2005 DODGE NEON SRT fuses

▫Hoses And Vacuum/Vapor Harnesses.......161
▫Brake System........................162
▫Manual Transaxle.....................164
▫Appearance Care And Protection From
Corrosion...........................165

Fuses...............................170
▫Underhood Fuses
(Power Distribution Center)..............170
▫Interior Fuses........................171

Vehicle Storage........................173

Replacement Bulbs.....................173

Bulb Replacement......................174▫Headlight Bulb Replacement.............174
▫Front Park/Turn Signal Lights............175
▫Front Sidemarker Light.................175
▫Tail/Stop, Rear Turn Signals And Back-Up
Lights.............................176
▫Center High Mounted Stop Light..........176

Fluids And Capacities...................176

Recommended Fluids, Lubricants And Genuine
Parts
...............................177
▫Engine.............................177
▫Chassis............................177
140 MAINTAINING YOUR VEHICLE

FUSES
Underhood Fuses (Power Distribution Center)
A Power Distribution Center is located in the engine
compartment; next to the battery. A label identifying the
components and circuits is located on the underside of
the cover.
FUSE Amp/Color Items Fused
1——
2——
3 40 Amp/
GreenHeadlamps
4 40 Amp/Blue Ignition Run
5 30 Amp/
GreenABS Solenoid
6 30 Amp/Blue Radiator Fan
7 Spare
8 40 Amp/
GreenABS Pump
9 30 Amp/
GreenStarter
10 40 Amp/
GreenElectric Back Light (EBL)
11 Spare
12 Spare
13 20 Amp/
YellowIOD/Int Lighting/Radio
14 20 Amp/Lt.
BluePower Outlet
Underhood Fuses (Power Distribution Center)
170 MAINTAINING YOUR VEHICLE

15 15 Amp/
YellowHazard Flasher
16 15 Amp/Lt.
BlueMTV
17 20 Amp/
YellowElectronic Automatic
Transaxle (EATX)
18 10 Amp/Red Horn
19 Spare
20 20 Amp/
YellowFog Lamp (Export Only)
21 20 Amp/
YellowASD/Fuel Pump
22 10 Amp/Red A/C Clutch
23 15 Amp/Lt.
BlueStop Lamps
Interior Fuses
The fuse access panel is behind the end cover at the left
side of the instrument panel. To remove the panel, pull it
out, as shown. A diagram identifying the components
and circuits is located on the inside of the cover.
FUSE Amp/Color Items Fused
1 10 Amp/Red Power Mirror/
Multifunction
2 20 Amp/
YellowWiper Switch/Motor
3 20 Amp/
YellowRadio/Power Sunroof
4 15 Amp/Lt.
BlueInterior Lighting
Interior Fuse Panel
MAINTAINING YOUR VEHICLE 171
