Mode selector dial
Turn the mode selector dial to select
airflow mode (page 6-4).
A/C switchí
Push the switch to turn the air conditioner
on. The indicator light on the switch will
illuminate when the fan control dial is set
at position 1, 2, 3, or 4.
Push the switch once again to turn the air
conditioner off.
NOTE
The air conditioner may not function
when the outside temperature
approaches 0 °C (32 °F).
Air intake selector
This lever controls the source of air
entering the vehicle.
It is recommended that under normal
conditions the lever be kept in the outside
air position.
Outside air position (
)
Outside air is taken into the vehicle. Use
this position for normal ventilation and
heating.
Recirculated air position (
)
Outside air is shut off. Air within the
vehicle is recirculated.
This position can be used when driving on
a dusty road or in similar conditions. It
also helps to provide quicker cooling of
the interior.
WARNING
The Recirculated Air Position:
Using the
position in cold or
rainy weather will cause the windows
to fog up. Your vision will be
hampered, which could lead to a
serious accident. Do not use the
position in cold or rainy weather.
6-6
Interior Comfort
íSome models.
Climate Control System
MX-5 Miata_8T72-EA-04G_Edition2 Page132
Tuesday, August 31 2004 11:24 AM
Form No.8T72-EA-04G

Black plate (136,1)
qRadio Reception
AM characteristics
AM signals bend around such things as
buildings or mountains and bounce off the
ionosphere. Therefore, they can reach
longer distances than FM signals. Because
of this, two stations may sometimes be
picked up on the same frequency at the
same time.
Station 2
Station 1 Ionosphere
FM characteristics
An FM broadcast range is usually about
40
―50 km (25 ―30 miles) from the
source. Because of extra coding needed to
break the sound into two channels, stereo
FM has even less range than monaural
(non-stereo) FM.
(25—30 miles) 40—50 km FM Station
Signals from an FM transmitter are similar
to beams of light because they do not
bend around corners, but they do reflect.
Unlike AM signals, FM signals cannot
travel beyond the horizon. Therefore, FM
stations cannot be received at the great
distances possible with AM reception.
AM wave
FM wave
FM wave
100—200 km (60—120 miles) Ionosphere
Atmospheric conditions can also affect
FM reception. High humidity will cause
poor reception. However, cloudy days
may provide better reception than clear
days.
Multipath noise
Since FM signals can be reflected by
obstructions, it is possible to receive both
the direct signal and the reflected signal at
the same time. This causes a slight delay
in reception and may be heard as a broken
sound or a distortion. This problem may
also be encountered when in close
proximity to the transmitter.
Reflected wave
Direct
6-10
Interior Comfort
Audio System
MX-5 Miata_8T72-EA-04G_Edition2 Page136
Tuesday, August 31 2004 11:24 AM
Form No.8T72-EA-04G

Black plate (138,1)
qOperating Tips for Cassette Tape
Player
Cleaning the cassette tape player
The tape head, capstans, and pinch rollers
will gather oxide residue from cassette
tapes. This can cause weak or wavering
sounds and damage to the cassette tapes
and player. Use a good quality head-
cleaning tape or a liquid cleaner cassette
tape to remove it.
Should the unit not operate normally,
consult an Authorized Mazda Dealer.
Never attempt to repair it or insert a
screwdriver or anything else.
Handling the cassette tape player
The following precautions should be
observed.
lDo not spill any liquid on the audio
system.
lDo not insert any objects, other than
cassette tape, into the slot.
lIf the cassette tape is loose, it may
produce poor sound or performance
during playback. Use a pencil or
something similar to remove any slack.
lOnly cassette tapes that play no longer
than 90 minutes should be used.
Cassette tape exceeding 90 minutes are
thin and may easily break.
lDo not leave a cassette tape in the tape
player slot when not in use. Remove it
completely to permit the slot door to
close and to protect the mechanism
from dust.
lStore cassette tapes away from extreme
heat, magnetic fields, and direct
sunlight. Protect the exposed cassette
tape from dirt and damage. Store
cassette tapes in their original cases or
other protective cases.
6-12
Interior Comfort
Audio System
MX-5 Miata_8T72-EA-04G_Edition2 Page138
Tuesday, August 31 2004 11:24 AM
Form No.8T72-EA-04G

