2005 CHRYSLER TOWN AND COUNTRY climate control

A/C Recirculation Programming
The recirculation control is programmed to cancel the
recirculation mode when the ignition key is turned OFF
and will reset to outside air mode when the ignition key
is turned ON. The frequent use of outside air will help
keep odors from building up within the air conditioner-
heater housing. It is recommended that the recirculation
mode be used as little as possible, especially in humid
climates.
For hot and dry climates, or people who are allergic to
pollen and find frequent use of the recirculation mode
necessary, the recirculation mode can be programmed to
not automatically reset to the outside mode by using the
following procedures:
•Turn the ignition switch to the OFF position.
•Set the mode control to“PANEL”.
•Depress and hold in the“Rear Wipe/Wash”button.
•Start the engine, and continue to hold in the“Rear
Wipe/Wash”button until the indicator light starts
flashing repeatedly.
•Press the recirculation button until the indicator light
remains lit.
•The selection will be stored when the ignition switch is
turned OFF or if the“Rear Wipe/Wash”button is
pressed.
If the recirculation indicator light is lit, the recirculation
mode will not reset when the engine is started. If the
recirculation indicator light is not lit, the recirculation
mode will reset to the outside air mode when the engine
is started. The programmed status can be changed back
and forth by following the above mentioned procedure.
UNDERSTANDING YOUR INSTRUMENT PANEL 273
4

Manual Rear Zone Climate Control—If Equipped
The Manual Rear Zone Climate Control system has floor
air outlets to the rear of the right side sliding door and
overhead outlets at each outboard rear seating position.
The unit provides warm or cool air through the floor and
upper outlets.
The rear blower and temperature controls for the rear
seat passengers are located in the headliner near the
center of the vehicle.
Rear Blower Control
The primary control for the rear blower is on the front
climate control unit located on the instrument panel.
The center knob on the front climate control unit has five
positions,“REAR”,“OFF”, and a range of blower speeds.
Manual Rear Zone Climate ControlRear Blower Control
274 UNDERSTANDING YOUR INSTRUMENT PANEL

Only when the primary control for the rear blower is in
the“REAR”position do the second seat occupants have
control of the rear blower speed.
The rear blower control, located in the headliner near the
center of the vehicle has an OFF position and 3 blower
speed positions. This allows the second seat occupants to
control the volume of air circulated in the rear of the
vehicle.CAUTION!
Interior air enters the Manual Rear Zone Climate
Control system through an intake grille located in
the passenger side trim panel behind the third seat.
The heater outlets are located in the passenger side
trim panel just behind the sliding door. Do not block
or place objects directly in front of the inlet grille or
heater outlets. The electrical system could overload
causing damage to the blower motor.
Rear Temperature And Mode Control
When the center knob on the front climate control unit is
set to the“REAR”position, the second seat occupants
have control of the rear temperature and modes as
follows:
•The rear temperature knob controls both the rear
temperature and mode. When the temperature knob is
UNDERSTANDING YOUR INSTRUMENT PANEL 275
4

in the cold position, cold air will be delivered from the
headliner outlets. As the rear temperature knob is
turned towards hot, the air will get warmer, and the
air will be delivered from both the headliner and floor
outlets. When the rear temperature knob reaches the
full hot position, all of the air will be delivered from
the floor outlets.
•When the center knob on the front climate control unit
is set to any position other than“REAR”, the rear
temperature selection follows the setting of the driv-
er’s temperature control on the front climate control
unit. The rear mode selection follows the setting of the
front mode control.
Rear Economy Mode
If rear economy mode is desired, set the center knob on
the front control unit to the“REAR”position. Turn the
A/C button OFF and select any mode except“MIX”or
“DEFROST”.The rear temperature knob and the rear blower speed can
be adjusted as desired by the second seat occupants.
Infrared Three-Zone Automatic Temperature
Control—If Equipped
The Infrared Three-Zone Automatic Temperature Control
System automatically maintains the interior comfort level
desired by the driver and all passengers. This is accom-
plished by using two infrared sensors, located in the
center of the instrument panel. The two infrared sensors
independently measure the surface temperature of the
driver and passenger. Based on the sensor input, the
system automatically adjusts the air temperature, the air
flow volume, and amount of outside air recirculation.
This maintains a comfortable temperature even under
changing conditions.
276 UNDERSTANDING YOUR INSTRUMENT PANEL

