’04 AVALON U (L/O 0408)
186
2004 AVALON from Aug. ’04 Prod. (OM41412U)
This air conditioning system has a high
efficient air refiner filter which helps
eliminate dust and pollen, thereby in-
creasing your driving comfort.
The air conditioning filter is set behind
the glove box.
The air conditioning filter may clog after
long use. The filter may need to be re-
placed if the air flow of the air conditioner
and heater experiences extreme reductions
in operating efficiency, or if the windows
begin to fog up easily.Perform filter replacement periodically.
Period of replacement (expected):
For U.S.A.—Every 30000 miles
For Canada—Every 16000 km
NOTE: This is the normal maintenance
period. This may change depending on
operating conditions.
If the symptoms of air conditioning
efficiency problems occur, contact your
Toyota dealer to have the filter checked
and replaced.
(Actual replacement time: Less than 10
minutes approximately)
NOTICE
Do not try to replace the air condi-
tioning filter by yourself. Doing so
may damage the vehicle.
INFORMATION
The air filter should be installed prop-
erly in position. The use of air condi-
tioning with the air filter removed
may cause deteriorated dustproof per-
formance and then affect air condi-
tioning performance.

’04 AVALON U (L/O 0408)
230
2004 AVALON from Aug. ’04 Prod. (OM41412U)
Ti r e relat ed ter mMeaning
Accessory weight
the combined weight (in excess of those standard items which may be
replaced) of automatic transmission, power steering, power brakes, power
windows, power seats, radio, and heater, to the extent that these items
are available as factoryinstalled equipment (whether installed or not)
Cold tire inflation pressure
tire inflation pressure when the vehicle has been parked for at least 3
hours or more, or it has not been driven more than 1.5 km or 1 mile
under that condition
Curb weight
the weight of a motor vehicle with standard equipment including the
maximum capacity of fuel, oil, and coolant, and, if so equipped, air
conditioning and additional weight optional engine
Intended outboard sidewall
(A) the sidewall that contains a whitew all, bears white lettering or bears
manufacturer, brand, and/or model name molding that is higher or
deeper than the same molding on th e other sidewall of the tire, or
(B) the outward facing sidewall of an asymmetrical tire that has a particular side that must always face outward when mounted on a vehicle
Maximum inflation pressurethe maximum cold inflation pressure to which a tire may be inflated and it
is shown on the sidewall of the tire
Maximum loaded vehicle weight
t he sum of —
(a) curb weight;
(b) accessory weight;
(c) vehicle capacity weight; and
(d) production options weight
—Glossary of tire terminology

’04 AVALON U (L/O 0408)
274
2004 AVALON from Aug. ’04 Prod. (OM41412U)
First vacuum over the upholstery to re-
move loose dirt. Then, using a sponge or
soft cloth, apply the soap solution to the
vinyl. After allowing it to soak in for a few
minutes to loosen the dirt, remove the dirt
and wipe off the soap with a clean damp
cloth. If all the dirt do not come off, re-
peat the procedure. Commercial foaming
type vinyl cleaners are also available
which work well. Follow the manufacturer ’s
instructions.
NOTICE
Do not use solvent, thinner, gasoline
or window cleaner on the interior.
Carpets
Use a good foamtype shampoo to
clean the carpets.
Begin by vacuuming thoroughly to remove
as much dirt as possible. Several types of
foam cleaners are available; some are in
aerosol cans and others are powders or
liquids which you mix with water to pro-
duce a foam. To shampoo the carpets,
use a sponge or brush to apply the foam.
Rub in overlapping circles.Do not apply water—the best results are
obtained by keeping the carpet as dry as
possible. Read the shampoo instructions
and follow them closely.
Seat belts
The seat belts may be cleaned with
mild soap and water or with lukewarm
water.
Use a cloth or sponge. As you are clean-
ing, check the belts for excessive wear,
fraying, or cuts.
NOTICE

