2005 CHRYSLER PT CRUISER engine

8
5/100 POWERTRAIN WARRANTY
The following powertrain components are covered for 5 years or
100,000 kilometres , whichever occurs first, measured from the
vehicle’s original warranty start date.
Vehicles placed in Police, Taxi, Limousine, Postal or Ambulance
service and all SRT vehicles are excluded from the 5-year or
100,000-kilometre Powertrain Warranty and are covered only under
the 3-year or 60,000-kilometre Basic Warranty.
• Engine – Cylinder block and all internal parts; cylinder head
assemblies; timing case, timing chain, timing belt, gears and
sprockets; vibration damper; oil pump; water pump and housing;
intake and exhaust manifolds; flywheel with starter ring gear; core
plugs; valve covers; oil pan; turbocharger housing and internal
parts; turbocharger wastegate actuator; supercharger; serpentine
belt tensioner; seals and gaskets for listed components only. •
Transmission – Transmission case and all internal parts; torque
converter; drive/flex plate; transmission range switch;
transmission control module; bell housing; oil pan; seals and
gaskets for listed components only.
Note: Manual transmission clutch parts are not covered at any time .
• Front-Wheel Drive – Transaxle case and all internal parts; axle
shaft assemblies; constant velocity joints and boots; differential
cover; oil pan; transaxle speed sensors; transaxle solenoid
assembly; PRNDL position switch; transaxle electronic controller;
torque converter; seals and gaskets for listed components only.
Note: Manual transmission clutch parts are not covered at any time.
5/100 POWERTRAIN WARRANTY
2005 Passenger Car • Minivan • Pacifica

2005 Passenger Car • Minivan • Pacifica
12
WHAT IS NOT COVERED
WHA
T IS NOT COVERED
DAMAGE FROMMISUSE ORACCIDENT
The warranties in this booklet do not cover repairs required due to
fire, accidents, abuse, negligence, objects striking your vehicle,
carrying corrosive materials (such as chemicals, acids and
fertilizers), misuse (such as driving over curbs, overloading,
spinning wheels, etc.), racing or participating in a racing event,
improper disconnection of components, modifying the exhaust
system, tampering or making adjustments which do not comply
with DaimlerChrysler specifications.
Disconnecting, tampering with or changing the reading of the
odometer will void your warranties.
D AMAGE FROMTHEENVIRONMENT
The warranties in this booklet do not cover fading or deterioration
caused by exposure to the elements, or repairs required due to
airborne fallout, acid rain, chemicals, tree sap, insects, bird or insec\
t
droppings, salt, sand, gravel, road hazards, hail, windstorms,
lightning, floods or any other event of nature. Road salt, car washes, scuffs and scratches, and everyday
abrasion from sand and dirt can affect the appearance of a vehicle’s
wheels (steel, chrome and aluminum) and other undercarriage
parts. Some surface corrosion with use is normal; it is not a defect
and is not covered by any warranty.
N ORMAL MAINTENANCE ANDWEAR
The warranties in this booklet do not cover normal
maintenance services, such as oil and filter changes, general
lubrication, tire rotation, engine tune-ups and replacing spark
plugs. Required maintenance services are described in detail in
your Owner’s Manual and herein. The warranties also do not
cover light bulbs and fuses, worn wiper blades, clutch discs, brake
rotors, pads, linings or drums, windshield and rear window,
wheel alignment and wheel balancing (unless they are defective,
see page 7).

