Windows and Sliding Roofs
99
Comfort function on vehicles without
Porsche Entry & DriveOpening and closing the Panorama roof
system
fHold the car key in the door lock in the
unlocking or locking position until the windows
and the Panorama roof system have reached
the desired position.Comfort function on vehicles with
Porsche Entry & DriveOpening and closing the Panorama roof
system
fHold the car key in the door lock in the
unlocking or locking position until the windows
and the Panorama roof system have reached
the desired position.
Closing the Panorama roof system
fHold the button in the door handle when
locking the vehicle until the windows and the
Panorama roof system have reached the
desired position.
Force limiter for the Panorama roof
system All roof elements are equipped with a force limiter.
If the sliding roof or the sliding/lifting roof element
is obstructed during the closing or opening
process, the respective roof element opens or
closes again immediately.
Closing a roof element after triggering the
force limiter
1. Remove the obstruction.
2. Turn knob to position A again.Electric emergency closing function
Warning!
Risk of injury from the emergency closing
function for the Panorama roof system. The
force limiter is not available and the roof
elements will close with full force.
fEnsure that no one can be injured when the Panorama roof system is closing.
If the roof cannot be closed due to dirt, ice, or
similar substances:
1. Turn knob to position A.
2. Hold the knob in position A until all roof
elements are completely closed.
Save final position of the Panorama roof
systemAfter disconnecting/reconnecting the vehicle
battery or if the vehicle battery is discharged, or
after emergency starting with jumper cables, the
final positions of the Panorama roof system are
lost.
Warning!
Risk of injury when closing the Panorama
roof system. The force limiter is not available
and the roof elements will close with full
force.
fEnsure that no one can be injured when the Panorama roof system is closing.
1. Switch ignition off.
2. Turn knob to position A.
3. Switch ignition on.
4. Press knob up at its front edge in position A
and keep pressed.
The teaching process begins after around
5 seconds. Hold the knob pressed in position
until the roller blind and all roof elements have
completely stopped moving. The procedure
lasts a maximum of 20 seconds.
5. Release the knob.
The raised sliding/lifting roof element 3 clo-
ses automatically. The teaching process is
then completed.
10_Cayenne_21_KW17.book Seite 99 Donnerstag, 9. April 2009 3:33 15

Multi-Purpose Display and Instruments
121
J - OdometerThe displays for the total mileage and individual
trips are located in the analog speedometer.
The upper display counts the total mileage, the
lower display counts the short trips.
After exceeding 6213 miles (9999 kilometers),
the short trip counter returns to 0.Resetting the short trip counter to “O”fPress button H for approx. 1 secondThe voltmeter indicates the vehicle electrical
system voltage.
Normal range: 12 to 16 volts.
The voltage may drop considerably when the
vehicle is being started.
If the indicator is continually below 12 volts
when the engine is running:
fPlease have the battery charging system
checked at an authorized Porsche dealer.
Battery/alternatorA warning message will appear on the multi-purpo-
se display of the instrument panel if the voltage
drops significantly.
fStop in a safe place and switch off the engine.
fFor information on the warning message on
the multi-purpose display:
Please see the chapter “OVERVIEW OF
WARNING MESSAGES” on Page 149.Possible causes
– Defect in the battery charging system
– Broken drive belt
Warning!
Risk of engine damage with resultant loss of
control and accident, leading to serious
personal injury or death.
A broken drive belt means there is no power
assistance to the steering (more effort is
required to steer) and engine cooling fails.
fDo not continue driving.
fHave the fault remedied at your nearest autho-
rized Porsche dealer.
Danger of steering assistance failing during
a long trip in the water if the drive belt slips.
fIf the steering assistance fails, more effort will be required to steer.
K - Voltmeter
10_Cayenne_21_KW17.book Seite 121 Donnerstag, 9. April 2009 3:33 15

158
Driving and Driving Safety
Ignition lock positions:
0- Initial position
1- Ignition on
2-Start engine
3- Ignition offIgnition Lock/Steering Lock
Caution!
Risk of damage. The ignition lock may be da-
maged if additional weight is attached to the
inserted ignition key, e.g. a heavy bunch of
keys and/or key tag.
fDo not attach a heavy weight to the inserted ig-nition key.
Ignition lock positions with Porsche Entry & Drive:
0- Initial position
1- Ignition on
2-Start engine
3- Ignition offThe ignition lock has a total of four ignition lock
positions.
Note on operation
The car key rebounds to the initial position from
every ignition lock position.
For vehicles that have Porsche Entry & Drive
you do not need to insert the key into the ignition
lock again but merely keep it with you. The ignition key is replaced by a control unit in the
ignition lock, which always remains in the ignition
lock, unless the vehicle is being towed.
Removing the control unit from the ignition
lock
fPress button A and remove the control unit.
Ignition lock position 0 - Initial positionThe ignition key cannot be withdrawn when the ig-
nition is switched on or when the engine is started.
To withdraw the ignition key:
fStop the vehicle.
fOn vehicles with Tiptronic S:
Move Tiptronic selector lever to position P.
fSwitch ignition off.
fWithdraw the ignition key.
Note on operation
The vehicle battery discharges if the ignition key is
left inserted.
fIf the vehicle battery is dead, the key can only
be pulled out of the ignition lock if the emergen-
cy operation is performed:
Please see the chapter “EMERGENCY OPERA-
TION - UNLOCKING THE IGNITION KEY” on
Page 159.
10_Cayenne_21_KW17.book Seite 158 Donnerstag, 9. April 2009 3:33 15

