3 mode) . . . . . . . . . . . . . . 54
POIs. . . . . . . . . . . . . . . . . . . . . . . . . 151
satellite radio station . . . . . . . . . . . . 76
telephone book entry . . . . . . . . . . . . 99
track
in CD changer mode . . . . . . . . . . . 68
in MP3 mode . . . . . . . . . . . . . . . . . 55
in Single CD mode . . . . . . . . . . . . . 47
Setting
balance . . . . . . . . . . . . . . . . . . . . . . . 31
for navigation announcements . . 112
bass. . . . . . . . . . . . . . . . . . . . . . . . . . 32
for navigation announcements . . 112
date . . . . . . . . . . . . . . . . . . . . . . . . . 162
date format . . . . . . . . . . . . . . . . . . . 162
display brightness . . . . . . . . . . . . . . 166fader . . . . . . . . . . . . . . . . . . . . . . . . . 31
for navigation announcements . . 112
language . . . . . . . . . . . . . . . . . . . . . 164
map orientation . . . . . . . . . . . . . . . . 143
radio station . . . . . . . . . . . . . . . . 38, 41
route mode . . . . . . . . . . . . . . . . . . . 111
time . . . . . . . . . . . . . . . . . . . . . . . . . 162
time format . . . . . . . . . . . . . . . . . . . 162
treble . . . . . . . . . . . . . . . . . . . . . . . . . 32
for navigation announcements . . 112
volume. . . . . . . . . . . . . . . . . . . . . . . . 31
for navigation announcements . . 112
Showing soft key displays (Navigation
mode). . . . . . . . . . . . . . . . . . . . . . . . . 135
SIM card . . . . . . . . . . . . . . . 85, 88, 173
SIM CARD BLOCKED. . . . . . . . . . . . . . 88
Single CD mode . . . . . . . . . . . . . . . . . 44
controls . . . . . . . . . . . . . . . . . . . . . . . 14
safety Instructions . . . . . . . . . . . 37, 44
switching to. . . . . . . . . . . . . . . . . . . . 45
Sirius Satellite Radio . . . . . . . . . . . . . 74
Sirius Service Center
calling the . . . . . . . . . . . . . . . . . . . . . 80SMS . . . . . . . . . . . . . . . . . . . . . . . . . . 173
deleting . . . . . . . . . . . . . . . . . . . . . . 103
reading . . . . . . . . . . . . . . . . . . . . . . 102
Soft key displays
showing in Navigation mode . . . . . . 135
Soft keys. . . . . . . . . . . . . . . . . . 28, 173
Sound functions. . . . . . . . . . . . . . . . . 33
switching . . . . . . . . . . . . . . . . . . . . . . 34
Speed dial . . . . . . . . . . . . . . . . . . . . . . 95
Spoken names to a phone book
entry . . . . . . . . . . . . . . . . . . . . . . . . . 100
Starting route guidance. . . . . . . . . . 130
Station (radio)
presets . . . . . . . . . . . . . . . . . . . . 39, 42
search . . . . . . . . . . . . . . . . . . . . . 38, 41
setting . . . . . . . . . . . . . . . . . . . . . 38, 41
storing . . . . . . . . . . . . . . . . . . . . . . . . 42
Station (satellite radio)
presets . . . . . . . . . . . . . . . . . . . . . . . 76
scan search . . . . . . . . . . . . . . . . . . . . 79
selecting . . . . . . . . . . . . . . . . . . . . . . 76
storing . . . . . . . . . . . . . . . . . . . . . . . . 79