Black plate (139,1)
qOperating Tips for Mini Disc
(MD) Player
The following precautions should be
observed.
lDo not spill any liquid on the audio
system.
lDo not insert any objects, other than
MDs, into the slot.
lThe MD player has been designed to
play MDs bearing the identification
logo as shown. No other MDs can be
played.
lThe MD player can also play MDLPs
that have been recorded in MDLP
mode. (MDLPs bearing the
identification logo as shown below).
lWhen inserting the MD, make sure the
MD label is facing up, and the MD is
oriented to the insertion slot in the
direction of the arrow. If not inserted
correctly, the MD will be ejected, or
may remain stuck in the MD deck.
lDo not touch the internal part of the
MD. If the MD shutter is slid open for
no reason, it may be broken.
lStore MDs in their cases and away
from direct sunlight.
Interior Comfort
Audio System
6-13
MX-5 Miata_8T72-EA-04G_Edition2 Page139
Tuesday, August 31 2004 11:24 AM
Form No.8T72-EA-04G

Black plate (141,1)
lWhen driving over uneven surfaces,
the sound may jump.
lThe CD player/changer has been
designed to play CDs bearing the
identification logo as shown. No other
discs can be played.
lBe sure never to touch the signal
surface when handling the CDs. Pick
up a CD by grasping the outer edge or
the edge of the hole and the outer edge.
lDo not stick paper or tape on the CD.
Avoid scratching the reverse side (the
side without a label).
lDust, finger smudges, and dirt can
decrease the amount of light reflected
from the signal surface, thus affecting
sound quality. If the CD should
become soiled, gently wipe it with a
soft cloth from the center of the CD to
the edge.
lDo not use record sprays, antistatic
agents, or household spray cleaners.
Volatile chemicals such as benzine and
thinner can also damage the surface of
the CD and must not be used. Anything
that can damage, warp, or fog plastic
should never be used to clean CDs.
lCDs, like traditional audio records, are
made of plastic. To avoid warping,
keep the CDs in their cases and do not
store them where they will be exposed
to direct sunlight.
lThe CD player/changer ejects the CD if
the CD is inserted upside down. Also
dirty and/or defective CDs may be
ejected.
l8 cm (3 in) CDs and CD accessories
(e.g. 8 cm disc adapter) cannot be used
in the CD player/changer.
lDo not insert cleaning discs in the CD
player/changer.
lDo not insert any disc with a peel-off
or seal on it.
Interior Comfort
Audio System
6-15
MX-5 Miata_8T72-EA-04G_Edition2 Page141
Tuesday, August 31 2004 11:24 AM
Form No.8T72-EA-04G

Black plate (170,1)
qAntitheft Systemí
Display
Channel preset buttons
Antitheft indicator light
Auto memory
button
To deter theft of your vehicle's audio unit,
it has an integrated antitheft system. The
system is designed to accept a code
number that makes the unit inoperable if it
is stolen.
This system will be activated if the power
source is ever disconnected from or in any
way interrupted to the audio unit. When
the system is activated, the audio system
will not operate when reconnected to a
power supply, and “CODE ”will flash on
the display until the correct code number
is input. If the antitheft system is
activated, reset the unit.CAUTION
Read and understand all code setting
procedures before attempting to input
your personal code number.
The personal code number is only
shown on the audio unit display while it
is being set. Once it is input and stored
by the unit, it is never again displayed.
For that reason, be very careful to
immediately record your personal code
number, and never let an unauthorized
person set a code.
NOTE
Although the audio unit is operable
without the code number being set, we
recommend that you set your personal
code number.
6-44
Interior Comfort
íSome models.
Audio System
MX-5 Miata_8T72-EA-04G_Edition2 Page170
Tuesday, August 31 2004 11:24 AM
Form No.8T72-EA-04G

Black plate (193,1)
Sunvisors
When you need a sunvisor, lower it for
use in front or swing it to the side.
qVanity Mirror
To use the vanity mirror, lower the
sunvisor.
Interior Light
qOverhead Light
Center position
Switch
Position Overhead Lights
Light off
Center Light on when any door is open
Light on
Interior Comfort
Interior Equipment
6-67
MX-5 Miata_8T72-EA-04G_Edition2 Page193
Tuesday, August 31 2004 11:24 AM
Form No.8T72-EA-04G

Black plate (194,1)
Lighter
The ignition switch must be in the ACC
or ON position.
Press the lighter in and release it. When
ready for use, it automatically pops out.
CAUTION
lDon't touch the metal part of the
lighter, you may burn yourself.
lDon't hold the lighter in because it
will overheat.
lDon't use the lighter socket for plug-
in accessories such as shavers and
coffee pots. They may damage it or
cause electrical failure. Use only a
genuine Mazda lighter or the
equivalent.
lIf the lighter doesn't pop out within
30 seconds, remove it to prevent
overheating.
Ashtray
CAUTION
Don't use the ashtray for trash. You
might start a fire.
To remove, open and pull up the ashtray.
