EAU12900
Front brake lever
The front brake lever is located on the
right handlebar grip. To apply the front
brake, pull this lever toward the handle-
bar grip.
EAU12950
Rear brake lever
The rear brake lever is located on the
left handlebar grip. To apply the rear
brake, pull this lever toward the handle-
bar grip.
EAU12961
Parking brake
This vehicle is equipped with a parking
brake to lock the rear wheel when the
vehicle is parked.
To lock the parking brake
Push the parking brake lever to the left
until it snaps into place.
To unlock the parking brake
Push the parking brake lever back to
the original position.
NOTE:
Be sure to check that the rear wheel
does not move when the parking brake
is applied.
1. Front brake lever
1
1. Rear brake lever1
1. Parking brake lever
1
