2005 DODGE VIPER power steering fluid

▫Body Lubrication.....................179
▫Front And Rear Suspension Ball Joints......179
▫Steering Linkage......................180
▫Body Mechanism Lubrication.............180
▫Windshield Washers...................182
▫Exhaust System......................182
▫Cooling System.......................183
▫Hoses And Vacuum/Vapor Harnesses.......188
▫Brake System........................188
▫Brake, Power Steering, And Fuel System
Hoses.............................189
▫Brake And Clutch Fluid.................190
▫Master Cylinder......................191▫Hydraulic Clutch.....................192
▫Transmission........................193
▫Rear Axle...........................193
▫Wheel Bearings.......................194
▫Appearance Care.....................194

Fuses—Power Distribution Center..........197

Vehicle Storage........................202

Replacement Bulbs......................204
▫Interior Light Bulbs....................204
▫Exterior Light Bulbs...................205

Exterior Light Bulb Service................205
▫Headlight, Parking, Front Park, Turn Signal, Front
Sidemarker And Front Fog Light Removal....205
158 MAINTAINING YOUR VEHICLE

Power Steering (Pump and Reservoir)
WARNING!
Fluid level should be checked with the engine off to
prevent injury from moving parts. Do not overfill.
Use only the manufacturer’s recommended fluid.
Refer to Recommended Fluids, Lubricants and
Genuine Parts for correct fluid type.
Check power steering fluid level at intervals as specified
in the maintenance schedules.
During scheduled maintenance, check the power steering
fluid level at the power steering fluid reservoir.The fluid should be checked HOT with the engine OFF.
Before removing the reservoir cap, wipe the outside of
the cap and reservoir so that no dirt can fall into the
reservoir.
Power Steering Fluid Reservoir
178 MAINTAINING YOUR VEHICLE

All power steering pumps have a dipstick. Fluid level
should be maintained at the proper level indicated on the
dipstick. If necessary, add fluid to restore to the proper
indicated level. With a clean cloth, wipe any spilled fluid
from all surfaces. Only petroleum fluids specially formu-
lated for minimum effect on the rubber hoses should be
used. Use only the manufacturer’s recommended fluid.
Refer to Recommended Fluids, Lubricants and Genuine
Parts for the correct fluid type.
Body Lubrication
Locks and all body pivot points, including such items as
seat tracks, doors, liftgate and hood hinges, should be
lubricated periodically to assure quiet, easy operation
and to protect against rust and wear. Prior to the appli-
cation of any lubricant, the parts concerned should be
wiped clean to remove dust and grit; after lubricating
excess oil and grease should be removed. Particular
attention should also be given to hood latching compo-
nents to insure proper function. When performing otherunderhood services, the hood latch, release mechanism
and safety catch should be cleaned and lubricated.
The external lock cylinders should be lubricated twice a
year, preferably in the fall and spring. Apply a small
amount of a high quality lubricant such as MoparLock
Cylinder Lubricant directly into the lock cylinder.
Front and Rear Suspension Ball Joints
Your vehicle has suspension ball joints that require
periodic servicing. These ball joints should be inspected
whenever servicing a vehicle for other reasons.
Damaged seals should be replaced to prevent leakage or
contamination of the grease. If there is any movement
within the ball joint, the knuckle or control arm must be
replaced. The ball joints are not serviceable by them-
selves.
MAINTAINING YOUR VEHICLE 179
7

WARNING!
Riding the brakes can lead to brake failure and
possibly an accident. Driving with your foot resting
or riding on the brake pedal can result in abnormally
high brake temperatures, excessive lining wear, and
possible brake damage. You wouldn’t have your full
braking capacity in an emergency.
Brake, Power Steering, and Fuel System Hoses
When servicing the vehicle for scheduled maintenance,
inspect surface of hoses and nylon tubing for evidence of
heat and mechanical damage. Hard and brittle rubber,
cracking, checking, tears, cuts, abrasion, and excessive
swelling suggest deterioration of the rubber. Particular
attention should be made to examining those hose sur-
faces nearest to high heat sources, such as the exhaust
manifold.Inspect all hose clamps and couplings to make sure they
are secure and no leaks are present.
Insure nylon tubing in these areas has not melted or
collapsed.
NOTE:Often, fluids are used during assembly plant
operations to ease the assembly of hoses to couplings.
Therefore, oil wetness at the hose-coupling area is not
necessarily an indication of leakage. Actual dripping of
hot fluid when systems are under pressure (during
vehicle operation) should be noted before hose is re-
placed based on leakage.
High pressure fuel system hoses have unique material
characteristics that provide adequate sealing and resist
attack by deteriorated gasoline.
Use only manufacturer specified hoses or their equiva-
lent in material and specification, in any fuel system
MAINTAINING YOUR VEHICLE 189
7

