GAUGES, METERS AND SERVICE REMINDER INDICATORS
102
w279
Dynamic radar cruise control—
If the system cannot easily measure the
vehicletovehicle distance because of a dirty millimeter
wave radar sensor or grille cover while the dynamic radar
cruise control is on, the master warning light comes on
and the “CRUISE” indicator light flashes. At this time a
warning tone sounds and the above message appears.
If this message appears, clean the sensor and grille cover with
a soft cloth and try setting the preset speed again. If the dirt
is removed without cleaning, the system will automatically
enter the “RADAR READY” mode. If the system does not enter
the “RADAR READY” mode even after cleaning or the
message remains on the display, the system might be
malfunctioning. Although it is no problem to continue driving,
contact your Lexus dealer. Dynamic laser cruise control—
If the system cannot easily measure the
vehicletovehicle
distance because of a dirty laser radar
sensor glass while the dynamic laser cruise control is on,
the master warning light comes on and the “CRUISE”
indicator light flashes. At this time a warning tone sounds
and the above message appears.
If this message appears, clean the sensor glass with a soft
cloth and try setting the preset speed again. If the dirt is
removed without cleaning, the system will automatically enter
the “RADAR READY” mode. If the system does not enter the
“RADAR READY” mode even after cleaning or the message
remains on the display, the system might be malfunctioning.
Although it is no problem to continue driving, contact your
Lexus dealer.

GAUGES, METERS AND SERVICE REMINDER INDICATORS
103
w280
If the system cannot easily measure the
vehicletovehicle distance because of the following
conditions while the dynamic radar/laser cruise control is
on, the master warning light comes on, the “CRUISE”
indicator light flashes, and a warning tone sounds. At this
time the above message appears.
Dynamic radar cruise control—
 The driving pattern selector switch is set to the “SNOW”
mode.
 It is determined that it is difficult to make a measurement
because of bad weather (such as extremely hot weather)
 The wipers are operated at high speed with the wiper lever
in the “AUTO” position
Dynamic laser cruise control—
 The driving pattern selector switch is set to the “SNOW”
mode.
 It is determined that it is difficult to make a measurement
because of bad weather (such as rainy, foggy, or snowy
weather)
 The wipers are operated at high or low speeds with the
wiper lever in the “AUTO” position.
 Direct sunlight from the front In the following
cases, the dynamic radar/laser cruise
control switches to the “RADAR READY” mode:
Dynamic radar cruise control—
 The driving pattern selector switch is changed to the
“normal” or “power” position.
 The wipers are stopped or are switched to low speed or
intermittent operation. (Including intermittent and stopped
wipers in the “AUTO” position)
In the above conditions, press the control lever upward in the
“RES/ACC” direction and release it. The dynamic radar cruise
control will be restored, however, even after the weather
clears, if the setting operation cannot be performed or if the
warning message still appears, the system might have
malfunctioned. Although it is no problem to continue driving,
contact your Lexus dealer.

GAUGES, METERS AND SERVICE REMINDER INDICATORS
104Dynamic laser cruise control—

The driving pattern selector switch is changed to the
“normal” or “power” position.
 The wipers are stopped or are switched to intermittent
operation. (Including intermittent and stopped wipers in the
“AUTO” position)
 No direct sunlight from the front
In the above conditions, press the control lever upward in the
“RES/ACC” direction and release it. The dynamic laser cruise
control will be restored, however, even after the weather
clears, if the setting operation cannot be performed or if the
warning message still appears, the system might have
malfunctioned. Although it is no problem to continue driving,
contact your Lexus dealer.
w281
If a system malfunction is detected when dynamic
radar/laser cruise control is in the “RADAR READY” mode
or operating, the master warning light comes on, the
“CRUISE” indicator light flashes and a warning tone
sounds. At this time the above message appears.
If this message appears, stop your vehicle in a safe place, turn
the ignition off, and then restart it to reset the system. If the
setting still cannot be made or the same message appears
again, the system might have malfunctioned. Although it is no
problem to continue driving, contact your Lexus dealer.
NOTICE
While you are cruising with the dynamic radar/laser
cruise control on, if the master warning light comes on,
the cruise indicator light flashes, “Check Cruise
System” appears on the multiinformation display and
the warning tone sounds, turn the ignition switch off
and then on again. If the function is cancelled again
after setting or if settings cannot be made, the dynamic
radar/laser cruise control system may be
malfunctioning. Although it is no problem to continue
driving, have your vehicle checked by your Lexus
dealer.

