8-83
EBU01179
Replacing the headlight bulb
If the headlight bulb burns out, replace the bulb
as follows.
1. Remove the screws holding the headlight
unit to the headlight body.
2. Remove the headlight bulb holder cover,
turn the bulb holder counterclockwise and
remove the defective bulb.
w
The headlight bulb is hot when it is on and
immediately after it is turned off. Wait for the
bulb to cool before touching or removing it.
You can be burned, or a fire could start if the
bulb touches something flammable.
3. Put a new headlight bulb into position and
secure it in place with the bulb holder.
1
1
1. Screw (× 2)1. Vis (× 2)1. Tornillo (×2)
1. Headlight bulb holder
1. Fixation d’ampoule de phare1. Portabombillas del faro
5VJ-9-61-08 3/17/03 4:52 PM Page 8-84

8-85
4. Install the headlight bulb holder cover.
cC
Make sure the bulb holder cover is securely
fitted over the bulb holder and seated
against the reflector.
5. Install the headlight unit assembly by
installing the screws.
6. Adjust the headlight beam if necessary.
5VJ-9-61-08 3/17/03 4:52 PM Page 8-86

10-5
Model YFA1
Shock absorber:
Front Coil spring/Oil damper
Rear Coil spring/Oil damper
Wheel travel:
Front 70 mm
Rear 80 mm
Electrical:
Ignition system C.D.I.
Charging system A.C. Magneto
Battery type/voltage, capacity 12N12C-4A-2/12V, 12Ah
Headlight type: Bulb
Bulb volgate, wattage ×quantity:
Headlight 12V, 25 W/25 W ×1
Tail/brake light 12V, 5 W/21 W ×1
Indicator light:
Neutral 12V, 3.4 W ×1
Reverse 12V, 3.4 W ×1
Fuse: 5A
