2004 NISSAN SENTRA glove box

1. Inside mirror (P. 3-16)
2. Map lights (if so equipped) (P. 2-30)
3. Sun visors (P. 3-16)
4. Glove box (P. 2-24)
5. Sunroof (if so equipped) (P. 2-28)
6. Front seat (P. 1-2)
7. Rear seat (P. 1-4)
8. Rear cup holders (if so equipped)
(P. 2-24)
9. Console box (if so equipped) (P. 2-25)
10. Front cup holders (P. 2-24)
11. Park brake, parking on hills (P. 5-13,
P. 5-17)
See the page number indicated in paren-
theses for operating details.
LII0008
PASSENGER COMPARTMENT
Illustrated table of contents0-5
ZREVIEW COPY:Ð2004 Sentra(b15)
Owners Manual(owners)ÐUSA English(nna)
03/18/04Ðtbrooks
X

1. Headlight/fog light (if so equipped)/ turn sig-
nal switch (P. 2-18)
2. Meters/gauges (P. 2-3)
3. Windshield wiper/washer switch (P. 2-17)
4. Heater/air conditioner control (P. 4-2)
5. Storage compartment (P. 2-25)
6. Hazard warning flasher switch (P. 2-20)
7. Center ventilators (P. 4-2)
8. Pasenger supplemental air bag (P. 1-6)
9. Glove box (P. 2-24)
10. Pocket (P. 2-23)
11. Power outlet/cigarette lighter (P. 2-21,
P. 2-22)
12. Power outlet (if so equipped) (P. 2-21)
13. Audio system (if so equipped) (P. 4-10)
14. Cruise control and main set switch
(if so eqipped) (P. 2-20)
15. Tilt steering lock lever (P. 3-15)
16. Trunk release Type B (P. 3-11)
17. Fuel filler lid opening lever (P. 3-14)
18. Driver supplemental air bag (P. 1-6)
19. Hood release lever (P. 3-11)
20. Fuse box cover/coin holder (P. 8-30, 2-25)
21. Trunk release Type A (P. 3-11)
22. Instrument brightness control switch (P. 2-19)
23. Outside mirror electric control type switch
(if so equipped) (P. 3-17)
See the page number indicated in paren-
theses for operating details.WIC0433
INSTRUMENT PANEL
0-6Illustrated table of contents
ZREVIEW COPY:Ð2004 Sentra(b15)
Owners Manual(owners)ÐUSA English(nna)
04/02/04Ðskoniecz
X

1. Supplemental front air bag modules
2. Supplemental side-impact air bag
modules (if so equipped)
3. Satellite sensors (if so equipped)
4. Seat belt pre-tensioner retractor
5. Diagnosis sensor unit
Supplemental front air bag system
The driver supplemental front air bag is located in
the center of the steering wheel. The passenger
supplemental front air bag is mounted in the
dashboard above the glove box.
These systems are designed to meet optional
certification requirements under U.S. regulations.They are also permitted in Canada. The optional
certification allows the front air bags to be de-
signed to inflate somewhat less forcefully than
previously.However, all of the information,
cautions and warnings in this manual still
apply and must be followed.
The supplemental front air bag system is de-
signed to inflate in higher severity frontal colli-
sions, although it may inflate if the forces in an-
other type of collision are similar to those of a
higher severity frontal impact. It may not inflate in
certain frontal collisions. Vehicle damage (or lack
of it) is not always an indication of proper supple-
mental front air bag system operation.
SSS0162WRS0135
1-12Safety—Seats, seat belts and supplemental air bags
ZREVIEW COPY:Ð2004 Sentra(b15)
Owners Manual(owners)ÐUSA English(nna)
03/18/04Ðtbrooks
X

2 Instruments and controls
Instrument panel...................................2-2
Meters and gauges................................2-3
Speedometer and odometer.....................2-4
Trip computer (if so equipped)...................2-5
Tachometer (if so equipped).....................2-6
Engine coolant temperature gauge...............2-7
Fuel gauge....................................2-7
Warning/indicator lights and audible reminders.......2-9
Checking bulbs................................2-9
Warning lights.................................2-9
Indicator lights................................2-11
Audible reminders.............................2-12
Security systems.................................2-13
Nissan vehicle immobilizer system (NVIS) (if
so equipped)..................................2-13
Vehicle security system (if so equipped)..........2-14
Windshield wiper and washer switch...............2-17
Switch operation..............................2-17
Rear window defroster switch......................2-18
Headlight and turn signal switch....................2-18
Headlight control switch........................2-18
Daytime running light system (Canada only)......2-19Instrument brightness control...................2-19
Turn signal switch.............................2-20
Fog light switch (if so equipped)................2-20
Hazard warning flasher switch.....................2-20
Horn............................................2-21
Power outlet.....................................2-21
Cigarette lighter..................................2-22
Storage.........................................2-23
Sunglasses holder (if so equipped)..............2-23
Cup holders..................................2-24
Glove box....................................2-24
Coin box.....................................2-25
Console box (if so equipped)...................2-25
Instrument panel storage (if so equipped)........2-25
Windows........................................2-26
Power windows (if so equipped)................2-26
Manual windows..............................2-28
Sunroof (if so equipped)...........................2-28
Electric sunroof...............................2-28
Interior light......................................2-29
Map lights (if so equipped)........................2-30
Trunk light.......................................2-30
ZREVIEW COPY:Ð2004 Sentra(b15)
Owners Manual(owners)ÐUSA English(nna)
03/18/04Ðtbrooks
X

