2005 CHRYSLER TOWN AND COUNTRY light

CAUTION!
Do not touch the new bulb with your fingers. Oil
contamination will severely shorten bulb life. If the
bulb comes in contact with an oily surface, clean the
bulb with rubbing alcohol.
Front Park/Turn Signal and Sidemarker Lights
1. Remove the three screws securing the headlight mod-
ule.
418 MAINTAINING YOUR VEHICLE

2. Twist the turn signal socket to remove from the
headlight module and pull bulb from socket.
3. Replace bulb, reinstall socket and then reinstall the
headlight module.Front Fog Light
1. Reach behind the front fascia from under the vehicle.
2. Twist the front fog light bulb to remove from the fog
light housing.
3. Disconnect the electrical connector and replace the
bulb.
CAUTION!
Do not touch the new bulb with your fingers. Oil
contamination will severely shorten bulb life. If the
bulb comes in contact with an oily surface, clean the
bulb with rubbing alcohol.
MAINTAINING YOUR VEHICLE 419
7

Rear Tail, Stop, Turn Signal, Side Marker and
Back-up Lights
1. Raise the liftgate.
2. Remove the two tail light assembly push-in type
fasteners, by prying under the fastener head with a large
flat screwdriver.3. Squeeze the socket assembly tabs to remove it from the
housing.
4. Pull the bulb to remove it from the socket.
5. Replace the bulb, reinstall the socket, and reattach the
light assembly.
420 MAINTAINING YOUR VEHICLE

Center High Mounted Stop Light (CHMSL)
1. Remove the two screws securing the CHMSL.2. Twist the bulb socket to remove from the CHMSL
housing.
3. Pull the bulb out of the socket.
4. Replace the bulb, reinstall the socket and reattach the
CHMSL.
License Light
1. Remove the two lens assembly mounting screws.
2. Pull the bulb out of the socket. Replace the bulb and
reattach the lens assembly.
MAINTAINING YOUR VEHICLE 421
7

Once a Month
•Check tire pressure and look for unusual wear or
damage.
•Inspect the battery and clean and tighten the terminals
as required.
•Check the fluid levels of coolant reservoir, brake
master cylinder and transmission, add as needed.
•Check all lights and all other electrical items for correct
operation.At Each Oil Change
•Change the engine oil filter.
•Inspect the exhaust system.
•Inspect the brake hoses.
•Inspect the CV joints and front suspension compo-
nents.
•Check the automatic transmission fluid level.
•Check the coolant level, hoses, and clamps.
428 MAINTENANCE SCHEDULES
8
M
A
I
N
T
E
N
A
N
C
E
S
C
H
E
D
U
L
E
S

contract, call the manufacturer’s Service Contract Na-
tional Customer Hotline at 1-800-521-9922.
The manufacturer will not stand behind any service
contract that is not the manufacturer’s Service Contract. It
is not responsible for any service contract other than the
manufacturer’s Service Contract. If you purchased a
service contract that is not a manufacturer’s Service
Contract, and you require service after your manufactur-
er’s new vehicle limited warranty expires, please refer to
your contract documents, and contact the person listed in
those documents.
We appreciate that you have made a major investment
when you purchased your new vehicle. Your dealer hasalso made a major investment in facilities, tools, and
training to assure that you are absolutely delighted with
your ownership experience. You’ll be pleased with their
sincere efforts to resolve any warranty issues or related
concerns.
WARRANTY INFORMATION
See your manufacturer’s Warranty Information Booklet
for information on warranty coverage and transfer of
warranty.
IF YOU NEED CONSUMER ASSISTANCE 447
9

Adding Fuel........................... 336
Adding Washer Fluid..................290,393
Additives, Fuel......................... 334
Adjustable Pedals....................... 150
Air Conditioner Maintenance............... 389
Air Conditioning.....................266,271
Air Conditioning Controls................. 266
Air Conditioning Filter.................288,390
Air Conditioning, Operating Tips............ 288
Air Conditioning, Rear Zone.............274,283
Air Conditioning Refrigerant............... 389
Air Conditioning System..........266,271,276,389
Air Conditioning System, Zone Control........ 267
Air Pressure, Tires....................... 319
Airbag................................ 54
Airbag Deployment....................... 66
Airbag Light...................58,59,68,84,202
Airbag Maintenance....................... 68
Airbag, Window......................... 55Alarm Light........................... 203
Alarm System........................... 27
Alignment and Balance................... 326
Alterations/Modifications, Vehicle............. 7
Antenna, Satellite Radio................... 261
Antifreeze (Engine Coolant)...........395,396,422
Disposal............................ 397
Anti-Lock Brake System (ABS).............. 305
Anti-Lock Warning Light.................. 202
Anti-Theft Security Alarm.................. 27
Appearance Care........................ 406
Arming Theft System...................... 28
Ashtray............................... 175
Auto Down Power Windows................ 41
Automatic Dimming Mirror................. 92
Automatic Door Locks...................19,20
Automatic Headlights.................... 140
Automatic Temperature Control............. 276
Automatic Transaxle...................... 299
454 INDEX

Interlock System....................... 300
Reset Mode.......................... 301
Selection Of Lubricant................403,424
Shifting............................. 301
Special Additives...................... 406
Automatic Transmission................... 403
Adding Fluid......................... 404
Fluid and Filter Changes................. 405
Fluid Change......................... 405
Fluid Level Check...................... 404
Fluid Type........................403,424
Ball Joints............................. 391
Battery............................... 387
Gas Caution.......................... 388
Jump Starting......................... 367
Keyless Transmitter Replacement............ 26
Saving Feature (Protection)............... 141
Bearings.............................. 406Belts, Drive............................ 384
Body Mechanism Lubrication............... 392
B-Pillar Location........................ 314
Brake Fluid............................ 424
Brake, Parking.......................... 303
Brake System........................304,400
Anti-Lock........................... 305
Fluid Check.......................... 401
Hoses.............................. 400
Warning Light........................ 200
Brakes.............................304,400
Brake/Transmission Interlock............... 300
Break-In Recommendations, New Vehicle........ 82
Bulb Replacement....................... 417
Bulbs, Light............................ 416
Calibration, Compass..................... 156
Capacities, Fluid........................ 422
INDEX 455