Do not use dye or bleach on the
belts—it may weaken them.
 Do not use the belts until they be-
come dry.
Windows
The windows may be cleaned with any
household window cleaner.
NOTICE
When cleaning the inside of the rear
window, be careful not to scratch or
damage the heater wires or connec-
tors.
Air conditioning control panel, car au-
dio, instrument panel, console panel,
and switches
Use a soft damp cloth for cleaning.
Soak a clean soft cloth in water or luke-
warm water then lightly wipe off dirt.
NOTICE
Do not use organic substances (sol-
vents, kerosene, alcohol, gasoline,
etc.) or alkaline or acidic solutions.
These chemicals can cause discol-
oring, staining or peeling of the
surface.
 If you use cleaners or polishing
agents, make sure their ingredients
do not include the substances men-
tioned above.
 If you use a liquid car freshener, do
not spill the liquid onto the ve-
hicle’s interior surfaces. It may con-
tain the ingredients mentioned
above. Immediately clean any spill
using the method mentioned above.

’04 AVALON U (L/O 0408)
324
2004 AVALON from Aug. ’04 Prod. (OM41412U)
18. AM2 10 A: SRS airbag system, multi-
port fuel injection system/sequential
multiport fuel injection system, starter
system, charging system, air/fuel sen-
sor, fuel pump
19. EFI NO.2 7.5 A: Multiport fuel injection
system/s equential multiport fuel injec-
tion system, air flow meter, oxygen
sensor, evaporative emission control
system, throttle positi oner control sys-
tem, engine control system
20. ABS NO.3 25 A: Antilock brake sys-
tem
21. ABS NO.2 25 A: Vehicle stability con-
trol system
22. EFI NO.1 15 A: Multiport fuel injection
system/s equential multiport fuel injec-
tion system, fuel pump
23. IG2 15 A: Multiport fuel injection sys-
tem/sequential multiport fuel injection
system
24. HEAD LH UPR 10 A: Lefthand head-
light (high beam), high beam indicator
light
25. HEAD RH UPR 10 A: Righthand
headlight (high beam)
26. ECUIG NO.1 5 A: Electric cooling
fans 27. ECUB 7.5 A:
Air conditioning system,
theft deterrent system, power seats,
meters, power windows (for driver and
front passenger), multiplex communica-
tion system
28. TAIL 10 A: Parking lights, license plate
lights, tail lights, rear side marker
lights, rear light failure warning light,
engine control system
29. SEAT HTR 20 A: Seat heaters
30. FR P/W 20 A: Power window (for front
passenger)
31. GAUGE NO.1 10 A: Vehicle stability
control system, rear window defogger,
cruise control system, shift lock sys-
tem, antilock brake system, auto anti
glare inside rear view mirror, automatic
light control system, power seats, rear
light failure warning light, automatic
transmission indicator lights, power out-
let, power window (for driver), brake
system warning light, electric moon
roof
32. HTR 10 A: Air conditioning system
33. FOG 15 A: Front fog lights
34. TURN 7.5 A: Turn signal lights
35. A/C 10 A: Air conditioning system
36. RADIO 15 A: Audio system, multiin-
formation display 37. PANEL 5 A:
Gauges and meters, audio
system, cigarette lighter, air c ondition-
ing system, emergency flasher, elec-
tronically controlled automatic transmis-
sion system, power rear view mirrors,
multiinformation display, glove box
light, instrument panel lights, instrument
panel light control, power outlet
38. FL P/W 25 A: Power window (for driv-
er)
39. PWR OUTLET NO.1 15 A: Power out-
let (ACC)
40. ECUACC 5 A: Audio system, power
rear view mirrors, multiinformation dis-
play, shift lock system, multiplex com-
munication system
41. SRSACC 10 A: SRS airbag system
42. MIR HTR 10 A: Outside rear view mir-
ror defoggers, engine control system
43. PWR OUTLET NO.2 15 A: Power out-
let (IG)
44. GAUGE NO.2 10 A: Backup lights
45. OBDII 7.5 A: Onboard diagnosis sys-
te

m
46. STOP 15 A: Stop lights, high mounted
stoplight, antilock brake system, shift
lock system, cruise control system, ve-
hicle stability control system, engine
control system