376
Index
Speed control (cruise control)
Accelerating
................................................. 167
Decelerating
................................................. 168
Functional description
..................................... 167
Interrupting operation
..................................... 168
Storing speed
............................................... 167
Switching off
................................................. 168
Switching on
................................................. 167
Speed limit
............................................................ 290
Setting on the multi-purpose display
.................. 129
Speedometer, digital
............................................... 120
Sport button
Functional description, Sport mode
................... 179
Switching Sport mode on and off
...................... 180
Sport mode
Functional description
..................................... 179
Switching on/off
............................................ 180
SportDesign package
.................................................. 3
Information on risk of damage
......................... 195
Sports exhaust system
Switching on/off
............................................ 179
Stainless steel exhaust tailpipes
................................ 276
Stainless steel tailpipes
Care instructions
........................................... 276
Starting
Emergency starting with jumper cables
............. 323
Engine
......................................................... 160
Engine (Tiptronic S)
........................................ 170
With jumper cables
........................................ 323
With Tiptronic S
............................................. 170
Steam-jet cleaners, information on use
....................... 271
Steam-jet units
....................................................... 238
Steering column
Locking with Porsche Entry & Drive
.................. 159
Locking without Porsche Entry & Drive
.............. 159
Steering column lock
With Porsche Entry & Drive
.............................. 159
Without Porsche Entry & Drive
......................... 159
Steering lock
Emergency operation of the key
....................... 159
Functional description
..................................... 158
Steering wheel
......................................................... 58
Adjusting
........................................................ 59
Airbag unit
...................................................... 58
Heating
.......................................................... 58
Multi-functional steering wheel
............................ 61
Multi-functional steering wheel,
functional description
....................................... 60
Operating the function keys
............................... 60
Operating the horn
........................................... 58
Shifting
........................................................ 172
Steering lock
................................................ 158
Switching Easy Entry function on/off
................... 39
Switching heating on/off
................................... 58
Switching key illumination on/off
......................... 61
Tiptronic rocker switches
.................................. 58
Stopping
............................................................... 174Engine
......................................................... 161
Storage
................................................................ 222Drawer under the right front seat
...................... 225
Glasses case in the roof console
...................... 222
Glove compartment
........................................ 223
Storage compartment
at the sides of the luggage compartment
........... 225
Storage compartment in the front armrest
......... 224
Storage compartment in the rear armrest
.......... 224
Storage options
............................................ 222
Storage compartment
............................................. 222
At the sides of the luggage compartment
........... 225
Drawer under the right front seat
...................... 225
Glasses case in the roof console
...................... 222
Glove compartment
........................................ 223
In the front armrest
........................................ 224
In the rear armrest
......................................... 224
Storage
....................................................... 222
Stowing luggage
.................................................... 233
When towing a Trailer
..................................... 234
Strap reel (cargo management system)
Inserting and adjusting
.................................... 208
Strap reel storage location
.............................. 208
Summer tires
......................................................... 350
Overview
...................................................... 350
Storage
....................................................... 287
Wheel change
............................................... 302
Sun blind
Cleaning position (Panorama roof system)
.......... 101
Opening/closing for Panorama roof system
........ 100
Pulling out/retracting for rear side windows
.......... 62
Sun sensor
For 2-zone air conditioning
................................ 71
For 4-zone air conditioning
................................ 76
Sun visor
................................................................. 62
Switching automatic anti-dazzle operation on and off
....... 57
Switching child lock (rear doors) on/off
........................ 29
Switching child protection on/off
Disabling central locking button on the rear doors
.29
Disabling control panel for air-conditioned areas
at the rear (4-zone air conditioning)
..................... 79
Disabling power windows in the rear doors
........... 88
Switching ECON mode on/off
With 2-zone air conditioning
............................... 65
With 4-zone air conditioning
............................... 65
With manual air conditioning
.............................. 65
Switching emergency flasher on/off
........................... 107
Switching front reading lights on/off
........................... 108
Switching Mono function on/off
With 2-zone air conditioning
............................... 72
With 4-zone air conditioning
............................... 78
Switching off readiness for operation
Vehicles with Porsche Entry & Drive
.................... 19
Switching on automatic recirculating-air mode
With 2-zone air conditioning
............................... 72
With 4-zone air conditioning
............................... 78
Switching on door-surrounding lighting
........................ 109
Switching on fog lights
............................................. 104
Switching on parking light
......................................... 106
Switching on recirculating-air mode
With 2-zone air conditioning
............................... 72
With 4-zone air conditioning
............................... 78
With manual air conditioning
.............................. 68
Switching the off-road roof-mounted headlights on/off
... 217
Switching the roof-mounted headlights on/off
.............. 217
TTachometer
Display
......................................................... 120
Tail light
Changing bulb
............................................... 338
Changing reversing light bulb
........................... 338
Installing
...................................................... 337
Removing
..................................................... 336
Removing tail light
.......................................... 336
Replacing rear fog light
................................... 338
Replacing turn signal light
................................ 338
Tailpipes
Stainless steel, care instructions
...................... 276
Tank opening
......................................................... 267
TCS (traction control system)
Functional description
..................................... 182
10_Cayenne_21_KW17.book Seite 376 Donnerstag, 9. April 2009 3:33 15
