2005 HONDA ODYSSEY turn signal bulb

The lef t or right turn signal indicator
blinks when you signal a lane change
or turn. If the indicators do not blink
or blink rapidly, it usually means one
of the turn signal bulbs is burned out
(see page ). Replace the bulb as
soon as possible, since other drivers
cannot see that you are signaling.This indicator comes on as a
reminder that you must ref uel soon.
On the Touring model, you will also
see a ‘‘FUEL LOW’’ message in the
multi-inf ormation display.
When you press the hazard warning
button, both turn signal indicators
and all turn signals on the outside of
the vehicle f lash.
338
Instrument Panel Indicators
Turn Signal and
Hazard Warning
Indicators
Low Fuel Indicator
68
LOW FUEL
INDICATOR

Remove the electrical connector
f rom the bulb by pushing on the
tab and pulling the connector
down.
Remove the bulb by turning it one-
quarter turn counterclockwise.Open the hood. Remove the
socket f rom the headlight
assembly by turning it one-quarter
turn counterclockwise.
Pull the burned out bulb straight
out of its socket.
Push the new bulb straight into
the socket until it bottoms.
Push the electrical connector back
onto the bulb. Make sure it is on
all the way.
Turn on the headlights to test the
new bulb.
If you replaced the high beam
headlight bulb on the passenger’s
side, reinstall the power steering
f luid reservoir.
Insert the new bulb into the hole,
and turn it one-quarter turn clock-
wise to lock it in place. 5.
6.
7.
2.
3.
4. 2. 1.
Lights
Replacing a Front T urn Signal
Bulb
338
TAB

Remove the two bolt covers on the
rear pillar by prying on the bottom
edge with a flat-tip screwdriver.
Remove the bolts with a Phillips-
head screwdriver, and remove the
light assembly f rom the rear pillar.
Determine which of the two bulbs
is burned out: turn signal or
brake/taillight.Remove the socket by turning it
one-quarter turn counterclockwise.
Push the new bulb straight into
the socket until it bottoms.
Test the lights to make sure the
new bulb is working.Put the socket back into the light
assembly, and turn it clockwise to
lock it in place.
Install the rear light assembly in
the rear pillar. Tighten the two
bolts. Snap the bolt covers into
position.
Remove the bulb by pulling it
straight out of its socket.
2. 3.
5.6.
7.
1. 4.
Lights
Replacing a Rear Turn Signal or
Brake L ight Bulb
Maint enance
341

CONT INUED
....................................
Accessories .284
ACCESSORY (Ignition Key .....................................
Position) .130
............
Accessory Power Sockets . 182
...........................
AC Power Outlet .182
....................
Additives, Engine Oil . 329
Adjustable Driver’s Foot .........................................
Pedals .169
...............
AdvancedAirbagSystem . 29
.............................
Airbag (SRS) .11, 25
..............
Air Conditioning System . 188
.............
Rear A/C Control . 194,197
.......................
Air Outlets (Vents) .191
.......................
Air Pressure, Tires .346
.......................
Alcohol in Gasoline .278
......................................
Antif reeze .331
Anti-lock Brakes (ABS) ...............................
Indicator .65, 300
...................................
Operation .300
..............
Anti-thef t, Audio System . 229
Anti-thef t Steering Column ............................................
Lock .130
........................................
Armrests .152
...............
Audio Controls, Remote . 228................................
Audio System .199
...
Automatic Seat Belt Tensioners . 23
.
Automatic Lighting Off Feature . 124
.............
Automatic Speed Control . 264
..............
Automatic Transmission . 294
..........................
Capacity, Fluid .386
...............
Checking Fluid Level . 334
.......................................
Shif ting .294
Shif t Lever Position ...............................
Indicators .294
................
Shif t Lever Positions . 294
....................
Shif t Lock Release . 297
Battery Charging System ...........................
Indicator .63, 371
............................
Jump Starting .367
..............................
Maintenance .352
............................
Specif ications .387
..............................
Bef ore Driving .277
..................................
Belts, Seat .10, 22
.........................
Beverage Holders .171
..................................
Booster Seats .53 Brakes
...........
Anti-lock System (ABS) . 300
.............
Break-in, New Linings . 278
....................
Bulb Replacement .341
...........................................
Fluid .335
.......................................
Parking .169
.................
System Indicator . 63,373
........................
Wear Indicators .299
.............................
Braking System .299
.................
Break-in, New Vehicle . 278
Brightness Control, Instruments . 125
......................
Brights, Headlights .122
Bulb Replacement ..........................
Back-up Lights .342
..............................
Brake Lights .341
................
Front Parking Lights . 339
........
Front Side Marker Lights . 339
...........
Front Turn Signal Light . 338
.................................
Headlights .337
.........................
Rear Bulbs .341, 342
............
Rear Turn Signal Light . 341
............................
Specif ications .387
..............................
Bulbs, Halogen .337
Index
A
B
INDEX
I