GAUGES, METERS AND SERVICE REMINDER INDICATORS
105
w278
The master warning light comes on, a warning tone
sounds and the above message appears in the following
conditions:
The millimeter wave radar sensor or the grille cover is
dirty.
Clean the grille or sensor with a soft cloth to remove the dirt.
 The precollision seat belts are activated repeatedly for
a short time.
The system turns of f temporarily for overheating protection,
but turns back on after a while.
w277
If there is a problem somewhere in the precollision safety
system, the master warning light comes on, a warning
tone sounds, and the above message appears.
If the above message appears, the pre −collision safety system
may not operate. Contact your Lexus dealer as soon as
possible to service the vehicle.
COMPASS
(Vehicles without Navigation System)
13L149
When the ignition is turned on, the previously selected display
appears. If the compass is not displayed, push the “DISP2”
button several times for 1 to 2 seconds to display the compass.
However if you push the main switch of dynamic radar/laser
cruise control to use dynamic radar/laser cruise control, the
dynamic radar/laser cruise control display appears. To change
to the compass display, push the “DISP2” button for longer
than about 1 second.
The compass indicates the direction in which the vehicle
is heading. The illustration shown above indicates that the
vehicle is heading north.

GAUGES, METERS AND SERVICE REMINDER INDICATORS
106Displays
Directions
N
NE
E
SE S
SW W
NWNorth
Northeast
East
Southeast South
Southwest West
Northwest
The compass may not show the correct direction in the
following conditions:
 The vehicle is stopped immediately after turning.
The compass does not adjust while the vehicle is stopped.
 The ignition switch is turned off immediately after turning.
 The vehicle is on an inclined surface.
 The vehicle is in a place where the earth’s magnetic field is
subject to interference by artificial magnetic fields
(underground parking, under a steel tower, between
buildings, roof parking, near a crossing, near a large
vehicle, etc.).
The vehicle is magnetized. (There is a magnet or a metal
object near the audio system.)
 The battery has been disconnected.
If the deviation is small, the compass works to calibrate the
direction automatically while the vehicle is in motion.
For obtaining additional precision or for complete calibrating,
see “CALIBRATING THE COMPASS” on page 107.
COMPASS SENSOR
13L072
 Compass sensor
The compass sensor is located behind the audio system.

GAUGES, METERS AND SERVICE REMINDER INDICATORS
107
NOTICE
Do not put magnets or a metal object near the audio
system. Doing this may cause malfunction of the
compass sensor.
CALIBRATING THE COMPASS
The direction display on the compass deviates from the true
direction determined by the earth’s magnetic field. The
amount of deviation varies according to the geographic
position of the vehicle.
If you cross over the area divided as shown in the illustration,
the compass will deviate. If it is necessary to calibrate the
compass (deviation calibration), take your vehicle to your
Lexus dealer. Even if you do not cross over, the compass may
sometimes deviate. If this happens, perform “DRIVE IN
CIRCLES” calibration as shown on the next page.
13L196

GAUGES, METERS AND SERVICE REMINDER INDICATORS
108
13L150
To rectify the deviation, stop the vehicle, and push and hold the
“RESET” button on the steering pad for more than 6 seconds.
“DRIVE IN CIRCLES” appears on the display. Perform the
following calibration.
CAUTION
Do not adjust the display while the vehicle is moving.
Be sure to adjust the display only when the vehicle is
stopped.
13L155
Drive the vehicle slowly (at 8 km/h (5 mph) or lower) in a circle
until the direction is displayed. If there is not enough space to
drive in a circle, drive around the block until the direction is
displayed.
After driving in 1 to 3 circles in the above method, calibration
is complete with the direction shown on the display.
If calibration cannot be performed because the vehicle is
magnetized, take your vehicle to a Lexus dealer.
If you want to cancel the calibration before it is complete, push
and hold the “RESET” button on the steering pad more than 6
seconds. To calibrate the compass again, push and hold the
same but ton more than 6 seconds. After “DRIVE IN CIRCLES”
appears on the display, follow the calibration procedure above.
Perform circling calibration just after you have purchased
your Lexus. And then always perform circling calibration
after the battery has been removed, replaced or
disconnected.

GAUGES, METERS AND SERVICE REMINDER INDICATORS
109

Do not perform circling calibration of the compass in a place
where the earth’s magnetic field is subject to interference by
artificial magnetic fields (underground parking, under a
steel tower, between buildings, roof parking, near a
crossing, near a large vehicle, etc.).
 During calibration, do not operate electric systems (moon
roof, power windows, etc.) as they may interfere with the
calibration.
CAUTION
When doing the circling calibration, be sure to secure
a wide space, and watch out for people and vehicles
in the neighborhood. Do not violate any local traffic
rules while performing circling calibration.
 Do not adjust the display while the vehicle is moving.
Be sure to adjust the display only when the vehicle is
stopped.
INSTRUMENT PANEL LIGHT
CONTROL
13L143a
To adjust the brightness of the instrument panel lights,
turn the knob.
With the knob turned fully right, the intensity of the instrument
panel lights will not be reduced when the headlight switch is on.