2005 Passenger Car • Minivan • Pacifica
16
OTHER THINGS YOU SHOULD KNOW
OTHER THINGS YOU SHOULD KNOW
O
PTIONAL SERVICE CONTRACT
DaimlerChrysler Canada has a service contract specially designed
for most new vehicles, to cover repair costs beyond your vehicle’s
warranty. Protection is available for almost every operating part of
your vehicle, and at reasonable cost.
DaimlerChrysler Canada stands fully behind its service
contracts. Be sure that the contract you buy is a genuine
DaimlerChrysler Service Contract. We are notresponsible for
other companies’ contracts. See page 24 for details on available
service contracts.
A PPEARANCE ITEMS
Defects or damage to sheet metal, paint, trim and other appearance
items are normally found and corrected during new-vehicle
inspection. For your protection, if you find any such defect or
damage, you should tell your selling dealer immediately, because if
the problem worsens due to use and exposure, repairs will not be
covered by any warranty. P
RODUCTION CHANGES
DaimlerChrysler Canada and its dealers reserve the right to make
changes in vehicles built and/or sold at any time without incurring
any obligations to make the same or similar changes on vehicles
which were built and/or sold previously.
E XCHANGE PAR TS
To reduce the amount of time your vehicle is out of service due
to repairs, DaimlerChrysler may offer exchange service on some
parts. Mopar ®or Autopar
®brand exchange parts may be new,
remanufactured, reconditioned or repaired, but all meet
DaimlerChrysler standards and are warranted the same as new
parts. Examples of parts that may be serviced by exchange include
engines, transmissions, instrument clusters, radios, tape and CD
players, speedometers and various electronic modules.

25
1.
POWER TRAIN PLANS*
Powertrain plans complement the factory powertrain warranty by
providing enhanced roadside coverage and car rental allowance if
your vehicle is not drivable and must be kept overnight. Certain
plans also provide additional distance coverage.
Major components covered are:
• engine • transmission • front-wheel drive • rear-wheel dri\
ve
• 4-wheel drive (4x4) • all-wheel-drive vehicles
2. “G OLD ” PLANS *
Each plan provides full mechanical repair protection to non-powertrain
(Gold) components. Certain plansalso provide full mechanical
protection against powertrain component repairs beyond your vehicle’s\
powertrain warranty coverage. Contracts are available with or without
a deductible.
Major components covered are:
• steering • air conditioning • engine cooling and fuel • fr\
ont
suspension • rear suspension • electrical • hydraulic brake
components • anti-lock brakes
* Maximum terms available on new vehicles registered in Canada only. 3.
“G OLD PLUS ” PLANS *
The most complete protection available for your new vehicle is one
of three “Gold Plus” Service Contracts which combines the benefits\
of “Gold” • Mechanical repair coverage for non-powertrain components
plus the most important vehicle maintenance functions • Engine oil and oil filter changes
plus • Tire rotation every other service
plus • “Peace-of-Mind” motoring with Tire Road Hazard
Protection which provides full, or pro-rata, replacement
of the original four tires, or their repair
plus • Rental car allowance for same-day warranty repairs –
your vehicle need not be kept overnight before eligibility
for the rental allowance is met.
OPTIONAL DAIMLERCHRYSLER CANADA SERVICE CONTRACTS
2005 Passenger Car • Minivan • Pacifica – October 1, 2004