CONT INUED
................................................
Keys .128
.........................................
Indicators .63
......
ABS (Anti-lock Brake) . 65,300
Brake (Parking and Brake ...........................
System) .63, 373
................
Charging System . 63,371
.............................
Cruise Control .69
DRL (Daytime Running .....................................
Lights) .69
.....................................
Fog Light .69
.............................
Fuel Economy .70
...................................
High Beam .69
.......
Key (Immobilizer System) . 67
.....................................
Lights On .66
......................................
Low Fuel .68
................
Low Oil Pressure . 63,371
......................
Low Tire Pressure .66
...............
Maintenance Required . 70
.....................
Side Airbag Of f .33, 64
.........................................
SRS .32, 64
.........................
System Message .70
Turn Signal and Hazard ...................................
Warning .68
Vehicle Stability Assist ..........................
(VSA) System .65
............................
VSA Activation .65
..............................
Washer Level .69 ..................
Individual Map Lights . 184
...............................
Inf ant Restraint .41
......................................
Inf ant Seats .43
......
LATCH Anchorage System . 45
...........................
Lower Anchors .45
..........
Tether Anchorage Points . 50
...................
Inf lation, Proper Tire . 346
...................
In-Floor Storage Area . 177
.................................
Inside Mirror .167
.............................
Inspection, Tire .347
........................
Instrument Panel .4 ,60
......
Instrument Panel Brightness . 125
....................
Integrated Sunshade .173
...............................
Interior Lights .183
........................................
Introduction .i
.................
Jacking up the Vehicle . 361
.......................................
Jack, Tire .360
................................
Jump Starting .367 .......................
Label, Certif ication .384
...............
Lane Change, Signaling . 122
..................
Lap/Shoulder Belts . 17,22
...........
LATCH Anchorage System . 45
.....................................
Lazy Susan .179
....................
Light Control Switch .183
Lights ....................
Bulb Replacement .337
.......................................
Indicator .63
.......................................
Interior .183
.......................................
Parking .122
................................
Turn Signal .122
............................
Load Limits .287, 306
....
LOCK (Ignition Key Position) . 130
Locks .....
Anti-thef t Steering Column . 130
............................
Fuel Fill Door .279
..................................
Glove Box .180
..................
Lockout Prevention . 137
...............................
Power Door .137
.............................
Sliding Doors .142
......................................
Tailgate .138
Index
J
K L
INDEX
V

Î
.....................................
Tachometer .71
..........................................
Tailgate .138
...............................
Opening the .138
...................
Open Monitor Light . 67
..
Taillights, Changing Bulbs . 341,342
...............................................
Seats .148
......................
Adjustments .149, 151
..........
Drivers Lumbar Support . 152
.............
Folding the Third Seat . 158
........................
Head Restraints .152
Installing the Stowable Second ...............
Row Plus-One Seat . 156
.....
Manual Height Adjustment . 150
....................
Passenger Seating .148
.......
Reclining the Second Seat . 150
..........
Reclining the Third Seat . 150
....
Removing the Second Seats . 155
.....................
Third Seat Access .153
............................
Security System .263
Sensors Front Passenger’s Weight .....................................
Sensors .29
....
Driver’s Seat Position Sensor . 29
...............................
Serial Number .384
...........................
Service Intervals .315
...........................
Service Manual .401
...........
Service Station Procedure . 279
..........................
Setting the Clock .227
...
Shif t Lever Position Indicators . 294
........................
Shif t Lock Release .297
..............................
Side Airbags .11, 30 ..........................
Of f Indicator .33, 64
Side Marker Lights, Bulb ..............................
Replacement .339
.............................
Signaling Turns .122
.................................
Sliding Doors .142
.....................................
Snow Tires .350
................................
Sound System .199
Spare Tire ......................................
Inf lating .359
............................
Specif ications .387
....................................
Spark Plugs .387
....................
Specif ications Charts . 386
................................
Speed Control .264
...................................
Speedometer .71
..........
SRS, Additional Inf ormation . 25
...
Additional Safety Precautions . 35
.............................
Airbag Service .34
..
How the SRS Indicator Works . 32
How Your Airbags ............................
Work .27, 30,32
........................
SRS Components .25
.............................
SRS Indicator .32 ,64
..
START (Ignition Key Position) . 130
.......................
Starting the Engine .293
In Cold Weather at High ..................................
Altitude .293 ................
With a Dead Battery . 367
..............
State Emissions Testing . 395
........
Steam Coming f rom Engine . 369
Steering Wheel ................................
Adjustment .127
...........
Anti-thef t Column Lock . 130
.................................
Buttons .75, 228
...................
Stereo Sound System . 199
....................
Storing Your Vehicle .353
Stowable Second Row Plus-One .............................................
Seat .156
........................
Sunglasses Holder .174
........................................
Sun Visor .175
Supplemental Restraint System ......................................
Servicing .34
.........................
SRS Indicator .32 ,64
...................
System Components . 25
..................................
Synthetic Oil .329
Index
T
VIII
