Check Gages Warning Light
The CHECK GAGES light will come on briey when you
start the engine.
If this light comes and stays on while you are driving,
check your coolant temperature and engine oil pressure
gages to see if they are in the warning zones.
Gate Ajar Light
If this light comes on, your endgate or liftglass is ajar.
Try closing the tailgate or liftglass again. Never
drive with the tailgate or liftglass even partially open. United States
CanadaUnited StatesCanada
3-37

Anti-Lock Brake System (ABS)
Your vehicle has anti-lock brakes. ABS is an advanced
electronic braking system that will help prevent a
braking skid.
When you start your engine and begin to drive away,
your anti-lock brake system will check itself. You
may hear a momentary motor or clicking noise while
this test is going on. This is normal.
If there is a problem with
the anti-lock brake system,
this warning light will
stay on. SeeAnti-Lock
Brake System Warning
Light on page 3-30.
Let us say the road is wet and you are driving safely.
Suddenly, an animal jumps out in front of you. You slam
on the brakes and continue braking. Here is what
happens with ABS:
A computer senses that wheels are slowing down. If
one of the wheels is about to stop rolling, the computer
will separately work the brakes at each front wheel
and at both rear wheels.
4-8

{CAUTION:
Snow can trap exhaust gases under your
vehicle. This can cause deadly CO (carbon
monoxide) gas to get inside. CO could
overcome you and kill you. You cannot see it
or smell it, so you might not know it is in your
vehicle. Clear away snow from around the
base of your vehicle, especially any that is
blocking your exhaust pipe. And check around
again from time to time to be sure snow does
not collect there.
Open a window just a little on the side of the
vehicle that is away from the wind. This will
help keep CO out.Run your engine only as long as you must. This saves
fuel. When you run the engine, make it go a little
faster than just idle. That is, push the accelerator
slightly. This uses less fuel for the heat that you get and
it keeps the battery charged. You will need a
well-charged battery to restart the vehicle, and possibly
for signaling later on with your headlamps. Let the
heater run for a while.
Then, shut the engine off and close the window almost
all the way to preserve the heat. Start the engine
again and repeat this only when you feel really
uncomfortable from the cold. But do it as little as
possible. Preserve the fuel as long as you can. To help
keep warm, you can get out of the vehicle and do
some fairly vigorous exercises every half hour or so until
help comes.
4-41

How to Check and Add Fluid
The proper uid should be added if the level does not
reach the bottom of the diaphragm when it is in place in
the reservoir. See the instructions on the reservoir cap.
Engine Coolant
The cooling system in your vehicle is lled with
DEX-COOL®engine coolant. This coolant is designed
to remain in your vehicle for ve years or 150,000 miles
(240 000 km), whichever occurs rst, if you add only
DEX-COOL
®extended life coolant.
The following explains your cooling system and how to
add coolant when it is low. If you have a problem
with engine overheating, seeEngine Overheating on
page 5-26.
A 50/50 mixture of clean, drinkable water and
DEX-COOL
®coolant will:
Give freezing protection down to−34°F (−37°C).
Give boiling protection up to 265°F (129°C).
Protect against rust and corrosion.
Help keep the proper engine temperature.
Let the warning lights and gages work as
they should.
Notice:Using coolant other than DEX-COOL
®may
cause premature engine, heater core or radiator
corrosion. In addition, the engine coolant may
require changing sooner, at 30,000 miles (50 000 km)
or 24 months, whichever occurs rst. Any repairs
would not be covered by your warranty. Always use
DEX-COOL
®(silicate-free) coolant in your vehicle.
What to Use
Use a mixture of one-halfclean, drinkable waterand
one-half DEX-COOL®coolant which will not damage
aluminum parts. If you use this coolant mixture, you do
not need to add anything else.
5-24

Audio System(s) (cont.)
Setting the Time for Radios without Radio
Data Systems (RDS)................................3-42
Theft-Deterrent Feature................................3-77
Understanding Radio Reception.....................3-78
Automatic Headlamp System............................3-16
Automatic Transmission
Fluid..........................................................5-19
Operation...................................................2-25
B
Battery..........................................................5-38
Run-Down Protection...................................3-19
Before Leaving on a Long Trip.........................4-34
Brake
Anti-Lock Brake System (ABS)........................ 4-8
Emergencies................................................ 4-9
Parking......................................................2-36
System Inspection.......................................6-32
System Warning Light..................................3-29
Brakes..........................................................5-35
Braking........................................................... 4-7
Braking in Emergencies..................................... 4-9
Break-In, New Vehicle.....................................2-20
Bulb Replacement...........................................5-45
Halogen Bulbs............................................5-46
Headlamps.................................................5-46
One-Piece Front Turn Signal Lamps...............5-48Bulb Replacement (cont.)
Replacement Bulbs......................................5-50
Taillamps....................................................5-50
Two-Piece Front Turn Signal Lamps...............5-49
Buying New Tires...........................................5-62
C
California Fuel.................................................. 5-6
Canadian Owners................................................ ii
Capacities and Specications............................5-95
Carbon Monoxide...................2-12, 2-40, 4-38, 4-57
Care of
Safety Belts................................................5-84
Your Cassette Tape Player............................3-78
Your CD Player...........................................3-79
Your CDs ...................................................3-79
Cargo Tie Downs............................................2-55
Center Front Passenger Position, Safety Belts....1-21
Center Rear Passenger Position, Safety Belts.....1-25
Center Seat Positions, Child Restraints..............1-49
Chains, Tire...................................................5-66
Charging System Light....................................3-28
Check
Engine Light...............................................3-31
Gages Warning Light...................................3-37
Checking Things Under the Hood......................5-10
Chemical Paint Spotting...................................5-87
2

