2004 TOYOTA MR2 SPYDER How to start the engine

vii2004 MR2 from Feb. ’04 Prod. (OM17518U)
Sequential manual
transmission driving tips
(Models equipped with Sequential Manual
Transmission only)
The sequential manual transmission is a 6 −speed forward/
reverse transmission. With the basics of the traditional
manual transmission, the clutch operation and transmission
shifting is controlled electronically. Unlike automatic trans-
missions, this system does not upshift automatically at the
time of acceleration.
To understand the unique system and operation method of
the sequential manual transmission, read Section 1 −6 on
page 85 thoroughly before driving. For starting procedures,
see “How to start the engine— ” on page 154 in Section 3.
Please refer to the “Important Information For Your
Sequential Manual Transmission” equipped in your vehicle
as well.

102004 MR2 from Feb. ’04 Prod. (OM17518U)
SB12040
KEY NUMBER PLATE
Your key number is shown on the plate.
Keep the plate in a safe place such as
your wallet, not in the vehicle.
If you should lose your keys or if you
need additional keys, duplicates can be
made by a Toyota dealer using the key
number.
We recommend writing down the key num-
ber and storing it in a safe place.
Engine immobilizer system
SB12047
The engine immobilizer system is a
theft prevention system. When you in-
sert the key in the ignition switch, the
transponder chip in the key’s head
transmits an electronic code to the ve-
hicle. The engine will start only when
the electronic code in the chip corre-
sponds to the registered ID code for
the vehicle.
SB12092
The system is automatically set when the
key is removed from the ignition switch.
The indicator light will start flashing to
show the system is set.
If either of the following indicator condi-
tions occurs, contact your Toyota dealer.
The indicator light stays on.
The indicator light does not start flash-
ing when the key is removed from the
ignition switch.
The indicator light flashes inconsistent-
ly.
Inserting the registered key in the ignition
switch automatically cancels the system,
which enables the engine to start. The
indicator light will go off.

112004 MR2 from Feb. ’04 Prod. (OM17518U)
For your Toyota dealer to make you a
new key with built−in transponder chip,
your dealer will need your key number
and master key. However, there is a limit
to the number of additional keys your
Toyota dealer can make for you.
If you make your own duplicate key,
you will not be able to cancel the sys-
tem or start the engine.
NOTICE
Do not modify, remove or disas-
semble the engine immobilizer sys-
tem. If any unauthorized changes or
modifications are made, proper opera-
tion of the system cannot be guaran-
teed.
For vehicles sold in U.S.A.
FCC ID: MOZ RI8FTY
MADE IN. JAPAN
This device complies with Part 15 of the
FCC Rules. Operation is subject to the
following two conditions:
(1) This device may not cause harmful
interference, and (2) this device must
accept any interference received, includ-
ing interference that may cause unde-
sired operation.
CAUTION
Changes or modifications not ex-
pressly approved by the party respon-
sible for compliance could void the
user’s authority to operate the equip-
ment.
Side doors
SB12041
LOCKING AND UNLOCKING WITH KEY
Insert the key into the keyhole and turn
it.
To lock: Turn the key forward.
To unlock: Turn the key backward.
Both the doors lock and unlock simulta-
neously with either side door. In the driv-
er’s door lock, turning the key once will
unlock the driver’s door and twice in suc-
cession will unlock both the doors simulta-
neously.

792004 MR2 from Feb. ’04 Prod. (OM17518U)
(a) Brake System Warning Light
This light comes on in the following cases
when the ignition key is in the “ON” posi-
tion.
When the parking brake is applied...
This light comes on for a few seconds
when the ignition key is turned to the
“ON” position even after the parking brake
is released.
When the brake fluid level is low...
CAUTION
It is dangerous to continue driving
normally when the brake fluid level is
low.
Have your vehicle checked at your
Toyota dealer in the following case:
The light does not come on even if the
parking brake is applied when the igni-
tion key is in the “ON” position.
The light does not come on even if the
ignition key is turned on with the park-
ing brake released.
A warning light turning on briefly during
operation does not indicate a problem.
CAUTION
If either of the following conditions
occurs, immediately stop your vehicle
at a safe place and contact your
Toyota dealer.
The light does not turn off even
after the parking brake is released
while the engine is running.
In this case, the brakes may not
work properly and your stopping
distance will become longer. De-
press the brake pedal firmly and
bring the vehicle to an immediate
stop.
The brake system warning light re-
mains on together with the “ABS”
warning light.
In this case, not only the antilock
brake system will fail but also the
vehicle will become extremely un-
stable during braking.
(b) Driver’s Seat Belt Reminder Light and Buzzer
This light and buzzer remind you to
buckle up the driver’s seat belt.
Once the ignition key is turned to “ON” or
“START”, the reminder light flashes and
buzzer sounds if the driver ’s seat belt is
not fastened. Unless the driver fastens the
belt, the light keeps flashing and the
buzzer stops after about 4 to 8 seconds.
(c) Passenger ’s Seat Belt Reminder Light
This light reminds you to buckle up the
passenger ’s seat belt.
Once the ignition key is turned to “ON” or
“START”, the reminder light flashes if a
passenger sits in the passenger seat and
does not fasten the seat belt. Unless the
passenger fastens the belt, the light stays
flashing. However, if a passenger uses an
additional seat cushion, the light may not
flash even when the seat belt is not
buckled up.
If luggage or other load is placed on the
passenger seat, depending on its weight
and how it is placed on the seat, built −in
sensors in the seat cushion may detect
the pressure, causing the reminder light to
come on.