MAINTENANCE Scheduled maintenance must be completed to provide the best vehicle
performance and reliability . The limited warranties in the warranty booklet DO NOT COVER repairs
required due to improper maintenance. W e strongly suggest you keep track of scheduled maintenance and
keep receipts or other documents. Use only recommended Mopar Lubricants \
and genuine Mopar Parts.
NOTE: WHERE TIME (MONTHS) AND METRAGE ARE INDICA TED, FOLLOW THE INTERVAL
THA T OCCURS FIRST .
AT EACH STOP FOR FUEL
• Check the engine oil level about 5 minutes after
a fully warmed engine is shut off. Checking the
oil level while the vehicle is on level ground will
improve the accuracy of the oil-level reading.
Add oil only when the level is at or below the
ADD or MIN mark.
• Check the windshield-washer solvent and add
if required.
ONCE A MONTH
• Check the tire pressure and look for unusual
wear or damage.
• Inspect the battery and clean and tighten the
terminals as required.
• Check the fluid levels of coolant reservoir , brake
master cylinder , power steering and transmission
and add as needed.
• Check all the lights and all other electrical items
for correct operation.
• Check and clean wiper blades. Replace if required.
VISUAL INSPECTIONS –
INSPECT FOR SIGNS OF COMPONENT
DETERIORA TION AND PHYSICAL DAMAGE.
There are two maintenance schedules
contained in your Owner’ s Manual. Schedule
“B” best describes operating conditions in
Canada and is the recommended service
schedule. For your convenience, the scheduled
maintenance intervals outlined in this booklet
follow the Severe Service Schedule as described
in your Owner’ s Manual. Schedule “B” is for
vehicles that are operated under one or more of
the following conditions: day or night tempera -
tures are below 0 °C; stop-and-go driving;
extensive engine idling; driving in dusty
conditions; short trips of less than 16.2 km; more than 50% of your driving is at sustained
high speeds during hot weather
, above 32°C;
trailer towing; T axi, Police, or delivery service
(commercial service); off-road or desert driving;
if equipped for and operating with E-85
(ethanol) fuel. Schedule “A” is for vehicles that
are not operated under any of the conditions
listed under Schedule “B.”
The performance of all scheduled service
work is required to maintain your vehicle in
good operating condition. DaimlerChrysler
Canada Inc. reserves the right to deny
warranty coverage if the vehicle has not been
properly maintained. While we do not insist
that such work be performed by factory-
authorized dealers, we strongly recommend
that an authorized Chrysler , Jeep
®or Dodge
Dealer perform this work.
INTRODUCTION

Maintenance Service
Sc hedule “B”
Odometer Reading
Date
Dealer Copy
Remove and attach to Repair Order 26-92-02-01 3N.
2005 Passenger Car • Minivan • Pacifica
Maint enance Service Sc hedule “B”
5,0 00 km
Change engine oil and engine oil filter (or every 3 months).
Inspect and lubricate, as required, all steering and suspension componen\
ts.
Inspect the engine air cleaner filter and replace if necessary (Sebring\
, Pacifica
and Minivan only).
INSPECT THE FOLLOWING:
Inspect the brake hoses.
Check the automatic transaxle fluid level.
Check the manual transaxle fluid level and fill-plug condition (SX 2.0,\
SRT-4
and PT Cruiser only, if equipped).
Check the coolant level, hoses and clamps.
Inspect the exhaust system.
5,0 00 km

DAIMLER CHR YSLER
D EALER STAMP
Signature of authorized DaimlerChrysler Canada dealer
2005 Passenger Car • Minivan • Pacifica

Change engine oil and engine oil filter (or every 3 months).
Inspect and lubricate, as required, all steering and
suspension components.
Inspect the engine air cleaner filter and replace if
necessary (Sebring, Pacifica and Minivan only).
INSPECT THE FOLLOWING:
Inspect the brake hoses.
Check the automatic transaxle fluid level.
Check the manual transaxle fluid level and fill-plug
condition (SX 2.0, SRT-4 and PT Cruiser only,
if equipped).
Check the coolant level, hoses and clamps.
Inspect the exhaust system.
Odometer Reading
Date
Repair Order No.
Maint enance Service Sc hedule “B”
5,0 00 km

2005 Passenger Car • Minivan • PacificaDealer Copy
Remove and attach to Repair Order 26-92-02-01 3N.
Maint enance Service
Sc hedule “B”
Odometer Reading
Date
Maint enance Service Sc hedule “B”
1 0,0 00 km
Change engine oil and engine oil filter (or every 3 months).
Inspect and lubricate, as required, all steering and suspension componen\
ts.
Inspect the engine air cleaner filter and replace if necessary (Sebring\
, Pacifica
and Minivan only).
Rotate tires and check tire pressure.
INSPECT THE FOLLOWING:
Inspect the brake hoses.
Check the automatic transaxle fluid level.
Check the manual transaxle fluid level and fill-plug condition (SX 2.0,\
SRT-4
and PT Cruiser only, if equipped).
Check the coolant level, hoses and clamps.
Inspect the exhaust system.
10,0 00 km
