2004 TOYOTA LAND CRUISER CD player

144
Push the “AM”, “FM”, “TAPE” or “DISC”
button to turn on that mode. The selected
mode turns on directly.
Push these buttons if you want to switch from
one mode to another.
If the tape or disc is not set, the cassette play-
er or compact disc player does not turn on.
You can turn off the cassette player by eject-
ing the cassette tape. If the audio system was
previously off, then the entire audio system
will be turned off when you eject the cassette
tape. If another function was previously play-
ing, it will come on again.The switches for radio, cassette tape and
disc player operation are displayed on the
liquid crystal display. Touch them lightly
and directly on the screen.
The selected switch is highlighted in green.

147
(e) Your cassette player
When you insert a cassette, the exposed tape
should be to the right.
NOTICE
Do not oil any part of the cassette player,
and do not insert anything except a
cassette tape into the slot.
(f) Your automatic changer
UNG603
If your Lexus is equipped with an automatic
changer, it can play selected discs or continu-
ously play all the discs set in the magazine.
When you set discs into the magazine, make
sure they face the correct way. If not, the play-
er will display “DISC CHECK” and the disc
number.
NOTICE
Never try to disassemble or oil any part
of the automatic changer. Do not insert
anything except a compact disc or DVD
video disc into the magazine.
The player is intended for use with 12 cm (4.7
in.) discs only.
Radio operation
(a) Listening to the radio
UNG610
Push these buttons to choose either an
AM or FM station.
“AM”, “FM1”, “FM2” or “FM TYPE” appears on
the display.
VI

151
Cassette tape player
operation
(a) Playing a cassette tape
When you insert a cassette tape, the ex-
posed tape should be to the right.
The player will automatically start when you
insert a cassette tape. At this time, “Tape” ap-
pears on the display.
If a metal or chrome equivalent cassette tape
is put in the cassette player, the player will au-
tomatically adapt to it and “MTL” appears on
the display.
To stop or eject the cassette tape, push the
“
” button.
If a cassette is already in the slot, push the
“TAPE” button.
Dolby
Noise Reduction* feature: If you are
listening to a tape that was recorded with
Dolby
B Noise Reduction, touch the “
”
switch. The “
” switch will be highlighted in
green. Touch the switch again to turn off
Dolby
B NR.
The Dolby NR mode reduces tape noise by
about 10 dB. For best sound reproduction,
play your tapes with this switch on or off ac-
cording to the mode used for recording the
tape.
* Dolby noise reduction manufactured under
license from Dolby Laboratories Licensing
Corporation. “DOLBY” and the double−D
symbol
are trademarks of Dolby Labora-
tories Licensing Corporation.
(b) Manual program selection
Reverse switch: You can reverse the tape by
touching the “” switch or “PROG” but-
ton. The display will show the opposite direc-
tion after reversing the tape. Also if the tape
reaches the end of one side, it is automatically
reversed to the other side.
Fast forward and Rewind switches: Yo u
can fast forward or fast rewind by touching the
“” or “” switch.
To stop the tape while it is fast forwarding,
touch “”, to stop the tape while it is rewind-
ing, touch “”.
If a tape rewinds completely, the cassette
player will stop and then play the same side.
If a tape fast forwards completely, the cas-
sette player will play the other side of the tape
using the auto−reverse feature.
VI

152 Autoreverse feature: After the cassette
player reaches the end of a tape, it automati-
cally reverses and begins to play the other
side, regardless of whether the cassette was
playing or fast forwarding.
(c) Automatic program selection
UNG622
“RPT” switch: The repeat feature automati-
cally replays the current program.
Touch the “RPT” switch while the program is
playing. When the program ends, it will auto-
matically be rewound and replayed. Touch
the switch again to turn off the repeat feature.
There must be at least 3 seconds of blank
space between programs for the repeat fea-
ture to work correctly.
“SKIP” switch: The skip feature allows you
to fast forward past long stretches of blank
tape. This is especially useful at the end of
cassettes.
Touch the “SKIP” switch. The player will au-
tomatically skip any blank portions of 15 se-
conds or more and play the next program. To
cancel it, touch the switch once again.
UNX623
“Automatic program selection” button:
The automatic program selection feature al-
lows you to program your cassette player to
skip forward or backward to locate the song
you want to hear. You can skip up to 9 pro-
grams at a time.
Push this button on the upper side to skip for-
ward. “FF” and the number will appear on the
display. Push the button until the number you
want to skip appears on the display. After that,
the player will automatically skip forward.
When the end of the tape is reached, the play-
er automatically reverses sides and resumes
normal play.
Push this button on the lower side to skip
backward. Push the button until “REW” and
the number you want to skip appear on the
display.

153
If you set “REW 1”, the player will rewind
to the beginning of the current program.
When counting the number of programs
you want to rewind, remember to count the
current program as well. For example, if
you want to rewind to a song that is two be-
fore the song you are listening to, push this
button until “REW 3” appears on the dis-
play.
When the beginning of the tape is reached,
the player automatically resumes normal
play.
There must be at least 5 seconds of blank
space between programs for this feature to
work correctly.
“RPT”, “SKIP” or “Automatic program
selection” features: These features may
not work well with some spoken word, live or
classical recordings.
DVD player operation
The DVD player can play audio CDs, DVD
video discs and video CDs.
For appropriate discs for this paper, see “Car
audio/video system operating hints” on page
169.
For safety reasons, you can enjoy DVD video
discs and video CDs only when the vehicle is
completely stopped with the ignition switch in
the “ACC” or “ON” position and the parking
brake applied. While you are driving, you can
hear audio alone even in the DVD video or
video CD mode.
The DVD player can play the discs labeled as
shown below.
(a) Inserting discs
unx604
1. Pull the lock release lever and open the
console box.
unx605
2. Push this button to eject the magazine.
VI

154
unx606
3. Pull out the tray while pushing the lock
release button.
unx607
4. Put a disc on the tray with its label face
up and push the tray back into the maga-
zine.If the label faces down, the disc cannot be
played. In this case, “DISC CHECK” and disc
number appears on the display.
If a disc which is not playable is inserted,
“DISC CHECK” will also appear on the
screen. For appropriate discs for this player,
see “Car audio/video system operating hints”
on page 169.
unx608a
5. Insert the magazine into the player as
indicated by the arrow ahead on the maga-
zine, close the door and console box.When the magazine is set completely, the
system will be in a “Load” cycle for approxi-
mately 30 seconds while the system
searches for discs in the magazine. Upon
completion of this cycle, the DVD player unit
will be ready to play. If the “DISC” button is
pushed during the “Load” cycle, “LOAD” ap-
pears on the display until the system has
completed the load cycle, after which the sys-
tem will begin normal play.
CAUTION
To reduce the chance of injury in case of
an accident or a sudden stop, always
keep the console box closed while driv-
ing.

155
(b) Playing a disc
ung627
Push the “DISC” button if the magazine is
already loaded in the player.
“DVD CHANGER” appears on the display.
The discs set in the magazine are played con-
tinuously, starting with disc number 1. The
disc number of the disc currently being
played, the track number and the time from
the beginning of the program are shown on
the display.
(c) Selecting a desired disc
On the screen: Touch the desired disc
number.
The selected disc number is highlighted in
green.
The player will start playing the selected disc
from the first track.
On the audio panel: Push the “
” or “”
side of the “DISC” button.
When you release the button, the player will
start playing the selected disc from the first
track.
(d) Operating an audio CD
(i) Playing an audio CD
Push the “AUDIO” button to display this
screen. You can operate the switches and
choose the number of the disc you want to
play. The selected disc is automatically
played.
VI

156 (ii) Selecting a desired track
“TRACK” button: Use for direct access to a
desired track.
Push either side of the “TRACK” button and
hold it until the desired track number appears
on the display. As you release the button, the
player will start playing the selected track from
the beginning.
Fast forward: Touch the “
” switch and
hold it to fast forward the disc. When you re-
lease the switch, the player will resume play-
ing from that position.
Reverse: Touch the “
” switch and hold it
to reverse the disc. When you release the
switch, the player will resume playing.(iii) Searching for a desired track or a disc
Touch the “SCAN” switch.
“Scan” will be highlighted in green. The player
will play the next track for 10 seconds, then
scan again. To select a track, touch the
“SCAN” switch a second time. If the player
reaches the end of the disc, it will continue
scanning at track 1.
After all the tracks are scanned in one pass,
normal play resumes.
Touch the “DISK SCAN” switch.
“DISC SCAN” will be highlighted in green.
The program at the beginning of each disc will
be played for 10 seconds. To continue listen-
ing to the program of your choice, touch the
“DISC SCAN” switch a second time.
After all the audio disc are scanned in one
pass, normal play resumes.(iv) Other functions“RPT” switch: Use it for automatic repeat of
the track you are currently listening to.
Touch the switch while the track is playing.
When the track is finished, the player will auto-
matically go back to the beginning of the track
and play the track again. To cancel it, touch
the switch once again.
“DISC RPT” switch: Use it for automatic re-
peat of the disc you are currently listening to.
Touch the switch while the disc is playing.
When the disc is finished, the player will auto-
matically go back to the beginning of the disc
and play the disc again. To cancel it, touch the
switch once again.
