At times you may notice a decrease in range. This is
normal for any remote keyless entry system. If the
transmitter does not work or if you have to stand closer
to your vehicle for the transmitter to work, try this:
Check the distance. You may be too far from your
vehicle. You may need to stand closer during
rainy or snowy weather.
Check the location. Other vehicles or objects may
be blocking the signal. Take a few steps to the
left or right, hold the transmitter higher, and
try again.
Check to determine if battery replacement or
resynchronization is necessary. See “Battery
Replacement” and “Resynchronization” under
Remote Keyless Entry System Operation on
page 2-5.
If you are still having trouble, see your Saturn
retailer or authorized service provider for service.
Remote Keyless Entry System
Operation
With this feature, you can lock and unlock the doors or
the trunk from about 26 feet (8 m) away using the
remote keyless entry transmitter supplied with your
vehicle.
LOCK:Press this button
on the remote keyless
entry transmitter to lock the
doors. This also arms
the theft-deterrent system.
See “Theft-Deterrent
System” following for
information on arming the
theft-deterrent system.
Your vehicle can be programmed so that the parking
lamps will ash and/or the horn will sound when you lock
the doors with the remote keyless entry transmitter.
See your retailer for more information on programming
this feature.
2-5
ProCarManuals.com

UNLOCK: Press this button on the remote keyless
entry transmitter to unlock the driver’s door. This also
disarms the theft-deterrent system. See “Theft-Deterrent
System” following for information on disarming the
theft-deterrent system. Press the button again within
5 seconds to unlock the rest of the doors.
L(Panic Alarm):Press the button with the horn
symbol when the ignition is turned off. The horn
will sound and the parking lamps and dome lamp will
ash for up to two minutes. To stop the panic alarm,
press this button again.
V(Trunk):Press this button to open the trunk or
liftgate. The trunk or liftgate will not open when this
button is pressed if the vehicle is moving.
Theft-Deterrent System
The remote keyless entry transmitter is used to
arm/disarm the theft-deterrent system. Your vehicle’s
theft-deterrent system can be programmed to three
different modes.
Active Arming:The system will arm when the lock
button on the remote keyless entry transmitter is
pressed. The system will disarm when the unlock button
is pressed.Passive Arming:The system will arm itself one minute
after the ignition is turned off and the driver’s door
has been opened and closed. If the lock button on the
transmitter is pressed before the minute has passed, the
system will arm immediately. The system will disarm
when the unlock button is pressed.
Security System Disable:The system will not arm.
To change the mode that your vehicle is programmed to,
do the following:
1. Turn the ignition to RUN or ACC.
2. Press the panic alarm button on the transmitter
slowly four times within ve seconds.
3. You must complete one of the following within three
seconds to change the mode.
To select the active arming mode, press the lock
button on the transmitter.
To select the passive arming mode, press the
trunk release button on the transmitter.
To select the security system disable mode,
press the unlock button on the transmitter.
2-6
ProCarManuals.com

A chime will sound once the mode has been selected.
If you accidentally set off the alarm when entering/exiting
the vehicle, you can shut it off by pressing any button
on the remote keyless entry transmitter other than
the panic alarm button.
If you hear three horn chirps when you press the unlock
button on the transmitter, that means the vehicle’s
alarm was triggered while you were away.
Matching Transmitter(s) to Your
Vehicle
Each remote keyless entry transmitter is coded to
prevent another transmitter from unlocking your vehicle.
If a transmitter is lost or stolen, a replacement can
be purchased through your retailer. Remember to bring
any remaining transmitters with you when you go to
your retailer. When the retailer matches the replacement
transmitter to your vehicle, any remaining transmitters
must also be matched. Once your retailer has coded the
new transmitter, the lost transmitter will not unlock
your vehicle. Each vehicle can have a maximum of four
transmitters matched to it.
Battery Replacement
Under normal use, the battery in your remote keyless
entry transmitter should last about four years.
You can tell the battery is weak if the transmitter won’t
work at the normal range in any location. If you have
to get close to your vehicle before the transmitter works,
it’s probably time to change the battery.
Notice:When replacing the battery, use care not to
touch any of the circuitry. Static from your body
transferred to these surfaces may damage the
transmitter.
1. Use a at thin object to pry open the transmitter.
2-7
ProCarManuals.com

Power Door Locks
Press the bottom half of
the switch on either front
door to lock all of the
doors. Push the top half of
the switch to unlock all
of the doors. The unlocked
door indicators on the
manual door lock pins will
be hidden when the
doors are locked.
Delayed Locking
A chime will sound three times to indicate a door is
open when you try to lock the doors with the remote
keyless entry transmitter or the power door lock switch.
The doors will not lock, and the remote keyless entry
system will not arm until all the doors are closed and ve
seconds have passed.
The delayed locking feature can be overridden by
pressing the lock button on the remote keyless entry, or
the door lock switch, a second time. The doors will lock
immediately and when all doors are closed the remote
keyless entry system will arm after 30 seconds.
To get the horn to chirp if a door was open during the
arming process, you must press the lock button on your
transmitter twice after the doors are closed.
2-10
ProCarManuals.com