802004 MR2 from Feb. ’04 Prod. (OM17518U)
(d) Discharge Warning Light
This light warns that the battery is being
discharged.
If it comes on while you are driving, there
is a problem somewhere in the charging
system.
The engine ignition will continue to oper-
ate, however, until the battery is dis-
charged. Turn off the air conditioning,
blower, radio, etc., and drive directly to
the nearest Toyota dealer or repair shop.
NOTICE
Do not continue driving if the engine
drive belt is broken or loose.
(e) Low Engine Oil Pressure WarningLight
This light warns that the engine oil pres-
sure is too low.
If it flickers or stays on while you are
driving, pull off the road to a safe place
and stop the engine immediately. Call a
Toyota dealer or qualified repair shop for
assistance.
The light may occasionally flicker when
the engine is idling or it may come on
briefly after a hard stop. There is no
cause for concern if it then goes out when
the engine is accelerated slightly. The light may come on when the oil level
is extremely low. It is not designed to
indicate low oil level, and the oil level
must be checked using the level dipstick.
NOTICE
Do not drive the vehicle with the
warning light on—even for one block.
It may ruin the engine.
(f) Malfunction Indicator Lamp
This lamp comes on when the ignition
key is turned to the “ON” position and
goes off after the engine starts. This
means that the warning light system is
operation properly.
If the lamp remains on, or the lamp
comes on while driving, first check the
following.
Empty fuel tank
If the fuel tank is empty, refuel immedi-
ately.
Loose fuel tank cap
If the fuel tank cap is loose, securely
tighten it.
These cases are temporary malfunctions.
The malfunction indicator lamp will go off
after taking several driving trips. If the lamp does not go off even after
several trips, contact your Toyota dealer
as soon as possible.
If the fuel tank is not empty or the fuel
tank cap is not loose...
There is a problem somewhere in the
engine, emission control system, elec-
tronic throttle control system, automatic
transmission electrical system or warn-
ing light system itself.
Contact your Toyota dealer as soon as
possible to service the vehicle.
If engine speed does not increase with the
accelerator pedal depressed down, there
may be a problem somewhere in your
electronic throttle control system.
At this time, vibration may occur. Howev-
er, if you depress the accelerator pedal
more firmly and slowly, you can drive your
vehicle at low speeds. Have your vehicle
checked by your Toyota dealer as soon as
possible.
Even if the abnormality of the electronic
throttle control system is corrected during
low speed driving, the system may not be
recovered until the engine is stopped and
the ignition key is turned to “ACC” or
“LOCK” position.

852004 MR2 from Feb. ’04 Prod. (OM17518U)
The sequential manual transmission is a
6−speed forward/reverse transmission.
With the basics of the traditional manual
transmission, the clutch operation and
shifting are controlled electronically. The
system has the following features:
The electronically controlled clutch op-
eration and transmission enables gear
shift by the operation of the selector
lever (or the steering switch) only.
When starting the engine, turn the igni-
tion switch to the “ON” position. While
holding down the brake pedal firmly,
shift the selector lever to the “N” posi-
tion. Make sure that the “N” indicator
in the instrument cluster comes on,
and then start the engine. In case the
selector lever is in a position other
than “N”, or the if the brake pedal is
not held down, the engine cannot be
started.
Sequential manual transmission will
downshift to 2nd or 1st automatically
when the speed is reduced less than
the fixed speed with the shift lever in
“S” position.
To understand this unique system and op-
eration method of the sequential manual
transmission, read this section thoroughly
before driving.
SD16017
The sequential manual transmission has a
shift lock system. This system locks the
selector lever to keep the transmission
gear and the selector lever position in the
same position when the ignition switch is
turned to the “ACC” or “LOCK” position.
However, if the selector lever is locked in
the “S” position, the lever can be moved
to the “+” or “ −” direction, but the gear
will not be actually shifted. (a) Selector lever
“R”: Reverse
“N”: Neutral and engine starting
“S”: Sequential driving
(normal driving)
“+”: Upshifting
Pull the selector lever to the “+”
direction and release it. Every
time the lever is operated, the
transmission is upshifted 1 step in
the order of 1st  2nd  3rd
4th  5th  6th gear.
“”: Downshifting
Push the selector lever to the “− ”
direction and release it. Every
time the lever is operated, the
transmission is downshifted in the
order of 6th  5th  4th  3rd
 2nd  1st gear.
The gear position is displayed on the gear
position indicator. The gear position indica-
tor shows the transmission gear position.
Before starting off, always make sure by
using the gear position indicator that the
gear is engaged in 1st or reverse, then
depress the accelerator pedal.
Sequential manual
transmission

