Page 118 of 186
117 Navigation*
Destination entry
Or, to store the selected destination as
home adress, press.
Call up the Navigation main menu
(page 110).
Use or to select the Destination entry
menu item and
press.
The Destination entry menu appears.
The destination displayed last can now
be adopted (
page 118), or another
location can be entered (
page 118).
Call up the Destination entry menu. The
Destination entry menu represents the
starting point.
Besides entering the name of a city
(
page 118), the following soft keys are
available for selecting a destination:
Map
soft key
Provides access to destination input di-
rectly via road map (
page 125).
Region
soft key
Provides access to the region input
(
page 117).
Street
soft key
Provides access to input of the destina-
tion street (
page 121).
CityCtr
soft key
Provides access to the input of a city
section (center) (
page 120).
POIs
soft key
Provides access to the input of a POI
(Point of interest) (
page 151).
List
soft key
Allows selecting a destination city from
a city list (
page 119).
In the Destination entry menu
(
page 117) the region currently selected
is indicated by the characters in parenthe-
sis in the status bar.
To change the region press the
Region
soft key.
The region list appears.
Destination entry menu
Entering a destination
iThe
Street
, CityCtr
, and
POIs
soft key
functions refer to the city on display.
If you wish to choose global POIs not
referring to a city (
page 151).
Selecting the region
Page 119 of 186
118 Navigation*Destination entry
Useor to select a region.
Press .
Selecting a different region deletes the
city last entered. The first city of the
newly selected region appears (in al-
phabetical order).
The Destination entry menu (
page 117)
represents the starting point.
Enter city (USA)
appears in the status bar.
The characters in parenthesis indicate the
selected region.
Accepting the displayed destination
Press and hold for approx. 2 sec-
onds.Entering a different city
Use the keypad menu or the 12 buttton
keypad to enter the data of the city
(page 114).
After entering the city a selection list of
cities appears. Now continue with se-
lecting a city.
Switching to a selection list is possible at
any time while entering a city.
Press the
List
soft key.
The selection list appears. Now contin-
ue with selecting a city.
Entering a city
iDo not confuse the button with the
symbol in the main screen. ok
Page 120 of 186
119 Navigation*
Destination entry
Selecting a city
Useor to select the destina-
tion city. The
Page
soft keys allow scroll-
ing through the list page by page.
Press.After selecting the desired city, one of
the following menus appears:
For larger cities with more than 15
streets:
Enter Street menu (
page 121).
For smaller cities with up to
15 streets:
Select Street menu (
page 121).
If no streets are registered for the
selected city:
Select City Center menu
(page 120).
The appropriate menu can be identified
from the display in the status bar.
.Besides entering a street name
(page 121), the following soft keys are
available for narrowing the destination:
Map
soft key
Provides access to further destination
input directly via road map
(page 125).
iThe selection is cancelled if the
Back
soft key is pressed.
Narrowing of the destination after
selecting city
Page 121 of 186
120 Navigation*Destination entry
CityCtr
soft key
Provides access to the selection of a
section of the city (center)
(
page 120).
POIs
soft key
Provides access to the input of a POI
referring to the destination city
(
page 152).
After the destination city (
page 118) has
been entered, the associated city center
(section of the city) can be selected.
Press the
CityCtr
soft key.
Enter center
is displayed in the status
bar.
.Accepting the destination displayed
Press and hold for approx. 2 sec-
onds.
Entering a center
Use the keypad menu or the 12 buttton
keypad to enter the data of the center
(page 114).
After entering the center a selection
list of centers appears. Now continue
with selecting a center.Switching to a selection list is possible at
any time while entering a center.
Press the
List
soft key.
The selection list appears. Now contin-
ue with selecting a center.
Selecting a city center
.
Useor to select a city center.
The
Page
soft keys allow scrolling
through the list page by page.
Entering a city center
Page 122 of 186
121 Navigation*
Destination entry
Press .
The Start Route Guidance menu
(page 130) appears.
The system accesses one of the following
menus after entering of a destination city
(
page 118):
For larger cities with more than 15
streets:
Enter Street menu.
For smaller cities with up to 15 streets:
Select Street menu (
page 121).
If no streets are registered for the se-
lected city, or if a street extends
through several city centers:
Select City Center menu (
page 120).
The appropriate menu can be identified
from the display in the status bar.Entering a street
Use the keypad menu or the 12 buttton
keypad to enter the data of the street
(page 114).
After entering the street a selection list
of streets appears. Now continue with
selecting a street.
Switching to a selection list is possible at
any time while entering a street.
Press the
List
soft key.
The selection list appears. Now contin-
ue with selecting a street.Selecting a street
Use or to select a street. The Page
soft keys allow scrolling through
the list page by page.
Press .
The Start Route Guidance menu with
the selected destination information
appears;
or
If the street extends through several
city centers, the list of city centers re-
ferring to the street selected appears.
Entering a street in the destination
city
Page 123 of 186
122 Navigation*Destination entrySelecting the city center referring to
the street selected
The system distinguishes between streets
with the same name in a city by specifying
the center. After selecting a street, a list of
city centers may appear.
The status bar shows how many times the
system found the same street name within
a given city.
Use or to select a center and
press.The Start Route Guidance menu with
the selected destination information
appears.
The following soft keys are available to
continue narrowing the destination after
entering the street:
Map
soft key
Provides access to further destination
input directly via road map
(page 125).
Intrsct.
soft key
An intersection with the destination
street can be entered (
page 123).
Hse. no.
soft key
A house number on the destination
street can be entered (
page 124).
POIs
soft key
A POI on or near the destination street
can be entered (
page 152).
The following soft keys can also be select-
ed:
Mode
soft key
For setting the route mode
(
page 111).
Save
soft key
Stores the entered destination in the
destination memory (
page 149).
Narrowing of the destination after
selecting street
iOnly the entry of either an intersecting
road or a house number is possible.
Page 124 of 186
123 Navigation*
Destination entry
After entering a street (
page 121), a
street intersecting with this street can be
entered.
Press the
Intrsct.
soft key.
The Enter Intersection menu or a list of
all intersecting streets appears. Enter Intersection menu
Proceed the same as when entering a
street (
page 121).List of intersecting streets
Use or to select an intersec-
tion. The
Page
soft keys allow scrolling
through the list page by page.
Press .
The Start Route Guidance menu
(page 130) appears.
Entering an intersectioniThe
Intrsct.
soft key is only available if
streets intersecting the destination
street are stored as intersections on
the navigation DVD.
Page 125 of 186
124 Navigation*Destination entryA house number can be entered after en-
tering the destination street (
page 121).
Press the
Hse. no.
soft key.The Enter House Number menu ap-
pears (
page 124), or the house num-
ber list appears. Now a house number
range can be selected (
page 125).
Enter House Number menu
Use, , ,, or to
select the numbers. Press after
each selection.
or
Press - to enter the numbers.
Press the
Delete
soft key if necessary.
The number last accepted by the sys-
tem is deleted.
Press and hold for approx. 2 sec-
onds to confirm the input;
or
Entering a house numberiAn intersection instead of a house
number can be entered (
page 123).
Entry of both is not possible.
iThe
Hse. no.
soft key is only available
when registered house numbers are
stored on the navigation DVD for the
selected street.
iSymbol “”XX represents a space.iDo not confuse the
Delete
soft key (de-
letion of the last number) with the
Back
soft key (deletion of the complete en-
try).
