2004 SATURN L-SERIES lock

Dinghy Towing
You may dinghy tow your vehicle from the front following
these steps:
1. Set the parking brake.
2. Turn the ignition key to ACC to unlock the steering
wheel.
3. Shift your transaxle to NEUTRAL (N).
4. Open the lid on the underhood fuse block and
remove the IGN 0/3/CR and IGN 1/2 fuses.
Refer to the underside of the underhood fuse block
cover for specic fuse locations.
5. Close the lid on the underhood fuse block and store
the two fuses in a safe place.6. Close the hood.
7. Release the parking brake.
Once you have reached your destination replace the
IGN 0/3/CR and IGN 1/2 fuses.
Notice:If you exceed 65 mph (110 km/h) while
towing your vehicle, it could be damaged. Never
exceed 65 mph (110 km/h) while towing your vehicle.
Notice:Towing your vehicle from the rear could
damage it. Also, repairs would not be covered by the
warranty. Never have your vehicle towed from
the rear.
4-33
ProCarManuals.com

Hitches
It’s important to have the correct hitch equipment.
Crosswinds, large trucks going by and rough roads are
a few reasons why you will need the right hitch. Here
are some rules to follow:
The rear bumper on your vehicle is not intended for
hitches. Do not attach rental hitches or other
bumper-type hitches to it. Use only a
frame-mounted hitch that does not attach to the
bumper.
Will you have to make any holes in the body of
your vehicle when you install a trailer hitch? If
you do, then be sure to seal the holes later when
you remove the hitch. If you don’t seal them, deadly
carbon monoxide (CO) from your exhaust can get
into your vehicle. SeeEngine Exhaust on
page 2-31. Dirt and water can, too.
Safety Chains
You should always attach chains between your vehicle
and your trailer. Cross the safety chains under the
tongue of the trailer so that the tongue will not drop to
the road if it becomes separated from the hitch.
Instructions about safety chains may be provided by the
hitch manufacturer or by the trailer manufacturer.
Follow the manufacturer’s recommendation for attaching
safety chains and do not attach them to the bumper.
Always leave just enough slack so you can turn
with your rig. And, never allow safety chains to drag on
the ground.
Trailer Brakes
Because your vehicle has anti-lock brakes, do not try to
tap into your vehicle’s hydraulic brake system. If you
do, both brake systems will not work well, or at all.
Be sure to read and follow the instructions for the trailer
brakes so you’ll be able to install, adjust and maintain
them properly.
4-43
ProCarManuals.com

Filling Your Tank
{CAUTION:
Fuel vapor burns violently and a fuel re can
cause bad injuries. To help avoid injuries to
you and others, read and follow all the
instructions on the pump island. Turn off your
engine when you are refueling. Do not smoke
if you are near fuel or refueling your vehicle.
Keep sparks, ames and smoking materials
away from fuel. Do not leave the fuel pump
unattended when refueling your vehicle — this
is against the law in some places. Keep
children away from the fuel pump; never let
children pump fuel.The fuel ller cap is
located behind a hinged
door on the passenger’s
side of your vehicle. It
is tethered to the door to
prevent loss while
refueling. Make sure that
water, snow, and dirt
are kept away from the
ller cap and ller
pipe nozzle.
To remove the fuel cap, turn it slowly to the left
(counterclockwise). It will require about 1/2 of a turn to
remove the cap. The fuel cap has a spring in it; if
you let go of the cap too soon, it will spring back to the
right (clockwise).
{CAUTION:
If you get fuel on yourself and then something
ignites it, you could be badly burned. Fuel can
spray out on you if you open the fuel cap too
quickly.
CAUTION: (Continued)
5-8
ProCarManuals.com