872004 MR2 from Feb. ’04 Prod. (OM17518U)
SB16019a
Transmission shift switches
(d) Upshift and downshift
The sequential manual transmission is not
an automatic transmission (A/T), therefore,
the gears are not shifted automatically. To
shift the transmission, the driver must op-
erate the selector lever to the “+” or “−”
direction, or the steering switch with the
selector lever in the “S” position. When
driving, the driver should shift the gear at
the most appropriate timing. As on the
traditional manual transmission vehicles,
releasing the accelerator pedal a little will
help the transmission to upshift smoothly.
Upshift: Pull the selector lever to the “+”
direction and release it (or push the up-
shift switch on the back of the steering
wheel.) Every time the switch or the lever
is operated, the transmission is upshifted
1 step in the order of 1st  2nd  3rd
 4th  5th  6th gear.
Downshift: Push the selector lever to the
“ − ” direction and release it (or push the
downshift switch on the face of the steer-
ing wheel.) Every time the switch or the
lever is operated, the transmission is
downshifted 1 step in the order of 6th
5th  4th  3rd  2nd  1st gear. In case of operating the selector lever and
switch operation on the steering wheel at
the same time, the selector lever opera-
tion has priority. In case of operating the
two switches of upshifting or downshifting
on the steering wheel at the same time,
it is regarded to operate the switch once.
Also, in case of operating the upshift and
downshift switches on the steering wheel
at the same time, demand is canceled and
no shifting is performed.
To shift down smoothly, the engine
runs fast in some cases. This is done
intentionally by the system and is not
a malfunction.
When the accumulated pressure of the
actuator is consumed due to shifting
operation, and the pressure decreases
to a specified level, the pump motor
starts running again. A motor sound
may be heard from the engine compart-
ment at this time, but it does not indi-
cate malfunction.
When driving down a hill, downshift
and use the engine brakes appropriate-
ly. If necessary, continuous shifting-
down is possible. However, if down-
shifting more than 3 steps continuously,
the gear shifting will take more time.

892004 MR2 from Feb. ’04 Prod. (OM17518U)
CAUTION
Be careful when accelerating, up-
shifting, downshifting or braking on
a slippery surface. Sudden accelera-
tion or engine braking could cause
the vehicle to spin or skid.
To drive down a long or steep hill,
reduce your speed and downshift.
Remember, if you ride the brakes
excessively, they may overheat and
fail.
Do not place the selector lever in
the “N” position while driving.
Otherwise the engine brake may not
work, and you may get involved in
an unexpected accident.
Do not apply the parking brake
while driving. Otherwise, it could
cause a skid and you may get in-
volved in an unexpected accident.
NOTICE
The system will not allow shifting
up or down to a gear that would
cause engine overrevving or un-
derrevving. When engine overrev-
ving occurs, a warning buzzer
(short pulse sound) will sound. In
either case, the demand will be can-
celled.
 If frequently driving at low speed
using a high gear position, a warn-
ing buzzer (long pulse sound) will
sound. Such driving will cause the
reduction of clutch life.
 Frequent downshifting (more than 3
positions continuously) causes the
reduction of transmission life.
 Do not drive with your foot on the
brake pedal. Otherwise, it will cause
the “Sequential manual
transmission” warning light to come
on.
(e) Starting off
1. Start the engine as instructed in “How to start the engine—” on page 154 in
Section 3.
CAUTION
The selector lever can become ex-
tremely hot after parking under the
sun.
2. With your foot holding down the brakepedal, shift the selector lever to the “S”
position properly. When the selector le-
ver is shifted to “S” position, the gear
will be shifted to 1st. On a slippery
surface, it is possible to start off with
the gear in 2nd. To start off with the
gear in 2nd, shift the selector lever
from “N” to “S” position, then operate
the lever to “+” direction. The gear will
be shifted to 2nd. Before starting off,
always make sure that the gear is en-
gaged by the gear position indicator,
then depress the accelerator pedal.
If the gear cannot be engaged to 1st
when the selector lever is shifted from
the “N” to “S” position, the “N” indica-
tor will flash and a warning buzzer
(long pulse sound) will sound. In this
case, the system will re −try shifting or
the driver can operate the selector le-
ver to shift, as follows.
