2005 MERCEDES-BENZ C WAGON height

36 Getting startedAdjustingManual seat adjustment
1Seat fore and aft adjustment
2Seat cushion tilt
3Seat backrest tilt
4Seat heightSeat fore and aft adjustment

Lift handle1.

Slide seat to the desired position.

Allow handle1 to reengage.

Check for proper engagement before
driving.
Adjust seat to a comfortable seating
position that still allows you to reach the
accelerator/brake pedal safely. The posi-
tion should be as far rearward as possible,
consistent with ability to properly operate
controls.Seat cushion tilt

Turn handwheel2 forward or back-
ward until your upper legs are lightly
supported
Seat backrest tilt

Switch on ignition (
page 33).

Press switch3 in direction of arrow
until your arms are slightly angled
when holding the steering wheel.
Seat height

Switch on ignition (
page 33).

Press switch4 in direction of arrow
until your legs are lightly supported.
A child’s risk of serious or fatal injuries is
significantly increased if the child restraints
are not properly secured in the vehicle and
the child is not properly secured in the child
restraint.
!When moving the seat, make sure that
there are no items in the footwell or
behind the seat. Otherwise you could
damage the seat.


37 Getting started
Adjusting
Head restraint height
1Release button
Raising:
Manually adjust the height of the head
restraint by pulling it upward.
Lowering:

To lower head the restraint, push
release button1 and push down on
the head restraint.Head restraint tilt
Manually adjust the angle of the head
restraint.

Push or pull on the lower edge of the
head restraint cushion.
For more information, see “Seats”
(
page 97).
Warning!
G
For your protection, drive only with properly
positioned head restraints.
Adjust head restraint so that the center of
the head restraint supports the back of the
head at eye level. This will reduce the poten-
tial for injury to the head and neck in the
event of an accident or similar situation.
Do not drive the vehicle without the seat
head restraints. Head restraints are intend-
ed to help reduce injuries during an acci-
dent.iAdjust the head restraint in such a way
that it is as close to the head as
possible.

38 Getting startedAdjustingPower seat* adjustment
The seat adjustment switches are located
in each front door.
1Head restraint height
2Seat height
3Seat cushion tilt
4Seat fore and aft adjustment
5Seat backrest tilt
Switch on ignition (
page 33).
or

Open the respective door.Seat fore and aft adjustment

Press switch forward or backward in
direction of arrow4.
Adjust seat to a comfortable seating
position that still allows you to reach the
accelerator/brake pedal safely. The posi-
tion should be as far rearward as possible,
consistent with ability to properly operate
controls.Seat cushion tilt

Press switch up or down in direction of
arrow3 until your upper legs are
lightly supported.
Seat backrest tilt

Press switch forward or backward in
direction of arrow5 until your arms
are slightly angled when holding the
steering wheel.
Seat height

Press switch up or down in direction of
arrow2.
Head restraint height

Press switch up or down in direction of
arrow1.
!When moving the seat, make sure that
there are no items in the footwell or
behind the seat. Otherwise you could
damage the seat.iThe memory function* (
page 105)
lets you store the setting for the seat
position together with the settings for
the steering wheel and exterior rear
view mirrors.
iAdjust the head restraint in such a way
that it is as close to the head as
possible.

45 Getting started
Driving

If necessary, tighten the lap portion to
a snug fit by pulling shoulder portion
up.
Seat belt height adjustment
Adjust seat belt so that shoulder portion is
located as close as possible to the middle
of your shoulder (it should not touch the
neck or pass under the arm).
Front seats
4Button for belt outlet height adjust-
ment

Press button4 and slide belt outlet
upward or downward.Rear outer seats
5Button for belt outlet height adjust-
ment

Press button5 and slide belt outlet
upward or downward.Proper use of seat belts


Do not twist the belt when fastening.


Adjust seat belt so that the shoulder
portion is located as close as possible
to the middle of the shoulder (it should
not touch the neck). Never pass the
shoulder portion of the belt under your
arm. For this purpose, you can adjust
the height of the belt outlet.


Position the lap belt as low as possible
on your hips (over hip joint) and not
across the abdomen.


Place the seat backrest in a nearly up-
right position.


Never use a seat belt for more than one
person at time.


Do not fasten a seat belt around a
person and another object at the same
time. When using a seat belt to secure
infant or toddler restraints or children
in booster seats, always follow the
child seat manufacturer's instructions.

