Theheadlightswereproperlyaimed
when your vehicle was new. If you
regularly carry heavy items in the
cargo area or pull a trailer,
readjustment may be required.
Adjustment should be done by your
dealer or other qualif ied mechanic.Your vehicle has halogen headlight
bulbs, two on each side. When
replacing a bulb, handle it by its base
and protect the glass from contact
with your skin or hard objects. If you
touch the glass, clean it with
denaturedalcoholandacleancloth.
Remove the electrical connector
fromthebulbbysqueezingthe
connector to unlock the tab, then
slide the connector of f the bulb.
Remove the bulb by turning it
approximately one-quarter turn
counterclockwise.
Open the hood.
1. 2.
3.
CONT INUED
Headlight A iming
Replacing a Headlight Bulb
Lights
Maint enance
245
BULBCONNECTORHalogen headlight bulbs get very hot
when lit. Oil, perspiration, or a scratch
on the glass can cause the bulb to
overheat and shatter.

Turn on the headlights to test the
new bulb.Remove the socket from the
headlight assembly by turning it
one-quarter turn counterclockwise.
To remove a bulb, pull it straight
out of its socket.Install the new bulb into the
socket.
Insert the socket back into the
headlight assembly. Turn it
clockwise to lock it in place.
Testthelightstomakesurethe
new bulb is working.
Push the electrical connector onto
the new bulb. Insert the new bulb into the hole
and turn it one-quarter turn clock-
wise to lock it in place.
1.
2.
4.
5.
6.
3.
4.
5.
Replacing Front Turn Signal/
Parking and Side Marker Light
Bulbs
Lights
246
TAB

Open the tailgate. Use a
screwdriver protected with a cloth
to pry open the two covers.
Remove the two screws and
remove the rear light assembly
f rom the rear pillar.
Determine which of the f our bulbs
is burned out: brake/taillight, turn
signal/hazard lights, side marker
light, or back-up light.Remove the socket by turning it
one-quarter turn counterclockwise.
Remove the burned-out bulb by
pulling it straight out of the socket.Install the new bulb into the
socket.
Push the socket into the light
assembly and turn it clockwise
until it locks.
Testthelightstomakesurethe
new bulb is working.
Install the rear light assembly in
the body. Tighten the two screws.
Snap the covers back into position.
1.
2.
3. 4.
5.6.
7.
8.
9.
Replacing Rear Bulbs
Lights
Maint enance
247

Remove the light assembly cover
by prying caref ully with a cloth-
covered screwdriver in the
notches along the top edge. Then
pivot the cover out and down.
Remove the socket f rom the light
assembly by turning it one-quarter
turn counterclockwise.Pull the bulb straight out of its
socket. Push the new bulb straight
into the socket until it bottoms.
Testthelightstomakesurethe
new bulb is working.
Put the socket back into the light
assembly, and turn it clockwise to
lock it in place.
Place the cover back into the light
assembly. Push it up until it locks
in place.
1. 4.
5.
6.
2. 3.
Lights
Replacing a High-mount Brake
Light Bulb
248

Open the tailgate.
Thetoolsandjackarebehinda
cover in the cargo area on the
driver’s side. Remove the cover by
pushing the top of the cover.Take the tools out of the storage
compartment.
The spare tire is stored
underneath the rear cargo area.
Remove the plastic cover on the
cargo area lining to access the
shaft for the spare tire hoist.
Turn the jack’s end bracket
counterclockwise to loosen it, then
remove the jack.
3.
4.
5.
6.7.
Changing a Flat T ire
262
COVER
COVER

Remove the bracket from the
spare tire. Keep turning the wheel nut
wrench to create slack in the cable.Loosen each wheel nut 1/2 turn
with the wheel nut wrench.
Put the wheel nut wrench on the
hoist shaf t. Turn the wrench
counterclockwise to lower the
spare tire to the ground. 11.
10.
8. 9.
CONT INUED
Changing a Flat T ire
T aking Care of t he Unexpect ed
263
BRACKET
WHEEL NUT WRENCH
The wheel nut wrench supplied with
your vehicle is specially adapted to f it
the hoist shaf t. Do not use any other
tool.

Ú
Place the jack under the jacking
point nearest the tire you need to
change. It is pointed to by a
mark molded into the underside of
the body. Turn the end bracket
clockwise until the top of the jack
contacts the jacking point. Make
sure the jacking point tab is
restinginthejacknotch. Use the extension and the wheel
nut wrench as shown to raise the
vehicle until the f lat tire is of f the
ground.
Remove the wheel nuts, then
remove the f lat tire.
Bef ore mounting the spare tire,
wipe any dirt of f the mounting
surface of the wheel and hub with
a clean cloth. Wipe the hub
carefully;itmaybehotfrom
driving.
12.
13.
14. 15.
Changing a Flat T ire
264
JACKING POINT EXTENSION
BRAKE HUB
WHEEL NUT WRENCH

Slowly turn the wheel nut wrench
clockwisetotakeuptheslackof
the hoist cable. Make sure the
bracketisseatedinthecenter
hole of the spare tire.
Turn the wheel nut wrench
clockwise until the f lat tire rests
against the underbody of the
vehicle and you hear the hoist
click.Store the jack in its holder. Turn
the jack’s end bracket to lock it in
place. Store the tools, and install
the cover.
Turn of f VSA (see page ).
Ref er to Changing a f lat tire with
TPMS (see page ).
22.
23. 26. 25. 24.
212
206
Changing a Flat T ire
266
Loose items can fly around the
interiorinacrashandcould
seriously injure the occupants.
Store the wheel, jack, and tools
securely before driving.
Always raise the spare tire hoist, even
if you are not stowing a tire. If the
hoist is lef t down, it will be damaged
during driving and need to be replaced.