D
Daytime Running Lamps..................................3-15
Defensive Driving............................................. 4-3
Doing Your Own Service Work........................... 5-4
Dome Lamps.................................................3-18
Door
Locks.......................................................... 2-8
Power Door Locks......................................... 2-9
Programmable Automatic Door Locks............... 2-9
Rear Door Security Locks.............................2-11
Driver
Position, Safety Belt.....................................1-14
Driver Behavior................................................ 4-2
Driver Information Center (DIC).........................3-39
Driving
At Night.....................................................4-28
City...........................................................4-32
Defensive..................................................... 4-3
Drunken....................................................... 4-4
Environment................................................. 4-2
Freeway.....................................................4-33
Hill and Mountain Roads..............................4-36
In Rain and on Wet Roads...........................4-30
Recovery Hooks..........................................4-43
Rocking Your Vehicle to Get it Out.................4-42
Winter........................................................4-38
E
Electrical System
Add-On Equipment......................................5-90
Engine Compartment Fuse Block...................5-92
Fuses and Circuit Breakers...........................5-90
Headlamps.................................................5-90
Instrument Panel Fuse Block.........................5-91
Power Windows and Other Power Options......5-90
Windshield Wiper Fuses...............................5-90
Engine
Air Cleaner/Filter.........................................5-17
Battery.......................................................5-38
Check and Service Engine Soon Light............3-31
Coolant......................................................5-24
Coolant Heater............................................2-24
Coolant Temperature Gage...........................3-31
Cooling System Inspection............................6-31
Engine Compartment Overview......................5-12
Exhaust.....................................................2-40
Fan Noise..................................................5-33
Oil .............................................................5-13
Overheating................................................5-26
Starting......................................................2-23
Entry Lighting.................................................3-18
Event Data Recorders (EDR)............................. 7-9
Exit Lighting...................................................3-18
Extender, Safety Belt.......................................1-28
Exterior Lamps...............................................3-14
4

F
Filter
Engine Air Cleaner......................................5-17
Finish Damage...............................................5-87
Fixed Mast Antenna........................................3-79
Flash-to-Pass................................................... 3-9
Flat Tire........................................................5-66
Flat Tire, Changing.........................................5-67
Flat Tire, Storing.............................................5-76
Fluid
Automatic Transmission................................5-19
Manual Transmission....................................5-22
Power Steering...........................................5-34
Windshield Washer......................................5-34
Fog Lamps....................................................3-17
Four-Wheel Drive....................................2-30, 5-44
Front Axle......................................................5-45
Front Reading Lamps......................................3-19
Front Storage Area.........................................2-52
Fuel............................................................... 5-5
Additives...................................................... 5-6
California Fuel.............................................. 5-6
Filling a Portable Fuel Container....................5-10
Filling Your Tank........................................... 5-8
Fuels in Foreign Countries.............................. 5-7
Gage.........................................................3-38
Gasoline Octane........................................... 5-5Fuel (cont.)
Gasoline Specications.................................. 5-5
Low Warning Light.......................................3-38
System Inspection.......................................6-31
Fuses
Engine Compartment Fuse Block...................5-92
Fuses and Circuit Breakers...........................5-90
Instrument Panel Fuse Block.........................5-91
Windshield Wiper.........................................5-90
G
Gage
Check Gages Warning Light..........................3-37
Engine Coolant Temperature.........................3-31
Fuel..........................................................3-38
Oil Pressure...............................................3-34
Speedometer..............................................3-26
Tachometer.................................................3-26
Voltmeter Gage...........................................3-28
Garage Door Opener.......................................2-45
Gasoline
Octane........................................................ 5-5
Specications............................................... 5-5
Gate Ajar Light...............................................3-37
Glove Box.....................................................2-49
GM Mobility Reimbursement Program.................. 7-5
5

H
Hazard Warning Flashers................................... 3-6
Head Restraints............................................... 1-6
Headlamps....................................................5-46
Automatic Headlamp System.........................3-16
Bulb Replacement.......................................5-45
Daytime Running Lamps...............................3-15
Electrical System.........................................5-90
Flash-to-Pass............................................... 3-9
Halogen Bulbs............................................5-46
High/Low Beam Changer................................ 3-9
On Reminder..............................................3-15
One-Piece Front Turn Signal Lamps...............5-48
Two-Piece Front Turn Signal Lamps...............5-49
Heated Seats................................................... 1-4
Heater...........................................................3-20
Highbeam On Light.........................................3-35
Highway Hypnosis...........................................4-35
Hill and Mountain Roads..................................4-36
HomeLink
®Transmitter....................................2-45
HomeLink®Transmitter, Programming................2-46
Hood
Checking Things Under................................5-10
Release.....................................................5-11
Horn............................................................... 3-6
How to Use This Manual...................................... ii
How to Wear Safety Belts Properly...................1-13
Hydraulic Clutch.............................................5-23
I
Ignition Positions.............................................2-21
Infants and Young Children, Restraints...............1-31
Ination -- Tire Pressure..................................5-59
Inspection
Brake System.............................................6-32
Engine Cooling System................................6-31
Exhaust System..........................................6-31
Fuel System...............................................6-31
Part C - Periodic Maintenance.......................6-31
Steering, Suspension and Front Drive
Axle Boot and Seal..................................6-31
Throttle System...........................................6-32
Transfer Case and Front Axle
(Four-Wheel Drive)...................................6-32
Instrument Panel
Brightness..................................................3-18
Cluster.......................................................3-24
Overview..................................................... 3-4
J
Jump Starting.................................................5-39
K
Keyless Entry System....................................... 2-4
Keys............................................................... 2-3
6