71 Safety and Security
Occupant safety
A statement by the child restraint man-
ufacturer of compliance with this stan-
dard can be found on the instruction
label on the restraint and in the
instruction manual provided with the
restraint.
When using any infant or child restraint
system, be sure to carefully read and
follow all manufacturer’s instructions
for installation and use.
Please read and observe warning labels
affixed to inside of vehicle and to infant
or child restraints.
Warning!
G
Children 12 years old and under must never
ride in the front seat, except in a
Mercedes-Benz authorized BabySmart
TM1

compatible child seat, which operates with
the BabySmart
TM system installed in the ve-
hicle to deactivate the passenger front
air bag when it is properly installed. Other-
wise they will be struck by the air bag when
it inflates in a crash. If this happens, serious
or fatal injury will result.
According to accident statistics, children
are safer when properly restrained in the
rear seating positions than in the front seat-
ing positions. Infants and small children
must ride in back seats and be seated in an
appropriate infant or child restraint system,
which is properly secured with the vehicle’s
seat belt and top tether strap, or secured via
lower anchors and top tether strap, fully in
accordance with the child seat manufactur-
er’s instructions.
1BabySmart
TM is a trademark of Siemens
Automotive Corp.
Infants and small children should never
share a seat belt with another occupant.
During an accident, they could be crushed
between the occupant and seat belt.
A child’s risk of serious or fatal injuries is
significantly increased if the child restraints
are not properly secured in the vehicle and
the child is not properly secured in the child
restraint.
Children too big for child restraint systems
must ride in back seats using regular seat
belts. Position shoulder belt across chest
and shoulder, not face or neck. A booster
seat may be necessary to achieve proper
belt positioning for children from 41 lbs until
they reach a height where a lap/shoulder
belt fits properly without a booster.
When the child restraint is not in use, re-
move it from the vehicle or secure it with the
seat belt to prevent the child restraint from
becoming a projectile in the event of an ac-
cident.


76 Safety and SecurityOccupant safetyTo fold anchors back
Press down button2 on each anchor
and return anchor1 to its catch.iThe child seat must be firmly attached
in the right and left side anchors1.
With a child seat installed in the left
rear seat, the seat belt for the center
seat occupied by a passenger must op-
erate freely. Guide seat belt between
its seat cushion mount and backrest
mount along outside of right side child
seat anchor.iNon-LATCH-type child seats may also
be used and can be installed using the
vehicle’s seat belt system. Install child
seat according to the manufacturer’s
instructions.
Warning!
G
Children too big for child restraint systems
must ride in back seats using regular seat
belts. Position shoulder belt across chest
and shoulder, not face or neck. A booster
seat may be necessary to achieve proper
belt positioning for children from 41 lbs until
they reach a height where a lap/shoulder
belt fits properly without a booster.
Before installing the child seat, make sure
anchors1 are folded out and locked in
place.
Install child seat according to manufactur-
er’s instructions.
T h e c h i l d s e a t m u s t b e f i r m l y a t t a c h e d i n t h e
right and left side anchors1.
An incorrectly mounted child seat may come
loose during an accident which could result
in serious injury or death to your child.
Damaged or impact damaged child seats or
child seat anchors1 must be replaced.
Do not leave children unattended in the
vehicle, even if the children are secured in a
child restraint system.

94 Controls in detailLocking and unlockingRear doors
Pull up locking knob1 on the
respective rear door to unlock door.

Pull on door handle2 on the
respective rear door to open door.
Opening the tailgate
A minimum height clearance of 6.40 ft
(1.95 m) is required to open the tailgate.
The handle is located above the rear
license plate recess.
1Handle
The vehicle must be unlocked.
Pull on handle1.

Lift the tailgate.
Closing the tailgate
1Handle
Lower tailgate by pulling firmly on
handle1.

Close tailgate with hands placed flat on
it.
iIf the vehicle has previously been
locked from the outside with the
SmartKey, opening a door from the
inside will trigger the anti-theft alarm
system*.
To cancel the alarm, do one of the
following:

Press buttonŒ or‹ on the
SmartKey.


Insert the SmartKey in the starter
switch.
!Always make sure there is sufficient
overhead clearance.

100 Controls in detailSeatsFront seat head restraints, power seat*
1Head restraint switch
Switch on ignition (
page 33).
Removing front seat head restraints

Press switch1 upwards and hold until
head restraint is fully extended.

Pull out head restraint.Installing front seat head restraints

Press switch1 upwards and hold for
about five seconds.

Push head restraint down until it
engages.

Adjust head restraint to desired
position (
page 38).
Rear seat head restraintsHead restraint height (rear outer seats)
1Release button
Raising:

Manually adjust the height of the head
restraint by pulling it upward.
If the head restraint is fully retracted,
push release button1 and pull the
head restraint out.
Lowering:

To lower the head restraint, push
release button1 and push down on
the head restraint.
Warning!
G
For safety reasons, always drive with the
rear head restraints in the upright position
when the rear seats are occupied.
Keep the area around head restraints clear
of articles (e.g. clothing) to not obstruct the
folding operation of the head restraints.
