2004 SATURN L-SERIES headlamp

Put on extra clothing or wrap a blanket around you.
If you have no blankets or extra clothing, make
body insulators from newspapers, burlap bags, rags,
oor mats — anything you can wrap around
yourself or tuck under your clothing to keep warm.
You can run the engine to keep warm, but be careful.
{CAUTION:
Snow can trap exhaust gases under your
vehicle. This can cause deadly CO (carbon
monoxide) gas to get inside. CO could
overcome you and kill you. You can not see it
or smell it, so you might not know it is in your
vehicle. Clear away snow from around the
base of your vehicle, especially any that is
blocking your exhaust pipe. And check around
again from time to time to be sure snow does
not collect there.
Open a window just a little on the side of the
vehicle that is away from the wind. This will
help keep CO out.
Run your engine only as long as you must. This saves
fuel. When you run the engine, make it go a little
faster than just idle. That is, push the accelerator
slightly. This uses less fuel for the heat that you get and
it keeps the battery charged. You will need a
well-charged battery to restart the vehicle, and possibly
for signaling later on with your headlamps. Let the
heater run for a while.
4-29
ProCarManuals.com

Service............................................................5-3
Doing Your Own Service Work.........................5-4
Adding Equipment to the Outside of Your
Vehicle......................................................5-5
Fuel................................................................5-5
Gasoline Octane............................................5-5
Gasoline Specications....................................5-6
California Fuel...............................................5-6
Additives.......................................................5-7
Fuels in Foreign Countries...............................5-7
Filling Your Tank............................................5-8
Filling a Portable Fuel Container.......................5-9
Checking Things Under the Hood....................5-10
Hood Release..............................................5-10
Engine Compartment Overview.......................5-12
Engine Oil...................................................5-16
Engine Air Cleaner/Filter................................5-20
Automatic Transaxle Fluid..............................5-23
Engine Coolant.............................................5-23
Coolant Surge Tank Pressure Cap..................5-26
Engine Overheating.......................................5-26
Cooling System............................................5-29
Power Steering Fluid.....................................5-34
Windshield Washer Fluid................................5-35
Brakes........................................................5-36Battery........................................................5-39
Jump Starting...............................................5-40
Bulb Replacement..........................................5-46
Halogen Bulbs..............................................5-46
Headlamps, Front Turn Signal, Sidemarker,
and Parking Lamps....................................5-47
Fog Lamps..................................................5-49
Center High-Mounted Stoplamp (CHMSL)
(Sedan)...................................................5-49
Center High-Mounted Stoplamp (CHMSL)
(Wagon)...................................................5-50
Taillamps, Turn Signal, Stoplamps and
Back-up Lamps (Sedan).............................5-50
Taillamps, Turn Signal, Stoplamps and
Back-up Lamps (Wagon)............................5-52
Replacement Bulbs.......................................5-52
Windshield Wiper Blade Replacement..............5-53
Tires..............................................................5-54
Ination - Tire Pressure.................................5-61
Tire Inspection and Rotation...........................5-62
When It Is Time for New Tires.......................5-64
Buying New Tires.........................................5-64
Uniform Tire Quality Grading..........................5-65
Wheel Alignment and Tire Balance..................5-67
Wheel Replacement......................................5-67
Section 5 Service and Appearance Care
5-1
ProCarManuals.com

Headlamps, Front Turn Signal,
Sidemarker, and Parking Lamps
1. Open the hood and secure it with the prop rod.
2. Remove push-pin fasteners from grill assembly.
3. Tilt grill assembly forward and lift it up to remove it
from the body of the vehicle.4. Remove fasteners from headlamp assembly.
5-47
ProCarManuals.com

5. Push headlamp housing lever up to disengage
headlamp housing from headlamp housing
pocket.
6. Turn the bulb socket being replaced
counterclockwise one–quarter of a turn while
pressing the socket in rmly. Pull the socket
rearward until the bulb clears the headlamp housing,
and lift it up to access the bulb.7. Disconnect the wire connector from the bulb by
lifting the lock tab and pulling it away from the
plastic base.
8. Remove the bulb assembly and replace it with the
appropriate bulb.
5-48
ProCarManuals.com

