2005 DODGE GRAND CARAVAN window

WARNINGS AND CAUTIONS
This manual contains WARNINGS against operating
procedures which could result in an accident or bodily
injury. It also contains CAUTIONS against procedures
which could result in damage to your vehicle. If you do
not read this entire manual you may miss important
information. Observe all Warnings and Cautions.
VEHICLE IDENTIFICATION NUMBER
The vehicle identification number (VIN) is found on the
left front corner of the instrument panel, visible from
outside of the vehicle through the windshield. This
number also appears on the Automobile Information
Disclosure Label affixed to a window on your vehicle.
Save this label for a convenient record of your vehicle
identification number and optional equipment. NOTE: It is illegal to remove the VIN plate. Vehicle Identification Number6 INTRODUCTION

Vehicle Theft Alarm — If Equipped ...........27

Sliding Side Door ........................29
▫ Sliding Door Open Flash .................30
▫ Power Sliding Door — If Equipped .........31
▫ Child Protection Door Lock ...............33

Liftgate ...............................35
▫ Power Liftgate — If Equipped .............36

Windows .............................38
▫ Manual Rear Vent Windows ...............38
▫ Power Vent Windows — If Equipped ........38
▫ Power Windows — If Equipped ............39

Occupant Restraints ......................41 ▫ Lap/Shoulder Belts .....................42
▫ Lap/Shoulder Belt Untwisting Procedure .....48
▫ Center Lap Belts .......................50
▫ Seat Belt Pretensioners ...................50
▫ Enhanced Driver Seat Belt Use Reminder System
(BeltAlert) ...........................51
▫ Seat Belts And Pregnant Women ............52
▫ Seat Belt Extender ......................52
▫ Driver And Front Passenger Supplemental
Restraint Systems (SRS) — Airbags ..........53
▫ DaimlerChrysler Corporation Integrated
Child Seat — If Equipped ................68
▫ Child Restraint ........................6910 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE

NOTE: The power window switches, radio, power
outlets, and removable console (if equipped), will remain
active for up to 45 seconds after the ignition switch has
been turned off. Opening a vehicle front door will cancel
this feature.
WARNING!Leaving children in a vehicle unattended is danger-
ous for a number of reasons. A child or others could
be injured. Children should be warned not to touch
the parking brake, brake pedal or the gear selector
lever. Don’t leave the keys in the ignition. A child
could operate power windows, other controls, or
move the vehicle. CAUTION!An unlocked car is an invitation to thieves. Always
remove key from the ignition and lock all doors
when leaving the vehicle unattended.
Key-In-Ignition Reminder
If you open the driver ’ s door and the key is in the ignition
switch, a chime will sound to remind you to remove the
key.
SENTRY KEY
The Sentry Key Immobilizer System prevents unautho-
rized operation of the vehicle by disabling the engine.
The system will shut the engine off after 2 seconds of
running if an invalid key is used to start the vehicle. This
system utilizes ignition keys which have an electronic THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 13
2

• If the power liftgate encounters multiple obstructions
within the same cycle, the system will automatically
stop and must be opened or closed manually.
WARNING!• Driving with the liftgate open can allow poison-
ous exhaust gases into your vehicle. You and your
passengers could be injured by these fumes. Keep
the liftgate closed when you are operating the
vehicle.
• If you are required to drive with the liftgate open,
make sure that all windows are closed, and the
climate control blower switch is set at high speed.
DO NOT use the recirculation mode. Gas props support the liftgate in the open position.
However, because the gas pressure drops with tempera-
ture, it may be necessary to assist the props when
opening the liftgate in cold weather.
WINDOWS
Manual Rear Vent Windows
A lever at the rear of each window releases the window
so that it can be pushed out for ventilation.
Power Vent Windows — If Equipped
Switches on the driver ’ s door trim panel let the driver
operate the two vent windows from the front seat.38 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE

Power Windows — If Equipped
You can control either front window using switches on
the driver ’ s door trim panel. There is a single switch on
the passenger ’ s door trim panel which operates the passenger door window. The switches will operate only
when the ignition switch is in the ON or ACCESSORY
position.
Power Vent Window Switches
Power Window SwitchesTHINGS TO KNOW BEFORE STARTING YOUR VEHICLE 39
2

Auto Down Feature — If Equipped
The driver ’ s window switch has an auto down feature.
Press the window switch past the detent, release, and the
window will go down automatically.
To open the window part way, press the window switch
part way and release it when you want the window to
stop.
The power window switches remain active for up to 45
seconds after the ignition switch has been turned off.
Opening a vehicle front door will cancel this feature. Wind Buffeting
Wind buffeting can be described as the perception of
pressure on the ears or a helicopter type sound in the
ears. Your vehicle may exhibit wind buffeting with the
windows down, or the sunroof (if equipped) in certain
open or partially open positions. This is a normal occur-
rence and can be minimized. If the buffeting occurs with
the rear windows open, open the front and rear windows
together to minimize the buffeting. If the buffeting occurs
with the sunroof open, adjust the sunroof opening to
minimize the buffeting.40 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE

OCCUPANT RESTRAINTS
Some of the most important safety features in your
vehicle are the restraint systems. These include the front
and rear seat belts for the driver and all passengers, front
airbags for both the driver and front passenger, driver
inflatable knee blocker and if equipped, window bags for
the driver and passengers seated next to a window. If you
will be carrying children too small for adult-size seat
belts, your seat belts or the LATCH feature (Lower
Anchors and Tether for CHildren) also, can be used to
hold infant and child restraint systems.
If your vehicle is equipped with the Occupant Classifi-
cation System (OCS) there will be a Passenger Airbag
Disabled (PAD) Indicator Light located on the center of
the instrument panel. NOTE: The front airbags have a multi stage inflator
design. This allows the airbag to have different rates of
inflation that are based on collision severity.
Please pay close attention to the information in this
section. It tells you how to use your restraint system
properly to keep you and your passengers as safe as
possible. Passenger Airbag Disabled Light THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 41
2

Also, the front passenger airbag is certified to the Federal
regulations that define Occupant Classification (Refer to
“ Occupant Classification System ” in this section).
This vehicle may also be equipped with a driver inflat-
able knee blocker located on the instrument panel below
the steering column.
This vehicle may also be equipped with window bags to
protect the driver, front, and rear passengers sitting next
to a window. If the vehicle is equipped with window
bags, they are located above the side windows. Their
covers are also labeled SRS AIRBAG.
NOTE: Airbag covers may not be obvious in the interior
trim; but they will open to allow airbag deployment. Window Bags54 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE
