2004 TOYOTA AVALON fuses

’04 AVALON U (L/O 0408)
284
2004 AVALON from Aug. ’04 Prod. (OM41412U)
Spare fuses
Fuse locations

’04 AVALON U (L/O 0408)
288
2004 AVALON from Aug. ’04 Prod. (OM41412U)
Here is a list of parts and tools you will
need to perform doityourself mainte-
nance. Remember all Toyota parts are de-
signed in metric sizes, so your tools must
be metric.
CHECKING THE ENGINE OIL LEVEL
Parts (if level is low):
“Toyota Genuine Motor Oil” or equiva-
lent
See Section 72 for details about en-
gine oil selection.
Tools:
Rag or paper towel
Funnel (only for adding oil)
CHECKING THE ENGINE COOLANT
LEVEL
Parts (if level is low):
“Toyota Super Long Life Coolant” or
similar high quality ethylene glycol
based nonsilicate, nonamine, nonni-
trite, and nonborate coolant with long
life hybrid organic acid technology.
“Toyota Super Long Life Coolant” is a
mixture of 50% coolant and 50% deion-
ized water (for the U.S.A.) or 55%
coolant and 45% deionized water (for
Canada). Tools:
Funnel (only for adding coolant)
CHECKING BRAKE FLUID
Parts (if level is low):
SAE J1703 or FMVSS No.116 DOT 3
brake fluid
Tools:
Rag or paper towel
Funnel (only for adding fluid)
CHECKING POWER STEERING FLUID
Parts (if level is low):
Automatic transmission fluid
DEXRON II or III
Tools:
Rag or paper towel
Funnel (only for adding fluid)
CHECKING BATTERY CONDITION
Tools:
Warm water
Baking soda
Grease
Conventional wrench (for terminal
clamp bolts) CHECKING AND REPLACING FUSES
Parts (if replacement is necessary):
Fuse with same amperage rating as
original
ADDING WASHER FLUID
Parts:
Water
Washer fluid containing antifreeze
(for winter use)
Tools:
Funnel
REPLACING LIGHT BULBS
Parts:
Bulb with same number and wattage
rating as original (See charts in “Re-
placing light bulbs” in Section 73.)
Tools:
Screwdriver
Parts and tools

’04 AVALON U (L/O 0408)
306
2004 AVALON from Aug. ’04 Prod. (OM41412U)
DOITYOURSELF MAINTENANCE
Electrical components
Checking battery condition307
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Battery recharging precautions 308
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Checking and replacing fuses 309
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Adding washer fluid 310
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . \
. . . . .
Replacing light bulbs 310
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . \
. . . .
SECTION 7 3

’04 AVALON U (L/O 0408)
309
2004 AVALON from Aug. ’04 Prod. (OM41412U)
Ty p e AGood Blown
Ty p e B
Good
Good Blown
Blown
Ty p e C
If the headlights or other electrical
components do not work, check the
fuses. If any of the fuses are blown,
they must be replaced.
See “Fuse locations” in Section 71 for
locations of the fuses.
Turn the ignition switch and inoperative
component off. Pull the suspected fuse
straight out and check it.
Determine which fuse may be causing the
problem. The lid of the fuse box shows
the name of the circuit for each fuse. See
Section 8 for the functions controlled by
each circuit. Type A fuses can be pulled out by the
pullout tool. The location of the pullout
tool is shown in the illustration.
If you are not sure whether the fuse has
blown, try replacing the suspected fuse
with one that you know is good.
If the fuse has blown, push a new fuse
into the clip.
Only install a fuse with the amperage rat-
ing designated on the fuse box lid.
If you do not have a spare fuse, in an
emergency you can pull out the “RADIO”
or “A/C” fuse, which may be dispensable
for normal driving, and use it if its
amperage rating is the same.
If you cannot use one of the same amper-
age, use one that is lower, but as close
to the rating as possible. If the amperage
is lower than that specified, the fuse
might blow out again but this does not
indicate anything wrong. Be sure to get
the correct fuse as soon as possible and
return the substitute to its original clip.
It is a good idea to purchase a set of
spare fuses and keep them in your ve-
hicle for emergencies.
Checking and replacing fuses

’04 AVALON U (L/O 0408)
318
2004 AVALON from Aug. ’04 Prod. (OM41412U)
SPECIFICATIONS
Specifications
Dimensions and weights319
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . \
Engine 319
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . \
. . . . . . . . . . . . . . . .
Fuel 320
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . \
. . . . . . . . . . . . . . . . . . .
Service specifications 320
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . \
. . .
Tires 322
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . \
. . . . . . . . . . . . . . . . . .
Fuses 323
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . \
. . . . . . . . . . . . . . . . .
SECTION 8

’04 AVALON U (L/O 0408)
323
2004 AVALON from Aug. ’04 Prod. (OM41412U)
Engine compartment
Engine compartment
Fuses (type A)1. HEAD RH UPR 10 A: No circuit
2. HEAD LH UPR 10 A: No circuit
3. HEAD RH LWR 15 A: Righthand
headlight (low beam)
4. HEAD LH LWR 15 A: Lefthand head-
light (low beam)
5. ABS NO.4 5 A: Vehicle stability control
system
6. DRL 7.5 A: Daytime running light sys-
tem
7. SPARE 30 A: Spare fuse
8. SPARE 15 A: Spare fuse
Instrument panel
9. SPARE 25 A: Spare fuse
10. SPARE 10 A: Spare fuse
11. ALTS 5 A: Charging system
12. DCC 30 A: “DOME”, “ECUB” and
“RADIO” fuses
13. SECURITY 10 A: Theftdeterrent sys-
tem
14. HAZ 15 A: Turn signal lights
15. A/F 25 A: Air/fuel sensor
16. DOOR NO.2 15 A: Power door lock
system
17. HORN 10 A: Horn, theftdeterrent sys-
tem
Fuses

’04 AVALON U (L/O 0408)
325
2004 AVALON from Aug. ’04 Prod. (OM41412U)
47. DOME 7.5 A: Interior lights, front per-
sonal lights, door courtesy lights, igni-
tion switch light, vanity lights, garage
door opener, open door warning light,
illuminated entry system, rear pers onal
lights, automatic light control system,
trunk light, wireless remote control sys-
tem, multiplex communication system
48. OPNER 5 A: No circuit
49. RL P/W 20 A: Power window (for rear
left passenger)
50. RR P/W 20 A: Power window (for rear
right passenger)
51. WIP 25 A: Windshield wipers and
washer
52. ECUIG NO.2 10 A: Antilock brake
system, cruise control system, multiin-
formation display, theft deterrent sys-
tem, vehicle stability control system,
meters, multiplex communication sys-
tem
53. CIG 15 A: Cigarette lighter
54. DOOR NO.1 25 A: Theft deterrent sys-
tem, trunk opener, multiplex commu-
nication system
55. SUN ROOF 30 A: Electric moon roofFuses (type B)
56. AM1 40 A: Multiport fuel injection sys-
tem/sequential multiport fuel injection
system
57. HTR 50 A: Air conditioning system
58. CDS 30 A: Electric cooling fans
59. RDI 30 A: Electric cooling fans
60. MAIN 40 A: Starter system
61. DEF 40 A: Rear window defogger,
noise filter
62. PWR SEAT 30 A: Power seats
Fuses (type C)
63. ABS 60 A: Antilock brake system,
“ABS NO.4” fuse
64. ALT 120 A: “HTR”, “A/C”, “ABS NO.2”,
“ABS NO.3”, “RDI”, “CDS”, “AM1”,
“ABS” and “ABS NO.4” fuses