CAUTION: (Continued)
This spray can happen if your tank is nearly full,
and is more likely in hot weather. Open the fuel
cap slowly and wait for any “hiss” noise to stop.
Then unscrew the cap all the way.
Be careful not to spill fuel. Clean fuel from painted
surfaces as soon as possible. SeeCleaning the Outside
of Your Vehicle on page 5-85.
When you put the fuel cap back on, turn it to the right
(clockwise) about 1/4 of a turn until you hear three
clicks. Make sure you fully install the cap. The diagnostic
system can determine if the fuel cap has been left off
or improperly installed. This would allow fuel to
evaporate into the atmosphere and may cause the
malfunction indicator lamp to come on. SeeMalfunction
Indicator Lamp on page 3-34.
Notice:If you need a new fuel cap, be sure to get the
right type. Your dealer can get one for you. If you get
the wrong type, it may not t properly. This may
cause your malfunction indicator lamp to light and
may damage your fuel tank and emissions system.
SeeMalfunction Indicator Lamp on page 3-34.
Filling a Portable Fuel Container
{CAUTION:
Never ll a portable fuel container while it is in
your vehicle. Static electricity discharge from
the container can ignite the gasoline vapor.
You can be badly burned and your vehicle
damaged if this occurs. To help avoid injury to
you and others:
Dispense gasoline only into approved
containers.
Do not ll a container while it is inside a
vehicle, in a vehicle’s trunk, pickup bed or
on any surface other than the ground.
Bring the ll nozzle in contact with the
inside of the ll opening before operating
the nozzle. Contact should be maintained
until the lling is complete.
Do not smoke while pumping gasoline.
5-9
ProCarManuals.com

1. You can remove the coolant surge tank pressure
cap when the cooling system, including the coolant
surge tank pressure cap and upper radiator
hose, is no longer hot. Turn the pressure cap slowly
counterclockwise (left) about one-quarter of a
turn. If you hear a hiss, wait for that to stop. This
will allow any pressure still left to be vented out the
discharge hose.
2. Then keep turning the pressure cap slowly, and
remove it.
3. Fill the coolant surge tank with the proper
DEX-COOL
®coolant mixture, to the COLD line.4. With the coolant surge tank pressure cap off, start
the engine and let it run until you can feel the upper
radiator hose getting hot. Watch out for the
engine cooling fans.
By this time, the coolant level inside the coolant
surge tank may be lower. If the level is lower, add
more of the proper DEX-COOL
®coolant mixture
to the coolant surge tank until the level reaches the
COLD line.
5. Then replace the pressure cap. Be sure the
pressure cap is hand-tight.
5-33
ProCarManuals.com

10. Now start the vehicle with the good battery and run
the engine for a while.
11. Press UNLOCK on the RKE transmitter to disarm
your security system (if equipped).
12. Try to start the vehicle that had the dead battery. If
it won’t start after a few tries, it probably needs
service.
Notice:If the jumper cables are removed in the
wrong order, electrical shorting may occur and
damage the vehicle. The repairs would not be
covered by your warranty. Remove the jumper
cables in the correct order, making sure that the
cables do not touch each other or other metal.
A. Heavy, Unpainted Metal Engine Part
B. Good Battery
C. Dead BatteryJumper Cable Removal
5-45
ProCarManuals.com

5. Push headlamp housing lever up to disengage
headlamp housing from headlamp housing
pocket.
6. Turn the bulb socket being replaced
counterclockwise one–quarter of a turn while
pressing the socket in rmly. Pull the socket
rearward until the bulb clears the headlamp housing,
and lift it up to access the bulb.7. Disconnect the wire connector from the bulb by
lifting the lock tab and pulling it away from the
plastic base.
8. Remove the bulb assembly and replace it with the
appropriate bulb.
5-48
ProCarManuals.com

Fog Lamps
1. Reach up from underneath the front body panel
and turn the bulb socket counterclockwise one–
quarter of a turn while pressing the socket in rmly.
Pull the socket rearward until the bulb clears the
fog lamp housing.
2. Disconnect the wire connector from the bulb by
lifting the lock tab and pulling it away from the
plastic base.
3. Remove the bulb assembly and replace it with the
appropriate bulb.
Center High-Mounted Stoplamp
(CHMSL) (Sedan)
1. Remove the center high mounted stop lamp cover
by pulling down on the cover edges.
2. Turn the bulb socket being replaced
counterclockwise one–quarter of a turn and remove
the bulb.
3. Replace it with the appropriate bulb.
5-49
