2004 Peugeot 406 C ECO mode

02-02-2004
YOUR 406 COUPE IN DETAIL
68
RDS Using the RDS (Radio Data System) function on FM Radio Data System allows you to continue listening to the same station, whatever frequency it is using for the region you are going through. Briefly press the "RDS"button to switch the function on or off.
The display will show: Ð "RDS" if the function is selected.
Ð "(RDS)" if the function is selected but not available.
RDS station following
The display indicates the name of the station selected. The radio is continually searching for the station which has the best reception and which is transmitting the same programme.
Traffic information programme Press the "TA"button to switch the function on or off.
The display will show: Ð "TA" if the function is selected,
Ð "(TA)" if the function is selected but not available.
Any traffic information flash will be given priority, whatever source is in use (radio, CD or CD changer). If you wish to interrupt a message, press the "TA"button; this switches the function off.
Note: the volume of traffic information announcements is independent of the volume of normal radio listening. You can adjust it using the volume button. The setting will be stored and will be used when the next messages are broad-cast. Regional following mode When they are part of a network, certain stations broadcast regional programmes in the various areas they serve. With regional following mode you can keep listening to the same programme.
Press the "RDS"button for more than two seconds to switch the function on or off.

02-02-2004
YOUR 406 COUPE IN DETAIL69
PTY function This allows you to listen to stations broadcasting a specific type of programme (news, culture, sport, rock etc.). With FM selected, press the "TA"button for two seconds to switch this function on or off.
To search for a PTY programme:
Ð select the PTYfunction,
Ð briefly press button Kor Mto scroll down the list of the various types of pro-
grammes offered.
Ð when the programme of your choice is displayed, keep button Kor Mpressed for two seconds to carry out an automatic
search (after an automatic search the PTYfunction is switched off).
In PTY mode the different types of programmes can be stored in the
memory. To do this, press the preselection buttons 1to 6for more
than two seconds. To recall the type of programme stored in the
memory, briefly press the corresponding button.
EON system
This connects stations which are part of the same network. It allows the broadcast of traffic information, by a station that is part of the same network as the station to which you are listening.
This service is available when you have selected the TA traffic information programme or the PTYfunction.

02-02-2004
YOUR 406 COUPE IN DETAIL
70
COMPACT DISC Selecting CD mode After inserting a disc, with the printed surface upwards, the player starts automatically.If a disc is already inserted, press button C.
Ejecting a disc Press button Eto eject the disc from the player.
Selecting a track Press button Kto select the following track.
Press button Mto return to the start of the current track or to select the previous
track.
Accelerated playPress the "MAN"button.
Press and hold button Kor Mfor forwards or backwards accelerated play.
Accelerated play stops as soon as the button is released.Buttons Kor Mresume the "track selection" function when the "MAN"button is pressed again.
Shuffle When the CD is selected, keep button Cpressed for two seconds. The tracks will be played in random
sequence. Pressing button Cagain for two seconds returns you to normal play.

02-02-2004
YOUR 406 COUPE IN DETAIL71
CD CHANGER Selecting CD changer mode Press button D.
Selecting a disc Press buttons 1to 6to select the corresponding disc.
Selecting a track Press button Kto select the following track.
Press button Mto return to the start of the current track or to select the previous
track.
Accelerated playPress the "MAN"button.
Press and hold button Kor Mfor forwards or backwards accelerated play.
Accelerated play stops as soon as the button is released.Buttons Kor Mresume the "track selection" function when the "MAN"button is pressed again.
Shuffle When the CD changer is selected, keep button Dpressed for two seconds. The tracks will be played in random
sequence. Pressing button Dagain for two seconds returns you to normal play.

02-02-2004
THE SATELLITE NAVIGATION SYSTEM IntroductionThe satellite navigation system guides you to the destination of yourchoice by means of vocal and visualinstructions. The heart of the system lies in the use of a map database and GPS
(Global Positioning System). Thisenables your position to be locatedby means of several satellites. The satellite navigation system
consists of the following components:
Ð the remote control,
Ð the display,
Ð the control unit,
Ð the last voice message recall control,
Ð the CD ROM.
Some functions or services
described in this guide may vary depending on the
CD ROM version or the countryThe remote control
There is a storage compartment for the remote control in front of the ashtray.Pointing the remote control at the screen enables the information contained in the various menus to be selected.
Direction arrows: These enable you to move around the screen and thus select a function.
On the welcome screen only, the Up and Down buttons enable the brightness of the screen to be adjusted.
menu : this button allows access to the main menu. It canbe used at any time.
esc : escape button "Short press": cancels the current operation and returns to the previous screen. "Press for more than 2 seconds": returns to the welcome screen. This button can be used in any menu. It is inactive during guidance.
mod : mode button "Short press": changes between date, navigation, radio and permanent locating.
val : validation button Confirms the function selected.
YOUR 406 COUPE IN DETAIL
74