1. Headlight/fog light (if so equipped)/turn
signal switch (P. 2-18)
2. Meters/gauges (P. 2-3)
3. Windshield wiper/washer switch (P. 2-17)
4. Heater/air conditioner control (P. 4-2)
5. Storage compartment (P. 2-25)
6. Hazard warning flasher switch (P. 2-20)
7. Center ventilators (P. 4-2)
8. Passenger supplemental air bag (P. 1-6)
9. Glove box (P. 2-24)
10. Pocket (P. 2-23)
11. Power outlet/cigarette lighter (P. 2-21,
2-22)
12. Power outlet (if so equipped) (P. 2-21)
13. Audio system (if so equipped) (P. 4-10)
14. Cruise control and main set switch
(if so equipped) (P. 5-14)
15. Tilt steering lock lever (P. 3-15)
16. Trunk release Type B (P. 3-11)
17. Fuel filler lid opening lever (P. 3-14)
18. Driver supplemental air bag (P. 1-6)
19. Hood release lever (P. 3-11)
20. Fuse box cover/coin holder (P. 8-30, 2-25)
21. Trunk release Type A (P. 3-11)
22. Instrument brightness control switch
(P. 2-19)
23. Outside mirror electric control type switch
(if so equipped) (P. 3-17)
WIC0433
INSTRUMENT PANEL
2-2Instruments and controls
ZREVIEW COPY:Ð2004 Sentra(b15)
Owners Manual(owners)ÐUSA English(nna)
04/02/04Ðskoniecz
X

CUP HOLDERS
Front
The right side cup holder has an adapter that can
be removed to accommodate larger cups. Twist
the adapter to remove it.
WARNING
The cup holder should not be used while
driving so full attention may be given to
vehicle operation.
Rear (if so equipped)
To open, pull the cup holder out fully. To close,
push the cup holder in fully.
CAUTION
cAvoid abrupt starting and braking when
the cup holder is being used to prevent
spilling the drink. If the liquid is hot, it
can scald you or your passenger.
cUse only soft cups in the cup holder.
Hard objects can injure you in an
accident.
GLOVE BOX
Open the glove box by pulling the handle.
WARNING
Keep glove box lid closed while driving to
help prevent injury in an accident or a
sudden stop.
WIC0303WIC0254WIC0255
2-24Instruments and controls
ZREVIEW COPY:Ð2004 Sentra(b15)
Owners Manual(owners)ÐUSA English(nna)
03/18/04Ðtbrooks
X

IN-CABIN MICROFILTER (if so
equipped)
The in-cabin microfilter restricts the entry of air-
borne dust and pollen particles and reduces
some objectionable outside odors. The filter is
located behind the glove box. Refer to the
“NISSAN Service and Maintenance Guide” for
change intervals.
To change the filter, perform the following proce-
dure:
1. Remove the glove box door by removing the
two lower hinge pins.2. Remove the two screws securing the glove
box frame.
3. Remove the two screws securing the glove
box door latch. Remove the latch by pulling it
down.
4. Remove the glove box frame by pulling it
away from the instrument panel to disen-
gage the retaining clips.
LDI0139LDI0140
8-24Maintenance and do-it-yourself
ZREVIEW COPY:Ð2004 Sentra(b15)
Owners Manual(owners)ÐUSA English(nna)
03/18/04Ðtbrooks
X

NOTE: Make sure the filter sits on top of the two
supporting tabs on the housing.
7. Replace the cover by inserting the upper
tabs inside the housing slot and pushing the
hook tabs until they snap onto the housing
lip.
8. Install the glove box frame and latch.
9. Install the glove box door.
10. Fill out the date information and the small
replacement label and attach it to the glove
box lid.
LDI0143
