Your seat belt system includes lap/
shoulder belts in all seven seating
positions. The f ront seat belts are
also equipped with automatic seat
belt tensioners.The seat belt system
includes an indicator on the
instrument panel and a beeper to
remind you and your passengers to
f asten your belts. The lap/shoulder belts in the center
seat of the second row and both of
the third row seats are equipped with
a detachable anchor that has two
parts: a small latch plate and a
buckle.
The detachable anchor should
normally be latched whenever the
seats-backs are in an upright position.To fasten the belt, insert the latch
plate into the buckle, then tug on the
belt to make sure the buckle is
latched (see page f or how to
properly position the belt).
To unlock the belt, push the red
PRESSbuttononthebuckle.Guide
the belt across your body so that it
retracts completely. Af ter exiting the
vehicle, be sure the belt is out of the
way and will not get closed in the
door.
All seat belts have an emergency
locking retractor. In normal driving,
the retractor lets you move f reely in
your seat while it keeps some
tension on the belt. During a collision
or sudden stop, the retractor
automatically locks the belt to help
restrain your body.
If you turn the ignition to ON (II)
bef ore f astening your seat belt, the
beeper will sound and the indicator
will f lash. If you do not f asten your
seat belt bef ore the beeper stops, the
indicator will stop f lashing but
remain on.
The lap and shoulder belt goes over
your shoulder, across your chest,
and across your hips.
If you continue driving without
f astening your seat belt, the beeper
sounds and the indicator will f lash
again at regular intervals. 16
CONT INUED
Additional Inf ormation About Your Seat Belts
Seat Belt System Components L ap/Shoulder Belt
Driver and Passenger Saf ety
21

Your vehicle’s exhaust contains
carbon monoxide gas. You should
have no problem with carbon
monoxide entering the vehicle in
normal driving if you maintain your
vehicle properly.High levels of carbon monoxide can
collect rapidly in enclosed areas,
such as a garage. Do not run the
engine with the garage door closed.
Even with the door open, run the
engine only long enough to move the
vehicle out of the garage.With the tailgate open, air flow can
pull exhaust gas into your vehicle’s
interior and create a hazardous
condition. If you must drive with the
tailgate open, open all the windows
and set the heating and cooling
system/climate control system as
shown below.
If you must sit in your parked vehicle
with the engine running, even in an
unconf ined area, adjust the heating
and cooling system/climate control
system as f ollows:
Select the f resh air mode.
Select the mode.
Turn the f an on high speed.
Set the temperature control to a
comfortable setting.
The vehicle is raised f or an oil
change.
You notice a change in the sound
of the exhaust.
The vehicle was in an accident
that may have damaged the
underside.
Have the exhaust system inspected
f or leaks whenever:
1.
2.
3.
4.
Carbon Monoxide Hazard
54
Carbon monoxide gas is toxic.
Breathing it can cause
unconsciousness and even kill
you.
Avoid any enclosed areas or
activities that expose you to
carbon monoxide.

The instrument panel has many
indicators to give you important
inf ormation about your vehicle.
If you turn the ignition switch to ON
(II) bef ore f astening your seat belt,
the beeper sounds and the indicator
f lashes. If you do not f asten your
seat belt bef ore the beeper stops, the
indicator stops f lashing but remains
on.
If you continue driving without
f astening your seat belt, the beeper
sounds and the indicator f lashes
again at regular intervals.See page .
The engine can be severely damaged
if this indicator f lashes or stays on
when the engine is running. For
more inf ormation, see page .
If this indicator comes on when the
engine is running, the battery is not
being charged. For more inf ormation,
see page .
This indicator comes on when you
turn the ignition switch to ON (II). It
reminds you and your passengers to
f asten your seat belts. A beeper also
sounds if you have not f astened your
seat belt.
This indicator comes on f or a f ew
seconds when you turn the ignition
switch to ON (II), see page f or
more inf ormation. If it comes on at
any other time, it indicates a
potential problem with your f rontairbags or automatic seat belt
tensioners. This indicator will also
alert you to a potential problem with
your side airbags, passenger’s side
airbag automatic cutoff system,
driver’s seat position sensor, f ront
passenger’s weight sensors, or side
curtain airbags. For complete
inf ormation, see page .
This indicator comes on f or a f ew
seconds when you turn the ignition
switch to ON (II). If it comes on at
any other time, it indicates that the
passenger’s side airbag has
automatically shut off. For more
inf ormation, see page .
273
272
272 32 32
32
Instrument Panel Indicators
Seat Belt Reminder
Indicator
Malf unction Indicator
Lamp
L ow Oil Pressure
Indicator
Charging System
Indicator
Supplemental Restraint
System Indicator Side A irbag Of f
Indicator
60
U.S.
Canada

This indicator has two f unctions:This indicator comes on when you
turn the ignition switch to ON (II).
It is a reminder to check the
parking brake. A beeper sounds if
you try to drive with the parking
brake not fully released. Driving
with the parking brake not fully
released can damage the brakes
and tires. This indicator comes on f or a f ew
seconds when you turn the ignition
switch to ON (II). It will go of f if you
have inserted a properly-coded
ignition key. If it is not a properly-
coded key, the indicator will blink
and the engine will not start (see
page ).
This indicator also blinks several
times when you turn the ignition
switch f rom ON (II) to ACCESSORY
(I) or LOCK (0).
This indicator normally comes on f or
a f ew seconds when you turn the
ignition switch to ON (II), and when
the ignition switch is turned to
START (III). If it comes on at any
other time, there is a problem in the
ABS. If this happens, have your
vehicle checked by your dealer. With
the indicator on, your vehicle still
has normal braking ability but no
anti-lock. For more inf ormation, see
page .
If the indicator remains on after
you have f ully released the
parking brake while the engine is
running, or if it comes on while
driving, it can indicate a problem
in the brake system. For complete
inf ormation, see page .
1.
2.
20980
274
Instrument Panel Indicators
Parking Brake and Brake System
Indicator Anti-lock Brake System
(A BS) Indicator
Immobilizer System
Indicator
Inst rument s and Cont rols
61
U.S. Canada