Taillamps, Turn Signal, Stoplamps
and Back-up Lamps (Wagon)
1. Open the liftgate.
2. Remove the interior access trim panel.
3. Turn the bulb socket being replaced
counterclockwise one–quarter of a turn while
pressing the socket in rmly. Pull the socket
rearward until the bulb clears the taillamp housing.
4. Replace it with the appropriate bulb.
Replacement Bulbs
Exterior Lamp Bulb Number
Headlamps —
High Beam 9005 HB39441732
Low Beam 9006 HB49441733
Front Park/Turn Lamps 34571999381
Front Side Markert Lamps W5W12092811
Stop/Taillamps P21/5W21019520
Rear Turn Lamps P21W21019521
Back-up Lamps P21W21019520
CHMSL PC16825085970
Fog Lamps 880L12450143
5-52
ProCarManuals.com

Wheel Alignment and Tire Balance
The wheels on your vehicle were aligned and balanced
carefully at the factory to give you the longest tire life
and best overall performance.
Scheduled wheel alignment and wheel balancing are
not needed. However, if you notice unusual tire wear or
your vehicle pulling one way or the other, the alignment
may need to be reset. If you notice your vehicle
vibrating when driving on a smooth road, your wheels
may need to be rebalanced.
Wheel Replacement
Replace any wheel that is bent, cracked or badly rusted
or corroded. If wheel bolts keep coming loose, the
wheel and wheel bolts should be replaced. If the wheel
leaks air, replace it (except some aluminum wheels,
which can sometimes be repaired). See your Saturn
Retailer if any of these conditions exist.
Your retailer will know the kind of wheel or wheel bolt
you need.
Each new wheel should have the same load-carrying
capacity, diameter, width, offset and be mounted
the same way as the one it replaces.If you need to replace any of your wheels or wheel
bolts, replace them only with new Saturn original
equipment parts. This way, you will be sure to have the
right wheel and wheel bolts for your Saturn.
{CAUTION:
Using the wrong replacement wheels or wheel
bolts on your vehicle can be dangerous. It
could affect the braking and handling of your
vehicle, make your tires lose air and make you
lose control. You could have a collision in
which you or others could be injured. Always
use the correct wheel and wheel bolts for
replacement.
Notice:The wrong wheel can also cause problems
with bearing life, brake cooling, speedometer or
odometer calibration, headlamp aim, bumper height,
vehicle ground clearance and tire or tire chain
clearance to the body and chassis.
SeeChanging a Flat Tire on page 5-70for more
information.
5-67
ProCarManuals.com

Fuses Usage
RADIOAudio, OnStar
®, Rear Seat DVD
(Option)
WIPERWindshield Washers and Wipers
(Front)
IGN 3Left Heated Seat Switch, Right
Heated Seat Switch, Air
Conditioning, Rear Defogger Relay
DEFOG LED Rear Defog LED
BTSI/BCM/
MIRRORBrake Transaxle Shift Interlock,
Body Control Module, Power Mirror
DIMMER Dimmer Switch
RR COMP LP Trunk Compartment Lamp
Relays Usage
RR DEFOG Rear Defogger
IGN 3 Ignition Switch
PARKLAMP Park Lamps
HEADLAMP Headlamps
5-93
ProCarManuals.com

Engine Compartment Fuse Block
The engine compartment
fuse block is located in the
forward part of the
engine compartment near
the battery.
Fuses Usage
IGN 1/2 Ignition switch
IGN 0/3/CR Ignition switch
COOL 1 Cooling fan module
COOL 2 Cooling fan module
ABS 1 Anti-Lock Brake System
ABS 2 Anti-Lock Brake System
Fuses Usage
HVAC
BLOWERHigh Blower
HORN Horn
R HDLP Right Headlamps
L HDLP Left Headlamps
A/C Air Conditioning System
LIGHTER Cigarette Lighter
AUX POWER Power Outlet
I/P BATT RTPassenger’s Side Instrument Panel
Fuse Block
CONTROLS
B+Powertrain Control Module (2.2L L4
(L61)), Engine Control Module (3.0L
V6 (L81), Transaxle Control Module
(3.0L V6 (L81))
BCM 2 Body Control Module
BCM/ECM/
CRUISE/ABSBody Control Module, Engine
Control Module, Cruise Control,
ABS
EISElectronic Ignition System
(2.2L L4 (L61))
IGN Ignition Coils (3.0L V6 (L81))
5-95
