MAINTAINING YOUR VEHICLE 237
7
Cup HolderUse a gentle dishwashing detergent or mild detergent
for delicate fabrics as a washing solution. Wipe with a
cloth moistened in lukewarm solution. Do not use
scouring agents.Seat BeltsThe webbing must not be treated with chemical
cleaning agents. Use only clear, lukewarm water and
soap. Do not dry the webbing at temperatures above
176
°F (+80
°C) or in direct sunlight.
Headliner and Shelf Below Rear WindowClean with soft bristle brush, or use a dry-shampoo
cleaner in case of excessive dirt.
UpholsteryUsing aftermarket seat covers or wearing clothing that
have the tendency to give off coloring (e.g. when wet
etc.) may cause the upholstery to become permanently
discolored. By lining the seats with a proper
intermediate cover, contact discoloration will be
prevented.
Leather Upholstery
Wipe leather upholstery with a damp cloth and dry
thoroughly or clean with a leather care product.
Exercise particular care when cleaning perforated
leather as its underside should not become wet.
Cloth Upholstery
Clean with soft bristle brush, or use a dry-shampoo
cleaner in case of excessive dirt.
Tex Upholstery
Pour an interior care product onto soft lint-free cloth
and apply with light pressure.Hard Plastic Trim ItemsPour an interior care product onto soft lint-free cloth
and apply with light pressure.
WARNING!
Do not bleach or dye seat belts as this may severe-
ly weaken them. Due to this treatment they may
not be able to provide adequate protection. For ex-
ample, in a crash the belts can be torn.

MAINTAINING YOUR VEHICLE 241
7
No. Rated Circuit
1. 10A Parking lamp right, taillamp right
2. 10A High beam head lamp,right
3. 10A High beam head lamp, left, high beam indicator lamp
4. 10A Backup lamp
5. 10A Brake lamp
6. 20A Windshield wiper motor
7. 15A Horn, heated rear window, air recirculation switch,
optional equipment relay (terminal 15)
8. 20A Interior lighting, cigarette lighter, radio (terminal 30)
9. 15A Clock, hazard warning lamps, parking lamps 10. 10A Instrument lighting, license plate lamp
daytime driving lamps
11. 10A Side lamp, left; taillamp, left
12. 10A Low beam headlamp, right
13. 10A Low beam headlamp, left
14. 15A Fog lamp
15. 10A Radio (terminal 15)
16. 25A Engine control unit
17. 15A Engine control unit
18. 15A Ignition (terminal 15)
19. 15A Not in use
20. 15A Heater controls (terminal 30)
21. 30A Heater blower (terminal 30)

MAINTAINING YOUR VEHICLE 245
7
BULB REPLACEMENTSwitch the lights off to prevent short circuits.
Only touch new bulbs with a clean, lint-free cloth. Do
not touch bulbs with wet or greasy fingers.
Only fit 12 volt bulbs of the same type as before and
with the correct wattage rating.
Front Lamp UnitBulbs are changed from inside the engine
compartment.
Move the retainer bar to the side and remove the
housing cover.
WARNING!
Bulbs and bulb holders can become very hot. Al-
low the lamp to cool down before changing the
bulb.
Keep bulbs out of reach of children.
Do not use bulbs which have been dropped or
which show signs of scratches on the glass. They
could explode.
Changing an H7 bulb:
The bulb is pressurized. Always wear eye and
hand protection.

268 MAINTENANCE SCHEDULES
M A I
N T
E
N A
N
C E
S
C
H
E
D
U L
E
S8
SCOPE OF WORK FOR MAINTENANCE SERVICE
Oil ServiceOil change
Engine:
Oil change and filter replacement
Check fluid levels of the following system, refill as
necessary.
If fluid is lost, trace and eliminate cause – as a separate
order.
Power-assisted steering
Lubrication work:
Trailer tow hitch (original equipment)
Maintenance
ASSYST maintenance computer reset Function check
Signalling system,
warning and indicator lamps
Headlamps, exterior lighting
Windscreen wipers,
windscreen washer system
Check for leaks and damage.
Check for abrasion points and ensure that
lines are correctly routed!
All assemblies:
Engine, transmission, transfer case, front axle, rear
axle, steering, power steering pump
All lines and hoses, sensor cables
Rubber boots on front axle drive shafts,
rubber boots on front axle suspension ball joints, shock
absorbers

INDEX 283
10
Acceleration Skid Control Warning Lamp . 143, 166
Additional Brake Lamp . . . . . . . . . . . . . . . . . . . . . 252
Anti-Lock Brake System (ABS) Indicator Lamp. 161
Battery Charge Indicator Lamp . . . . . . . . . . . . . . 104
Brake Lamp . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 157
Brake System . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 164
Coolant Level Indicator Lamp . . . . . . . . . . . . . . . 106
Electronic Brake Force Distribution . . . . . . . . . . . 157
Engine Control Unit Indicator Lamp . . . . . . . . . . 107
Engine Oil Level . . . . . . . . . . . . . . . . . . . . . . . . . . . 115
Engine Oil Level Indicator Lamp . . . . . . . . . . . . . 105
Exit Lamps . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 256
Indicator Lamps . . . . . . . . . . . . . . . . . . . . . . . . . . . . 91
License Plate Lamp . . . . . . . . . . . . . . . . . . . . . . . . . 252
Reading Lamp . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 255
Reserve Fuel Indicator Lamp . . . . . . . . . . . . . . . . 103
Seat Belt Warning Lamp . . . . . . . . . . . . . . . . . . . . . 44
Side-Marker Lamp . . . . . . . . . . . . . . . . . . . . . . . . . 253
SRS Malfunction Indicator Lamp . . . . . . . . . . . . . . 49
Taillamp . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 250
Water in Fuel Indicator Lamp . . . . . . . . . . . . . . . . 104 Lifting Points . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 203
Lighter, Cigar . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 82
Lighting, Interior . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 69
Loading . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 150
Lock, Ignition . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Locking, Central . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Lumbar Support . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 61
MMaintenance Computer . . . . . . . . . . . . . . . . . . . . . . . 110
Maintenance Intervals . . . . . . . . . . . . . . . . . . . . . . . . . 265
Maintenance Schedules
Additional Maintenance Work After ... Years . . 270
Brake Fluid . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 267
Coolant . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 267
Dust Filter for Heating/Ventilation Replacement . .
267
Engine Oil Change and Filter Replacement . . . . 267
Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 264
Oil Service . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 268
Once a Year . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 267
Regular Check-Ups . . . . . . . . . . . . . . . . . . . . . . . . . 266
Scope of Work for Maintenance service . . . . . . . 268