Operating Tips A/C Air Filter—If Equipped
The climate control system filters out dust, pollen and
some odors from the air. Strong odors can not be totally
filtered out. Refer to MAINTAINING YOUR VEHICLE,
“Air Conditioner Maintenance”for filter replacement
instructions.
REAR WINDOW FEATURES
Intermittent Rear Wiper Operation—Manual
Temperature Control Only
The controls are located on the Manual Tempera-
ture Control head above the front blower control.
When the button is pressed and released and the
Ignition Switch in ON, the rear wiper will operate at a
fixed interval of about 8 seconds. As vehicle speed
increases, the time delay will shorten. The LED indicator
will light when the wiper is ON. Pressing and releasing
the button again with turn the wiper off.
288 UNDERSTANDING YOUR INSTRUMENT PANEL

Call Toll Free at1–800–890–4038 (U.S.)or1–800–387–1143
(Canada)
Or
Visit us on the World Wide Web at:
www.techauthority.daimlerchrysler.comor
www.daimlerchrysler.ca/manuals
DEPARTMENT OF TRANSPORTATION UNIFORM
TIRE QUALITY GRADES
The following describes the tire grading categories estab-
lished by the National highway Traffic Safety Adminis-
tration. The specific grade rating assigned by the tire’s
manufacturer in each category is shown on the sidewall
of the tires on your car.
All Passenger Car Tires Must Conform to Federal Safety
Requirements in Addition to These Grades.
Treadwear
The treadwear grade is a comparative rating based on the
wear rate of the tire when tested under controlled con-
ditions on a specified government test course. For ex-
ample, a tire graded 150 would wear one and a half (1
1/2) times as well on the government course as a tire
graded 100. The relative performance of tires depends
upon the actual conditions of their use, however, and
may depart significantly from the norm due to variations
in driving habits, service practices and differences in road
characteristics and climate.
Traction Grades
The traction grades, from highest to lowest, are A, B, and
C, and they represent the tire’s ability to stop on wet
pavement as measured under controlled conditions on
specified government test surfaces of asphalt and con-
crete. A tire marked C may have poor traction perfor-
mance.
IF YOU NEED CONSUMER ASSISTANCE 451
9

Caps, Filler
Fuel................................ 336
Oil (Engine).......................... 383
Radiator (Coolant Pressure)............... 397
Car Washes............................ 407
Carbon Monoxide Warning................. 335
Cargo Compartment
Luggage Carrier....................... 185
Cargo (Vehicle Loading)................... 184
Cassette Tape and Player Maintenance......... 264
Cassette Tape Player................209,219,224
Catalytic Converter...................... 385
Caution, Exhaust Gas.................38,83,335
CD Changer.............218,227,240,241,244,246
CD Player.........215,219,226,229,232,236,239,246
CD Player Maintenance................... 265
Cellular Phone........................96,265
Center High Mounted Stop Light............ 421
Center Lap Belts......................... 51Chains, Tire............................ 330
Changing A Flat Tire..................... 348
Chart, Tire Sizing........................ 311
Check Engine Light
(Malfunction Indicator Light).............205,378
Child Restraint.......................... 69
Child Restraint Tether Anchors............... 74
Child Safety Locks........................ 34
Child Seat............................69,76
Clean Air Gasoline....................... 333
Climate Control......................... 266
Clock................................ 207
Compact Disc Changer.................... 244
Compact Disc Maintenance................. 265
Compact Disc Player..................209,215
Compact Spare Tire...................... 322
Compass.............................. 155
Compass Calibration..................... 156
Compass Variance....................... 156
456 INDEX
