The security system helps to protect
your vehicle and valuables f rom thef t.
The horn sounds and a combination
of headlights, parking lights, side
marker lights, and taillights f lash if
someone attempts to break into your
vehicle. This alarm continues for two
minutes, then the system resets. To
reset an alarm system bef ore the two
minutes have elapsed, unlock the
driver’s f ront door with the key or
the remote transmitter.Once the security system is set,
opening any door without using the
key or the remote transmitter, or the
hood, will cause it to alarm. It also
alarms if the radio is removed from
the dashboard or the wiring is cut.The security system will not set if
the hood, the tailgate, or any door is
not f ully closed. If the system will not
set, check the Door and Tailgate
Open Monitor on the instrument
panel (see page ) to see if the
doors and the tailgate are f ully
closed. Since it is not part of the
monitor display, manually check the
hood.
Do not attempt to alter this system
or add other devices to it.
The security system automatically
sets 15 seconds after you lock the
doors, hood, and the tailgate. For the
system to activate, you must lock the
doors f rom the outside with the key,
lock tab, door lock switch, or remote
transmitter. The security system
indicator next to the driver’s door
lock starts blinking immediately to
show you the system is setting itself . 62
On EX and EX-L models
Security System
Features
137
SECURITY SYSTEM INDICATOR

Your dealer has Honda accessories
that allow you to personalize your
vehicle. These accessories have
been designed and approved f or your
vehicle, and are covered by warranty.When properly installed, cellular
phones, alarms, two-way radios, and
low-powered audio systems should
not interf ere with your vehicle’s
computer controlled systems, such
as your airbags and anti-lock brakes.Bef ore installing any accessory:
Make sure the accessory does not
obscure any lights, or interf ere
with proper vehicle operation or
perf ormance.
Be sure electronic accessories do
not overload electrical circuits
(see page ) or interf ere with
proper operation.
Modif ying your vehicle, or installing
some non-Honda accessories, can
make your vehicle unsaf e. Bef ore
you make any modif ications or add
anyaccessories,besuretoreadthe
f ollowing inf ormation.
Bef ore installing any electronic
accessory, have the installer
contact your dealer for assistance.
If possible, have your dealer
inspect the f inal installation.
Although non-Honda accessories
may f it on your vehicle, they may not
meet f actory specif ications, and
could adversely af f ect your vehicle’s
handling and stability. (See
‘‘Modif ications’’ on page f or
additional information.) 152 241
A ccessories
A ccessories and Modif ications
Bef ore Driving
151
Improper accessories or
modifications can affect your
vehicle’s handling, stability, and
performance, and cause a
crash in which you can be hurt
or killed.
Follow all instructions in this
owner’s manual regarding
accessories and modifications.

Your vehicle can be towed behind a
motorhome at legal highway speeds
up to 65 mph (100 km/h). Do not
exceed 65 mph (100 km/h) or severe
transmission damage will occur. To
avoid damage to the 4WD system, it
must be towed with all f our wheels
on the ground (f lat towing).
When purchasing a tow bar, make
sure you select a reputable
manuf acturer. Follow the
manufacturer’s attachment
instructions caref ully.
Perf orm the f ollowing procedure
everyday immediately bef ore you
begin towing. Otherwise severe
automatic transmission damage will
occur.Check the transmission f luid level
(see page ).
Start the engine. Press on the brake pedal. Move
the shif t lever through all its
positions.
ShifttoD,thentoN.Letthe
engine run f or three minutes, then
turn it off.
Release the parking brake.
Leave the ignition switch in the
ACCESSORY (I) position so the
steering wheel does not lock.
Make sure the radio and any
items plugged into the
accessory power sockets are
turned of f so you do not run
down the battery.
If you tow more than 8 hours in one
day, you should repeat the above
procedure at least every 8 hours
(when you stop f or f uel, etc.)
204
Do not overf ill. Ext ended T owing
Towing Your Vehicle Behind a Motorhome
182
Improper towing preparation will
damage the transmission. Follow the
above procedure exactly. If you cannot
shif t the transmission or start the
engine, your car must be transported
on a f lat-bed or trailer.
The steering system can be damaged if
the steering wheel is locked. Leave the
ignition switch in the ACCESSORY (I)
position, and make sure the steering
wheel turns f reely bef ore you begin
towing.

If you cannot drive the vehicle
without f ixing the problem, and you
do not have a spare fuse, take a fuse
of the same rating or a lower rating
f rom one of the other circuits. Make
sureyoucandowithoutthatcircuit
temporarily (such as the accessory
power socket or radio).
If you replace the blown f use with a
spare f use that has a lower rating, it
might blow out again. This does not
indicate anything wrong. Replace the
f use with one of the correct rating as
soon as you can.If the replacement fuse of the
same rating blows in a short time,
there is probably a serious
electrical problem with your
vehicle. Leave the blown fuse in
that circuit, and have your vehicle
checked by a qualif ied mechanic.
If a trailer light is burned out, check
if these f uses are blown when you
replace the light bulbs:
If thosefusesareOK,butthetrailer
lights still do not work, there are two
blown 7.5 amp f uses in the trailer
hitch wiring. To access the 7.5 amp
f uses:
Open the tailgate and remove the
cargo f loor lid.
Pull out the bottom of the tailgate
rubber seal.
Remove rear trim panel by pulling
up on the inside edge of the rear
trim panel, and unhooking the f our
clips and tabs.
Af ter replacing f uses, and reinstall
the rear trim panel in the reverse
order of removal. Primary under-hood f use box
fuses5,7,and24
Interior driver’s side f use box: 10
Interior passenger’s side f use box:
10
If the radio f use is removed, the
audio system will disable itself . The
nexttimeyouturnontheradioyou
will see ‘‘COdE’’ in the f requency
display. Use the preset buttons to
enter the f ive-digit code (see page ).
6.
1.
2.
3.
4.
123
On EX and EX-L model
Trailer Fuses
Fuses
240
Replacing a f use with one that has a
higher rating greatly increases the
chances of damaging the electrical
system. If you do not have a
replacement f use with the proper rating
f or the circuit, install one with a lower
rating.

µµ
No. Amps. Circuits Protected No. Circuits Protected
No. Amps. Circuits Protected No. Amps. Circuits Protected Amps.
1
2
3
4
5
6
7
8
9
10
11
12
13 20 A
30 A
20 A
15 A
15 A
20 A
20 A
20 A
40 A
40 A
30 A
40 A Spare Fuse
Spare Fuse
Right Headlight
ACG S
Hazard
Not used
Stop
Lef t Headlight
Radio
Power Window Motor
Power Seat
Rear Defroster
Back Up, ACC 14
15
16
17
18
19
20
21
22
23
24
Rear A/C
Heater Motor
Cooling Fan
Spare Fuse
Spare Fuse
Spare Fuse
Battery
Condenser Fan
MG Clutch
IGI Main
Trailer (accessory)
1
2
3
4
5
6 40 A
20 A
30 A
40 A
20 A
20 A ABS F/S Relay
VSA F/S Relay
VSA Motor
ABS Motor
4WD
Rear Accessory Socket 7
8
9
10
11 15 A
15 A
15 A
7.5 A
(15 A) ET CS
IG Coil
LAF
TPMS
(FR FOG)
30 A
40 A
30 A
7.5 A 10 A
15 A
120 A 30 A
7.5 A 50 A
Fuse Locations
T aking Care of t he Unexpect ed
241
PRIMARY UNDER-HOOD FUSE BOX
SECONDARY UNDER-HOOD FUSE BOX

µµ
Î Î
Î Î
Î
No. No.
Amps. Amps.
Circuits Protected Circuits Protected
1
2
3
4
5
6
7
8
9
10
11
12
13 1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
15 A
10 A
7.5 A
7.5 A
7.5 A 15 A
7.5 A
7.5 A 10 A
7.5 A
7.5 A 30 A 20 A
20 A
20 A
20 A
10 A
20 A
20 A
15 A
15 A
10 A
20 A
7.5 A
7.5 A 20 A
20 A
Fuel Pump
SRS
Heater Control, A/C Clutch
Relay, Cooling Fan Relay
Power Mirror, VTM-4
Daytime Running Light
ECU(PCM),CruiseControl
OPDS, Rear Wiper
ACC Relay
Back-up Lights, Instrument
Lights
Turn Signals
VTM-4
Front Wiper
Not used
Driver’s Power Window
Driver’s Power Seat Reclining
Heated Seat
Driver’s Power Seat Sliding
Not used
Daytime Running Light
Driver’s side Rear Power
Window
Front Passenger’s Power
Window
Front Accessory Socket, Radio
Small Light
Interior Light, Navi
Power Door Lock
Back Up
Moonroof
Moonroof
Passenger’s Side Rear Power
Window
Canadian models
:
Canadian models
Fuse Locations
242
Driver’s Side INTERIOR FUSE BOX
Passenger’s Side
Front Front
:

CONT INUED
.
Malf unction Indicator Lamp . 58,235
..............
Manual Seat Adjustments . 84
...............................
Meters, Gauges .66
.................................
Modif ications .152
...................
Neutral Gear Position . 161
..................
New Vehicle Break-in . 146
...................
NOTICE, Explanation of . i
...............
Numbers, Identif ication . 244..............
Panel Brightness Control . 72
........................
Park Gear Position .161
...........................................
Parking .167
.................................
Parking Brake .93
Parking Brake and Brake System ...............................
Indicator .59, 236
.................................
Parking Lights .71
..
Parking Over Things that Burn . 253
..........................
Playing the Radio .106
..................................
Playing a CD .111
......
Playing the CD Changer . 113,114
...............................
Playing a Tape .119
.............................
PGM-FI System .252
................
Power Seat Adjustments . 83
.................
Power Socket Locations . 94
..............................
Power Windows .90
.........
Pregnancy, Using Seat Belts . 18.........
Protecting Adults and Teens . 12
...
Additional Safety Precautions . 19
.....
Advice f or Pregnant Women . 18
........................
Protecting Children .34
...........................
Protecting Inf ants .39
...........
Protecting Larger Children . 49
.............
Protecting Small Children . 40
...................
Radiator Overheating . 232
Radio/CD Sound ........................................
System .106
..........................
Readiness Codes .254
...............................
Rear A/C Unit .105
............
Rear Audio Control Panel . 129
........
Rear Entertainment System . 125
..
Rear Lights, Bulb Replacement . 210
............................
Rear View Mirror .88
.................
Rear Window Def ogger . 73
.
Rear Window Wiper and Washer . 70
..........
Reclining the Seat Backs . 83-86
.............................
Reminder Lights .57
................
Remote Audio Controls . 122
...
Octane Requirement, Gasoline . 146
.........................................
Odometer .66
...............................
Odometer, Trip .66
....................
Of f -Highway Driving . 183
...................
Of f -Road Precautions . 183
Oil ........................
Change, How to .200
..............
Change, When to . 192,193
......................
Checking Engine .149
..............
Pressure Indicator . 58,234
Selecting Proper Viscosity ......................................
Chart .199 ...........
ON (Ignition Key Position) . 77
Onboard Ref ueling Vapor ................................
Recovery .251
..............................
Outside Mirrors .89
....................
Overheating, Engine .232
....
Owner’s Maintenance Checks . 191
Index
N
O P
R
INDEX
V
