2005 CHRYSLER PACIFICA spark plugs

MAINTAINING YOUR VEHICLE
CONTENTS

3.5L Engines..........................320

3.8L Engines..........................321

Onboard Diagnostic System—OBDII........322
▫Loose Fuel Filler Cap Message............323

Emissions Inspection And Maintenance
Programs............................323

Replacement Parts......................325

Dealer Service.........................325

Maintenance Procedures..................326▫Engine Oil..........................326
▫Engine Oil Filter......................330
▫Drive Belts—Check Condition And Tension . . 330
▫Spark Plugs.........................331
▫Engine Air Cleaner Filter................331
▫Fuel Filter..........................332
▫Catalytic Converter....................332
▫Maintenance-Free Battery................333
7

Belts should be inspected for evidence of cuts, cracks, or
glazing, and replaced if there is indication of damage
which could result in belt failure. Low generator belt
tension can cause battery failure.
Also check belt routing to make sure there is no interfer-
ence between the belts and other engine components.
Spark Plugs
Spark plugs must fire properly to assure engine perfor-
mance and emission control. New plugs should be in-
stalled at the specified mileage. The entire set should be
replaced if there is any malfunction due to a faulty spark
plug. Malfunctioning spark plugs can damage the cata-
lytic converter. For proper type of replacement spark
plugs, refer to the“Vehicle Emission Control Informa-
tion”label in the engine compartment.
Engine Air Cleaner Filter
Under normal driving conditions, replace the air filter at
the intervals shown on Schedule“A”. If, however, you
drive the vehicle frequently under dusty or severe con-
ditions, the filter element should be inspected periodi-
cally and replaced if necessary at the intervals shown on
Schedule“B”.
WARNING!
The air cleaner can provide a measure of protection
in the case of engine backfire. Do not remove the air
cleaner unless such removal is necessary for repair or
maintenance. Make sure that no one is near the
engine compartment before starting the vehicle with
the air cleaner removed. Failure to do so can result in
serious personal injury.
MAINTAINING YOUR VEHICLE 331
7

RECOMMENDED FLUIDS, LUBRICANTS AND GENUINE PARTS
Engine
Component Fluids, Lubricants and Genuine Parts
Engine Coolant MoparAntifreeze/Coolant 5 Year/100,000 Mile Formula HOAT (Hybrid Or-
ganic Additive Technology) or equivalent
3.5 Liter Engine Oil Use API Certified SAE 10W-30 engine oil, refer to oil viscosity chart for cor-
rect SAE grade meeting DaimlerChrysler Material Standard MS-6395.
3.8 Liter Engine Oil Use API Certified SAE 5W-20 engine oil. Refer to your oil filler cap for cor-
rect SAE grade, meeting DaimlerChrysler Material Standard MS-6395.
Spark Plugs Refer to the Vehicle Emission Control Information label in the engine com-
partment.
Oil Filter, 3.5/3.8 Liter Engines Mopar5281090 or equiv.
Fuel Selection 89 Octane
MAINTAINING YOUR VEHICLE 369
7

Miles 75, 000 78, 000 81, 000 84, 000 87, 000 90, 000
(Kilometers) (120 000) (125 000) (130 000) (134 000) (139 000) (144 000)
Change engine oil and engine oil filter.XXXXX X
Rotate Tires X X X
Inspect the brake linings. X X
Inspect the engine air cleaner filter, replace if
necessary. *XXXX
Replace theengine air cleaner filterXX
Replace thespark plugs.X
Inspect the tie rod ends and boot seals. (Front
& Rear)X
Check thePCV valveand replace if necessary.
Not required if previously changed.*X
Inspect the serpentine drive belt, replace if
necessary.‡XX
Change the All Wheel Drive power transfer
unit fluid. (See the note at the end of this
chart.)XX
SCHEDULE“B”381
8
M
A
I
N
T
E
N
A
N
C
E
S
C
H
E
D
U
L
E
S

Miles 78, 000 84, 000 90, 000 96, 000 100, 000
(Kilometers) (125 000) (134 000) (144 000) (154 000) (160 000)
[Months] [78] [84] [90] [96]
Change engine oil and engine oil filter. X X X X
Rotate Tires X X X X
Inspect the brake linings. X
Inspect the engine air cleaner filter, replace if neces-
sary. *XX XX
Replace theengine air cleaner filter.X
Inspect the tie rod ends and boot seals. (Front &
Rear)X
Check and replace thePCV valve, if necessary.* X
Inspect the serpentine drive belt, replace if neces-
sary.‡X
Replace thespark plugs.X
Flush and replace the engine coolant at 100,000
miles, if not done at 60 months.X
Replace the air conditioning filter. X X
SCHEDULE“A”389
8
M
A
I
N
T
E
N
A
N
C
E
S
C
H
E
D
U
L
E
S

Security Alarm (Theft Alarm)................ 25
Selection of Coolant...................341,369
Sentry Key............................. 12
Sentry Key Programming................... 14
Service Assistance....................... 394
Service Contract......................... 396
Service Engine Soon Light (Malfunction Indicator) . 170
Service Manuals........................ 400
Setting the Clock.....................182,183
Shoulder Belts........................... 33
Signals, Turn.....................166,366,367
Slippery Surfaces, Driving On............... 311
Snow Chains (Tire Chains)................. 284
Snow Tires............................ 285
Spare Tire.......................276,277,304
Spark Plugs............................ 331
Speed Control.......................... 134
Speedometer........................... 166
Starting............................... 248Engine Fails to Start.................... 249
Starting and Operating.................... 248
Starting Procedures...................... 248
Steering
Linkage............................. 337
Power...........................261,336
Shaft Seal............................ 337
Tilt Column.......................... 129
Steering Wheel Mounted Sound System
Controls............................. 218
Storage............................151,362
Storage, Vehicle......................242,362
Storing Your Vehicle...................... 362
Sun Roof.............................. 145
Sun Visor Extension....................... 79
Sunglass Storage........................ 138
Sunroof Maintenance..................... 148
Supplemental Restraint System - Airbag........ 44
Synthetic Engine Oil...................... 330
INDEX 417
10
