AIR CONDITIONING
193
(e) Checking and replacing the air conditioningfilter
The air conditioning filter information label is placed in the
glove box as shown and indicates that a filter has been
installed.
The air conditioning filter prevents dust from entering the
vehicle through the air conditioning vent.
The air conditioning filter is behind the glove box.
The air conditioning filter may clog after long use. The filter
may need to be replaced if the air flow of the air conditioner and
heater experiences extreme reductions in operating ef ficiency,
or if the windows begin to fog up easily.
To maintain the air conditioning efficiency, inspect and replace
the air conditioning filter according to the maintenance
schedule. In dusty areas or areas with heavy traffic flow, such
as inner city or desert areas, early replacement may be
required. (For scheduled maintenance information, please
refer to the “Owner’s Manual Supplement/Scheduled
Maintenance”.)

AIR CONDITIONING
194
1. Open the glove box. Remove the screw with a
Phillipshead screwdriver.
2. Remove the 2 pins installed on the upper part of the
glove box and lower the glove box.
3. Take out the filter case.
4. Remove the filter from the filter case.
5. Inspect the filter on the surface.
If it is dirty, it should be replaced.

AIR CONDITIONING
195
INFORMATION
The air conditioning filter should be installed properly
in position. The use of air conditioning with the filter
removed may cause deteriorated dustproof
performance and then affect air conditioning
performance.

62Z002
Outside temperature
ENGINE
345
— LUBRICATION SYSTEM
Oil capacity Drain and refillWith filter
Without filter
4.7 L (5.0 qt., 4.1 Imp. qt.)
4.5 L (4.8 qt., 4.0 Imp. qt.)
Oil gradeAPI grade SL “Energy− Conserving” or ILSAC multigrade engine oil
Recommended oil viscosity (SAE):
NOTE:
“Toyota Genuine Motor Oil” is used in your Lexus vehicle. Use Lexus approved “T oyota Genuine Motor Oil” or equivalent to satisfy
the above grade and viscosity. Please contact your Lexus dealer for further details.

ENGINE
351
USED ENGINE OIL
CAUTION
Used engine oil contains potentially harmful
contaminants which may cause skin disorders such
as inflammation or skin cancer, so care should be
taken to avoid prolonged and repeated contact with
it. To remove used engine oil from your skin, wash
thoroughly with soap and water.
 Do not leave used oil within the reach of children.
 Dispose of used oil and used oil filters only in a safe
and acceptable manner. Do not dispose of used oil
and used oil filters in household trash, in sewers or
onto the ground. Call your Lexus dealer or a service
station for information concerning recycling or
disposal.
CHECKING THE ENGINE OIL LEVEL
With the engine at operating temperature and turned off,
check the oil level on the dipstick.
1. To get a correct reading, the vehicle should be on level
ground. After turning off the engine, wait a few minutes for the
oil to drain back into the bottom of the engine.
2. Pull the dipstick out, hold a rag under the end and wipe it
clean.
3. Reinsert the dipstick and push it in as far as it will go, or the
reading will not be correct.

BODY
413
Fuel
filler door: Do not apply water (high −pressure car wash,
for example) at or near the fuel tank inlet with the fuel filler door
opened. If the water enters the air vent, you may experience
trouble with refueling or rough engine idling.
Plastic wheel ornaments: The plastic wheel ornaments are
damaged easily by organic substances. If any organic
substances splashes an ornament, be sure to wash it off with
water and check if the ornament is damaged.
CAUTION
Do not attach the heavily damaged plastic wheel
ornament. It may fly off the wheel and cause accidents
while the vehicle is moving.
Aluminum wheels: Use only a mild soap or neutral detergent.
Urethane bumpers and side moldings: Wash carefully. Do
not scrub with abrasive cleaners. The bumper and side
molding faces are soft.
Road tar: Remove with turpentine or cleaners that are marked
safe for painted surfaces.
NOTICE
Do not use organic substances (gasoline, kerosene,
benzine or strong solvents), which may be toxic or
cause damage.
3. Rinse thoroughly — dried soap can cause streaking. In hot
weather you may need to rinse each section right after you
wash it.
4. To prevent water spots, dry the vehicle using a clean soft
cotton towel. Do not rub or press hard — you might scratch the
paint.
Automatic car wash
Your vehicle may be washed in an automatic car wash, but
remember that the paint can be scratched by some types of
brushes, unfiltered washing water, or the washing process
itself. Scratching reduces paint durability and gloss, especially
on darker colors. The manager of the car wash should be able
to advise you whether the process is safe for the paint on your
vehicle.
Waxing your Lexus
Polishing and waxing is recommended to maintain the
original beauty of your Lexus’ finish.
Apply wax once a month or if the vehicle surface does not repel
water well.
1. Always wash and dry the vehicle before you begin waxing,
even if you are using a combined cleaner and wax.
2. Use a good quality polish and wax. If the finish has become
extremely weathered, use a car −cleaning polish, followed by
a separate wax. Carefully follow the manufacturer’s
instructions and precautions. Be sure to polish and wax the
chrome trim as well as the paint.

GAS STATION INFORMATION
Fuel selection:
Select unleaded gasoline with an Octane Rating of 87
(Research Octane Number 91) or higher. For improved
vehicle performance, the use of premium unleaded
gasoline with an Octane Rating of 91 (Research Octane
Number 96) or higher is recommended.
 Fuel tank capacity:
70 L (18.5 gal., 15.4 Imp. gal.)
 Engine oil:
“Toyota Genuine Motor Oil” or equivalent
Oil grade: API grade SL “Energy −Conserving” or ILSAC
multigrade engine oil
Recommended oil viscosity: SAE 5W −30
Oil capacity: L (qt., Imp. qt.)
Drain and refill With filter 4.7 (5.0, 4.1)
Without filter 4.5 (4.8, 4.0)
See page 351 for detailed information.
 Engine coolant:
Capacity: 9.2 L (9.7 qt., 8.2 Imp. qt.)
Coolant type — “T oyota Super Long Life Coolant” or similar
high quality ethylene glycol based non −silicate, non −amine,
non−nitrite, and non −borate coolant with long −life hybrid
organic acid technology (Coolant with long −life hybrid
organic acid technology is a combination of low phosphates
and organic acids.)
Do not use plain water alone.
For checking the engine coolant, see page 355 .
Automatic transaxle:
Fluid type — Toyota Genuine ATF Type T −IV
See page 360 for detailed information.
 Tire information:
See pages 366 through 386 for detailed information.
 Tire inflation pressure:
cold tires
kPa (kgf/cm
2 or bar, psi)
Tire size: P215/60R16 94V
Front tires 200 (2.0, 29) . . . . . . . . .
Rear tires 200 (2.0, 29) . . . . . . . . .
For sustained high speeds above 160 km/h (99 mph), in
countries where such speeds are permitted by law, add 40
kPa (0.4 kgf/cm
2 or bar, 6 psi) to the front tires and rear tires,
but never exceed the maximum cold tire inflation pressure
molded on the tire sidewall.
Tire size: P215/55R17 93V
Front tires 210 (2.1, 30)
. . . . . . . . .
Rear tires 210 (2.1, 30)
. . . . . . . . .
For sustained high speeds above 160 km/h (99 mph), in
countries where such speeds are permitted by law, add 30
kPa (0.3 kgf/cm
2 or bar, 4 psi) to the front tires and rear tires,
but never exceed the maximum cold tire inflation pressure
molded on the tire sidewall.
See page 362 or 363 for detailed information.