This indicator monitors the
temperature of the automatic
transmission f luid. The indicator
should come on f or a f ew seconds
when you turn the ignition switch to
ON (II). If it comes on while driving,
it indicates the transmission f luid
temperature is too high. Pull to the
side of the road when it is saf e, shif t
to Park, and let the engine idle until
the indicator goes out.This indicator normally comes on f or
a f ew seconds when you turn the
ignition switch to ON (II). If this
indicator comes on at any other time,
there is a problem in the 4WD
system. Take the vehicle to your
dealer to have it checked.
If the indicator blinks while driving,
pull to the side of the road when it is
saf e, shif t to Park, and let the engine
idle until the indicator goes out.
This indicator reminds you that the
exterior lights are on. It comes on
when the light switch is in either the
or position. This indicator
will also come on when the light
switch is in AUTO and the lights
turn on automatically.
If you turn the ignition switch to
ACCESSORY (I) or LOCK (0)
without turning of f the light switch,
this indicator will remain on. A
reminder chime will also sound when
you open the driver’s door.
U.S. models only
U.S. Models except Touring
Lights On Indicator A/T Temperature
IndicatorVTM-4 Indicator
Instrument Panel Indicators
64
Continuing to drive with the VTM-4
indicator blinking may cause serious
damage to the system.
Continuing to drive with the A/T
Temperature indicator on may cause
serious damage to the transmission.

µ
µ µ
Press and hold this
button for about 1 second to attract
attention; the horn will sound and
the exterior lights will f lash f or about
30 seconds. To cancel panic mode,
press any other button on the remote
transmitter or turn the ignition
switch to ON (II).
Avoid dropping or throwing the
transmitter.
Protect the transmitter from
extreme temperature.
Do not immerse the transmitter in
any liquid.
Press this button once to
lock all doors and the tailgate. Some
exterior and interior lights will f lash.
When you push LOCK twice within 5
seconds, you will hear a beep to
verify that the doors and tailgate are
locked and the security system has
set. This button does not work if any
door or tailgate is not f ully closed. If you lose a transmitter, the
replacement needs to be
reprogrammed by your dealer.
Press this button once
to unlock the driver’s door. Push it
twice to unlock the other doors.
Some exterior and interior lights will
flash twice when you push the
button. If you do not open any door
orthetailgatewithin30seconds,
they will automatically relock.
When you press the UNLOCK
button, the f ront and rear individual
map lights and the cargo area light,
depending on their switch positions,
will come on (see page ). If you
do not open any door or the tailgate,
the lights stay on for about 30
seconds, then go out. If you relock
thedoorsandthetailgatewiththe
remote transmitter before 30
seconds have elapsed, the lights will
go of f immediately. 96
Remote Transmitter
PA NIC
LOCK UNL OCK
Remote Transmitter Care
Inst rument s and Cont rols
83
LED
UNLOCK
BUTTON
PANIC
BUTTON LOCK
BUTTON

Theinsidemirrorcanautomatically
darken to reduce glare. To turn on
this feature, press the button on the
bottom of the mirror. The AUTO
indicator comes on as a reminder.
When it is on, the mirror darkens
when it senses the headlights of a
vehicle behind you, then returns to
normal visibility when the lights are
gone. Press the button again to turn
of f this sensing.
Keeptheinsideandoutsidemirrors
clean and adjusted f or best visibility.
Be sure to adjust the mirrors bef ore
you start driving. Mirrors
Parking Brake, Mirrors
Inst rument s and Cont rols
95
AUTO SWITCH SENSOR INDICATOR
Driving the vehicle with the parking
brake applied can damage the rear
brakes and axles. A beeper will sound
if the vehicle is put into gear with the
parking brake on.

µµ
µ µ
µ
If you are
traveling far from home and can no
longer receive your preset stations,
you can use the auto select feature to
find stations in the local area.
Press the A. SEL button. ‘‘A.SEL’’
f lashes in the display, and the system
goes into scan mode f or several
seconds. It stores the f requencies of
six AM, and twelve FM stations in
the preset buttons.
You will see a ‘‘0’’ displayed if auto
select cannot f ind a strong station f or
every preset button.
If you do not like the stations Auto
Select has stored, you can store
other f requencies on the preset
buttons. Use the TUNE, SEEK, or
SCAN f unction to f ind stations, then
store them in the preset buttons as
described previously. press the
A. SEL button. This restores the
presets you originally set.
Adjust the Balance,
or side-to-side strength of the sound.
Adjust the Fader, or the
f ront-to-back strength of the sound.
AdjusttheTrebleinthe
sound.
Adjust the Bass in the
sound. On models with navigation system,
pushandholdtheTUNEbuttonfor
5 seconds to display inf ormation on
the navigation screen. Press the TUNE knob repeatedly to
display Bass, Treble, Balance, and
Fader settings. Turn the TUNE knob
to adjust the setting. The indicators
on the display will show you the
adjustable range. The system will
return to the audio display in about 5
seconds.To turn of f Auto Select,AUTO SELECT
Adjusting the Sound
BAL ANCE
FADER
TREBLE
BASS
Playing the Radio
Features
115