Programmable Automatic Door
Locks
With this feature, all the doors will lock as the transaxle
is shifted out of PARK (P) if the ignition key is in the
RUN position and all doors are closed. The doors
will automatically lock if the vehicle is going faster than
3 mph (5 km/h).
In the following two situations, when a door is opened,
all doors will lock again:
The brake pedal is applied, a door is opened and
then closed, and the brake pedal is released.
A door is opened and closed without the brake
pedal applied while the vehicle is moving faster than
3 mph (5 km/h).
When programmed, all doors will unlock when the key
is removed from the ignition.
The programmable unlocking feature can be
programmed on or off by turning the ignition key to RUN
and pressing the unlock power door lock switch for
eight seconds. The horn will chirp once when this
feature is on and will chirp twice when it is off.
Rear Door Security Locks
Your vehicle has rear door security locks that prevent
passengers from opening the rear doors from the inside.
The rear door security locks
are located on the inside
edge of each rear door.
You must open the rear
doors to access them.
To set the secondary locks, do the following:
1. Insert the key into the lock next to the rear door
security lock label and turn it clockwise for the
driver’s side and counterclockwise for the
passenger’s side.
2. Close the door.
2-11
ProCarManuals.com

Instrument Panel Overview...............................3-2
Hazard Warning Flashers................................3-4
Other Warning Devices...................................3-5
Horn.............................................................3-5
Tilt Wheel.....................................................3-5
Turn Signal/Multifunction Lever.........................3-6
Windshield Wiper Lever...................................3-8
Cruise Control..............................................3-10
Exterior Lamps.............................................3-13
Interior Lamps..............................................3-15
Accessory Power Outlets...............................3-16
Ashtrays and Cigarette Lighter........................3-17
Climate Controls............................................3-17
Climate Control System.................................3-17
Automatic Climate Control System...................3-20
Outlet Adjustment.........................................3-24
Passenger Compartment Air Filter...................3-24
Warning Lights, Gages, and Indicators............3-25
Instrument Panel Cluster................................3-26
Speedometer and Odometer...........................3-27
Tachometer.................................................3-27
Safety Belt Reminder Light.............................3-28
Air Bag Readiness Light................................3-28
Battery Warning Light....................................3-29
Brake System Warning Light..........................3-30
Anti-Lock Brake System Warning Light.............3-31Traction Control System (TCS) Warning Light......3-32
Engine Coolant Temperature Warning Light......3-32
Engine Coolant Temperature Gage..................3-33
Low Coolant Warning Light............................3-33
Malfunction Indicator Lamp.............................3-34
Oil Pressure Light.........................................3-37
Change Engine Oil Light................................3-38
Security Light...............................................3-38
Reduced Engine Power Light.........................3-38
Daytime Running Lamps Indicator Light...........3-39
Low Washer Fluid Warning Light.....................3-39
Trunk Ajar Light............................................3-39
Service Vehicle Soon Light............................3-39
Fuel Gage...................................................3-40
Low Fuel Warning Light.................................3-40
Audio System(s).............................................3-41
Setting the Time...........................................3-41
AM-FM Radio...............................................3-42
Radio with CD..............................................3-45
Radio with Cassette and CD..........................3-50
Rear Seat Entertainment System....................3-59
Theft-Deterrent Feature..................................3-69
Radio Reception...........................................3-71
Care of Your Cassette Tape Player.................3-72
Care of Your CDs and DVDs.........................3-73
Care of Your CD and DVD Player...................3-73
Fixed Mast Antenna......................................3-73
Section 3 Instrument Panel
3-1
ProCarManuals.com

The main components of the instrument panel are the
following:
A. Air Outlets. SeeOutlet Adjustment on page 3-24.
B. Turn Signal/Multifunction Lever. SeeTurn
Signal/Multifunction Lever on page 3-6.
C. Cruise Control (If Equipped). SeeCruise Control on
page 3-10.
D. Horn. SeeHorn on page 3-5.
E. Instrument Panel Cluster. SeeInstrument Panel
Cluster on page 3-26.
F. Windshield Wiper Lever. SeeWindshield Wiper
Lever on page 3-8.
G. Heated Seats (If Equipped). SeeHeated Seats on
page 1-5.
H. Fog Lamps (If Equipped). SeeInterior Lamps on
page 3-15.I. Hazard Warning Flasher Button. SeeHazard
Warning Flashers on page 3-4.
J. Traction Control. SeeTraction Control System (TCS)
Warning Light on page 3-32.
K. Audio System. SeeAudio System(s) on page 3-41.
L. Trunk Release Button/Dimmer Switch. See
Trunk/Liftgate on page 2-13/Interior Lamps on
page 3-15.
M. Hood Release. SeeHood Release on page 5-10.
N. Climate Control. SeeClimate Control System
on page 3-17.
O. Automatic Transaxle Shift Lever. SeeAutomatic
Transaxle Operation on page 2-23.
P. Power Windows. SeePower Windows on page 2-17.
Q. Glove Box. SeeGlove Box on page 2-41.
3-3
ProCarManuals.com

Other Warning Devices
If you carry reective triangles, you can set one up at
the side of the road about 300 feet (100 m) behind your
vehicle.
Horn
You can sound the horn by pressing the center of your
steering wheel.
Tilt Wheel
Your vehicle may have a tilt wheel which allows you to
adjust the steering wheel before you drive. You can
raise it to the highest level to give your legs more room
when you exit and enter the vehicle.
The lever that allows you to tilt the steering wheel is
located on the left side of the steering column.To tilt the wheel, hold the
wheel and pull the lever.
Then, move the wheel to a
comfortable position and
release the lever to
lock the wheel in place.
3-5
ProCarManuals.com