Never leave one or more children alone and unsu-pervised in a vehicle. Never leave a child or an
animal in a vehicle which is exposed to the sun and has thewindows closed.
To protect your young children from the sun, fit blinds on the rearwindows. Never leave the keys within reach of children inside the vehicle. Observe strictly the recommenda- tions for assembling and securingthe child seat as shown in thechild seat instructions.
To prevent the doors from opening
accidentally, use the child lock*. Also, do not open the rear win- dows more than a third*.
* According to model.
YOUR 406 COUPE IN DETAIL 99
Groups 2 and 3: from 15 to 36 kg
L5 - "Recaro Start'': installed using a three-point seat belt.
The height and width at the shoulders and length of the seat cushion must be adjusted according to the age and build of your child.
L6- "Klippan Optima": installed in the rear using a three-point seat belt. From the age of 6 years (approximately 22 kg), the booster is used on its own
Groups 1, 2 and 3: from 9 to 36 kg
L7 - "Kiddy Life": installed in the rear using a three-point seat belt. The height and width at the shoulders and the length of the seat cushion must be adjusted according to the age and build of your child.
For the safety of young children (from 9 to 18 kg), PEUGEOT recommends use of the restraining cushion.
Recommendations For optimum installation of a forwards facing child seat, check that the back of the child seat is resting against the back of the vehicle's seat correctly and thatthe head restraint does not cause any discomfort. If it is necessary to remove the head restraint, as in the case of the "RECARO
Start", "KLIPPAN Optima" and "KIDDY Life" child seats (over 6 years of age),ensure that the head restraint is securely stored or attached so that it cannot actas a projectile in the event of sharp braking. Disarm the passenger air bag when installing a "rearwards facing" child seat on the front passenger seat. Otherwise, the child would risk beingseriously injured or killed were the air bag to inflate.
02-02-2004

02-02-2004
AUTOMATIC SWITCHING ON OF THE LIGHTS The side lights and dipped beam headlamps switch on automatically if
the light is poor, or during continuousoperation of the windscreen wipers.
They switch off as soon as the lightbecomes bright enough or the wind-screen wipers stop. This function is active when the vehi-
cle is supplied to the customer.
To disarm or activate the function: Place the key in the accessories position (1st notch),
 Press the end of the lights stalkfor more than two seconds.
Note: in foggy weather, the bright-
ness sensor can detect sufficientlight. Because of this, the lights do
not come on automatically. Do not cover the brightness sen-
sor connected to the rain sensor,located on the windscreen behind
the mirror. It is used for automat-ic switching on of the lights. Operating check Activation Activation of this function is accom- panied by an audible signal and themessage
"Automatic lighting of
the headlamps activated" on the
multi-function display. Note: Manual operation of the lights
stalk always takes priority Disarming Disarming of the function is accom- panied by an audible signal and themessage "Automatic lighting of
the headlamps deactivated" on the
multi-function display. When driving, if this function is
switched off when the headlampswould switch on in automatic mode,the lights remain on. It is howeverpossible to disarm this function and
switch off the lights by:
Ð manually switching off the lights using the lights stalk,
Ð switching off the engine. If the brightness sensor does not
function correctly,
the system acti-
vates the function (the lights come
on). The driver is alerted by theflashing of the ''dipped beam'' warn-ing light on the instrument panel.
Contact a PEUGEOT dealer to have the system checked. Follow me Home When there is a low level of bright- ness or at night, if you leave yourvehicle, the side lights and thedipped beam lights may remain onfor approximately one minute. This function can only be used if the automatic switching on of the lightsmode is activated then:  with the key in the accessories position (1st notch), flash theheadlamps,
 get out of the car and lock it.
YOUR 406 COUPE IN DETAIL 103

02-02-2004
WINDSCREEN WIPER STALK Front windscreen wipers2 Rapid wipe (heavy rain)
1 Normal wipe (moderate rain).
AUTO Automatic wipe.
0 Off.


Single wipe (press downwards). Operation In position
1or 2, when the vehicle
stops, the windscreen wiper changes to a lower wiping speed, thenresumes its initial speed when thevehicle starts again. When the ignition has been switched off for more than a
minute with the stalk in the AUTOposition, it is necesary to reacti-vate this function. To do this, move
the stalk to any position, then move itback to the AUTOposition.
Automatic wipe In the AUTO position, the wiper oper-
ates automatically and adjusts its
speed to the intensity of the rainfall. Operating check ActivationActivation of the function is accom- panied by the message "Automatic
wiper activated" on the multi-func-
tion display. In the event of malfunction in the
AUTO position, the windscreen
wiper will operate in down-grade mode. Have the system checked by a
PEUGEOT dealer.
YOUR 406 COUPE IN DETAIL
104
Do not cover the rain detector located on thewindscreen behind the
interior mirror.
When using an automatic carwash, switch off the ignition orcheck that the wiper stalk is not inthe automatic position.
In winter, it is advisable to wait for the windscreen to completelyclear of ice before operating theautomatic wipe.
Windscreen and headlamp wash Pull the windscreen wiper stalk
towards you. The windscreen washthen the windscreen wipers operatefor a fixed period. The windscreen wash and headlamp wash operate simultaneously for twoseconds, only if the headlamps are
on.
