UNDERSTANDING YOUR INSTRUMENT PANEL
CONTENTS

Instrument Panel And Interior Controls.......141

Instrument Cluster......................142

Instrument Cluster Description.............143

Electronic Digital Clock..................148
▫Clock Setting Procedure.................148

Radio General Information................149
▫Radio Broadcast Signals.................149
▫Two Types Of Signals..................149
▫Electrical Disturbances..................149▫AM Reception.......................149
▫FM Reception........................149

Sales Code RBK—AM/ FM Stereo Radio With
CD Player And CD Changer Controls........150
▫Radio Operation......................150
▫CD Player Operation...................152
▫CD Changer Control Capability — If
Equipped...........................154

Sales Code RBQ—AM/FM Stereo Radio With
6 - Disc CD Changer....................1564

23. Fuel Cap Indicator
This symbol indicates the side of the vehicle
where the fuel cap is located.
24. Fuel Gauge
The pointer shows the level of fuel in the fuel tank. When
the fuel gauge pointer initially moves to E, for your
safety, approximately 2 U.S. Gallons (7.6L) of fuel remain.
NOTE:When the ignition switch is turned to OFF, the
fuel gauge, voltmeter, oil pressure and temperature
gauges may not show accurate readings. When the
engine is not running, turn the ignition switch to ON to
obtain accurate readings.ELECTRONIC DIGITAL CLOCK
The clock and radio each use the display panel built into
the radio. A digital readout shows the time in hours and
minutes whenever the ignition switch is in the ON or
ACC position and the time button is pressed.
When the ignition switch is in the OFF position, or when
the radio frequency is being displayed, time keeping is
accurately maintained.
Clock Setting Procedure
1. Turn the ignition switch to the ON or ACC position
and press the time button. Using the tip of a ballpoint pen
or similar object, press either the hour (H) or minute (M)
buttons on the radio.
2. Press the H button to set hours or the M button to set
minutes. The time setting will increase each time you
press a button.
148 UNDERSTANDING YOUR INSTRUMENT PANEL

Blower Switch
The blower switch is the rotary knob to the left of the
controls. The blower speed will increase as the knob
is turned clockwise. There are four blower speeds.
NOTE:The blower motor will run until the mode
control knob is turned to the “Off” (“O”) position or the
ignition is turned OFF.
Temperature Control
The temperature control is the center knob located on the
climate controls. It controls the temperature of the air
delivered to the passenger compartment.
You can choose your degree of comfort by rotating the
knob. The coldest setting is to the extreme left (blue
region) and the warmest setting is to the extreme right
(red region).
Mode Selection
The mode selector is the right knob located on the climate
controls. It can be set in any of the following positions:
Off
This position turns off the blower motor. In this
mode, there may be some slight air flow from the
floor outlets, side window outlets, and defrost outlet
located at the base of the windshield.
Panel
Outside air comes from the outlets in the instrument
panel. Each of these outlets can be individually
adjusted to direct the flow of air. Also, a slight amount of
airflow may be noticed at the defrost outlet located at the
base of the windshield.
170 UNDERSTANDING YOUR INSTRUMENT PANEL

Spare Tire Stowage
To remove the spare tire from the carrier, remove the tire
cover, if equipped, and remove the lug nuts with the lug
wrench turning them counterclockwise.NOTE:If you have added aftermarket accessories to the
spare tire mounted carrier, it cannot exceed a gross
weight of 50 lbs (23 kg) including the weight of the spare
tire.
Preparations For Jacking
Park on a firm level surface, avoid ice or slippery areas,
set the parking brakeand place automatic transmission
in P (Park), or manual transmission in R (Reverse). Turn
OFF the ignition.
WARNING!
Do not attempt to change a tire on the side of the
vehicle close to moving traffic. Pull far enough off
the road to avoid being hit when operating the jack
or changing the wheel.
•Turn on the Hazard Warning Flasher.
Jack Storage Location
WHAT TO DO IN EMERGENCIES 239
6