Chassis
Component Fluid, Lubricant, or Genuine Part
Transmission Mopar Synthetic Manual Transmission Lubricant SAE 75W-85 (Castrol Syn-
torq LT 75W/85)
Rear Axle Mopar Synthetic Gear and Axle Lubricant SAE 75W-140, with Limited Slip
Additive Friction Modifier
Brake Master Cylinder MoparBrake & Clutch Fluid DOT 4 Motor Vehicle
Power Steering Reservoir ATF+4
214 MAINTAINING YOUR VEHICLE

At Each Stop for Fuel
•Check the engine oil level about 5 minutes after a fully
warmed engine is shut off. Checking the oil level while
the vehicle is on level ground will improve the accu-
racy of the oil level reading. Add oil only when the
level is at or below the ADD or MIN mark.
•Check the windshield washer solvent and add if
required.
Once a Month
•Check tire pressure and look for unusual wear or
damage.
•Inspect the battery and clean and tighten the terminals
as required.
•Check the fluid levels of coolant reservoir, brake
master cylinder, power steering and transmission and
add as needed.
•Check all lights and all other electrical items for correct
operation.
At Each Oil Change
•Change the engine oil filter.
•Inspect the exhaust system.
•Inspect the brake hoses.
•Inspect the suspension components.
•Lubricate door hinges and check springs.
•Check the engine coolant level, hoses, and clamps.
•Check power steering fluid level.
220 MAINTENANCE SCHEDULES
8
M
A
I
N
T
E
N
A
N
C
E
S
C
H
E
D
U
L
E
S

Gas Caution.......................... 173
Jump Starting......................... 150
Keyless Transmitter Replacement............ 19
Bearings.............................. 194
Belt System, Six Point..................... 32
Belts, Drive............................ 168
Belts, Seat.............................. 26
Body Damage.......................... 195
Body Mechanism Lubrication............179,180
Body Mechanisms....................... 181
Boot, Convertible Top...................59,64
B-Pillar Location........................ 126
Brake, Parking.......................... 116
Brake System........................ 117,188
Anti-Lock............................ 117
Fluid Check.......................190,214
Hoses.............................. 189
Master Cylinder....................... 191
Warning Light......................... 91Break-In Recommendations, New Vehicle.....50,121
Bulb Replacement....................... 205
Bulbs, Light.........................204,205
Capacities, Antifreeze (Engine Coolant)........ 212
Capacities, Fluid........................ 212
Capacity, Cargo Weight................... 146
Caps, Filler
Power Steering........................ 178
Radiator (Coolant Pressure)............... 185
Car Washes............................ 197
Carbon Monoxide Warning...............51,145
Cargo Compartment
Capacity............................ 146
Carpeting............................. 196
Catalytic Converter...................... 168
CD Player............................95,98
CD Player Maintenance................... 103
Chains, Tire............................ 140
INDEX 245
10

Engine Oil Viscosity...................166,212
Engine Oil Viscosity Chart................. 166
Exhaust Gas Caution................51,145,182
Exhaust System......................... 182
Exterior Lights.......................... 205
Fan .................................. 105
Filters
Air Cleaner.......................... 171
Engine Oil........................... 213
Flashers
Hazard Warning.....................87,148
Turn Signal........................... 87
Flash-To-Pass........................... 78
Floor Console........................... 66
Fluid Capacities......................... 212
Fluid Leaks............................. 52
Fluid Level Checks
Brake............................190,214Capacities........................... 212
Cooling System....................... 183
Engine Oil........................... 164
Manual Transmission................... 193
Power Steering.....................178,214
Fluids................................ 213
Fog Lights.........................75,77,90
Four-Way Hazard Flasher.................. 148
Freeing A Stuck Vehicle................... 155
Fuel................................. 142
Adding............................. 145
Additives............................ 144
Clean Air............................ 142
Gasoline............................ 142
Gauge............................... 93
Octane Rating........................ 213
Requirements......................142,212
Tank Capacity........................ 212
Fueling............................... 145
248 INDEX
