2005 MERCEDES-BENZ E-Class reset

40 AudioRadio operation
Use , ,  or  to choose a
preset and press.
or

Press one of the number keys

- .
The system tunes to the station stored
under this number.
Tuning via scan search
Scan search is characterized as follows:

Scan search performs two runs.
During the first run, stations with ex-
tremely good reception are played.
During the second run, stations with
weaker reception are played.

Scan search plays each receivable sta-
tion for approx. 8 seconds.

Scan search can be ended manually.

Scan search automatically stops at the
station listened to before the scan
search was started.
Starting scan search

Switch to the desired waveband
(page 37).

Press the
Scan
soft key.
Scanning begins.
Ending Scan search manually

Press the
Scan
soft key again.Manual tuning

Switch to the desired waveband
(page 37).

Press and hold or  for at
least 2 seconds to tune up or down.
Manual tuning is activated.

Keep the button pressed or release it
and keep tapping or  in
quick succession.
The frequency will change by the tuning
increments for the respective wave-
band each time one of the buttons is
pressed or for as long as a button is
pressed and held.
Manual tuning is deactivated if no but-
ton is pressed for approx. 3 seconds.

42 AudioRadio operation
The system will tune to the strongest
receivable station.

Press  or.
Search begins in ascending or
descending frequency.
The search stops at the next receivable
station.
On multifunction steering wheel

Switch the multifunction display in the
instrument cluster to Radio display
(page 25).

Pressj ork.
The search stops at the next receivable
station. Tuning via station presets
The seven strongest channels are sorted in
prest 1 to 7 each time you press the
WB soft
key. They are accessed using the number
keypad.

Press one of the number keys

- .
The system tunes to the station stored
under this number.
Ten presets each are available for the
FM and AM waveband.
The following options are available:

Storing manually using number keys

Storing manually using the Presets
menu

Storing using Autostore Storing manually using the number
keys
-

Tune to the station to be stored
(page 38).

Press a number key between
and
 and hold it for more than 2 sec-
onds.
The station is now stored in the respec-
tive memory location.
Storing manually using the Presets
menu

Tune to the station to be stored
(page 38).

Press the
Presets
soft key.
The Presets menu appears.
Storing FM/AM stations

43 Audio
Radio operation

Use, ,  or  to select a
preset.

Press for more than 2 seconds.
The station will be stored in the respec-
tive memory location.
Storing using Autostore
The Autostore function places stations into
the Autostore memory sorted by reception
quality.
The system stores the station with the
strongest signal in preset 1.

Switch to the desired waveband
(page 37).

Press the
Autost.
soft key.
The Autostore preset list appears.

Use to select the Reprogram Autostore
header entry.

Press.
The Autostore search starts. After a de-
lay the new preset assignment ap-
pears. The system tunes to the station
stored on preset 1.
To tune-in another station from the
Autostore preset list (
page 39).
iThe Autostore feature stores presets in
a separate memory, not in the regular
presets seen under the
Presets
soft key.
As such, the Autostore memory is only
temporary.

76 Satellite radio*Satellite radio operationMain area, in this example:
ROCK
= selected category (
page 77)

Vault
= name of the selected station
Status bar, in this example:

SAT
(on the left) = the selected mode

SAT5
= location in the program
memory, if the current channel is pre-
stored

Ch16
= number of the current channel
Selectable soft keys

Presets

shows channels pre-stored in the pro-
gram memory (up to 10 channels). You
can store stations (
page 79) and re-
quest stored stations (page 76).

Info

shows additional text information relat-
ed to the current channel.

Scan

is used to start and stop the scan
search (
page 79).

Service

displays a screen showing the tele-
phone number of the Sirius Service
Center and electronic serial number
(ESN) of the particular receiver.
You can also adjust the following:

Bass and treble (
page 32)

Balance and fader (
page 31)

Sound functions (
page 33)

Volume (not on soft keys)
(page 30)
The following options are available:

Tuning via station presets (
page 76)

Tuning via manual channel input
(page 77)

Tuning via the program category list
(page 77)

Tuning a station within the selected
category (
page 78)

Tuning via scan search (
page 79)
Tuning via station presets
Ten Satellite radio station presets are
available.
You can access the presets via number
keys or via the Presets menu.
Selecting a station
iThe Presets memory is empty at first-
time activation of the system.

77 Satellite radio*
Satellite radio operation
Accessing via number keys
Press one of the number keys

- .
The system will tune to the station
stored under this number.
Accessing via Presets menu.

Press the
Presets
soft key.
The Presets list appears.

Use  or  to choose a preset and
press,
or

Press one of the number keys

- .
The system tunes to the station stored
under this number.
Tuning via manual channel input
Example: Tuning in channel 12

Press.

Press
and !.
The system tunes to channel 12.
Tuning via the program category list
The category list contains all currently re-
ceivable categories of programs. It is sort-
ed alphabetically.Only one entry is visible at a time. The en-
try appears at the top of the main screen.
Selecting a category
Example 1: category
ALL

The station list of category
ALL
contains all
receivable channels (channel mode).

Use or  to select the category All
from the list.
The station listened to before remains
tuned.
iIf an entry is made and such a channel
is not available, the message
Channel

unavailable
appears. The channel select-
ed last continues playing.

79 Satellite radio*
Satellite radio operation

Pressj.
The search proceeds in descending or-
der and stops at the first receivable
station.
Tuning via scan search
Scan search is characterized as follows:

Scan search plays a channel for
approx. 8 seconds and then skips to
the next channel within the current
category.

Scan search can be ended manually.

Scan search stops automatically at the
station that was playing when scan
search was started.

Press the
Scan
soft key.
The scan search starts.

Press the
Scan
soft key again.
The scan search ends.
Additional text information (artist and title)
related to the current broadcast can be
displayed.

Press the
Info
soft key.Two options are available:

Storing using the number keys
(page 79).

Storing using the Presets menu
(page 80).
Storing via number keys

Press and hold a number key between

and  for more than 2 seconds.
The currently selected station is stored
in the corresponding preset location.
Obtaining additional text
information
Storing stationsiWhen storing a station out of the cate-
gory
All
, later selection of this channel
does not lead into the category mode.

80 Satellite radio*Satellite radio operationStoring via Presets menu
Press the
Presets
soft key.
The Preset list appears.

Use or  to select a preset loca-
tion.

Press for more than 2 seconds.
The currently selected station is stored
in the corresponding preset location.Resetting Presets menu
The
Presets
soft key is active indicated by
its color changed.

Press the
Presets
soft key.
All channels in the Preset list are delet-
ed.

Press the
Service
soft key.The telephone number of the Sirius
Service Center and the twelve-digit
electronic serial number (ESN) of the
particular receiver appear.
It may be necessary to call the Sirius Ser-
vice Center if, for example:

you want to cancel the subscription or
to re-subscribe at a later date,

you forget to pay the bill, or

you sell the car to another person.
Calling the Sirius Service Center

162 SystemSystem settings
Press.
The System menu appears.
Selectable soft keys

Time
soft key
For setting the date and time.

Lang.
soft key
For setting the language (
page 164).

Tones
soft key
For switching confirmation beeps
and acoustic signals ON and OFF
(
page 165).

Display
soft key
For changing the display settings
(
page 165).

VC tips
soft key
To call up the Voice control settings*
(
page 166).

Reset
soft key
For reversing COMAND to the factory
settings (
page 169).

In the System menu, press the
Time
soft
key.
The Date/Time settings menu appears.
The following options are now available:

Setting the time

Setting the date

Setting the date/time format
Calling up the System menu
Setting the date/time
