2004 NISSAN 350Z keyless entry

3 Pre-driving checks and adjustmentsKeys ......................................................................................... 3-2
Doors ....................................................................................... 3-2
Locking with key ............................................................. 3-3
Locking with inside lock knob..................................... 3-3
Locking with power door lock switch ....................... 3-4
Remote keyless entry system ............................................ 3-4
How to use remote keyless entry system ................ 3-5
Battery replacement ....................................................... 3-8
Hood ........................................................................................ 3-9
Rear hatch (Coupe models) .............................................. 3-9
Opener operation ......................................................... 3-10
Secondary rear hatch release .................................... 3-10
Trunk lid (Roadster models) ............................................ 3-11
Opener operation ......................................................... 3-11
Interior trunk lid release ............................................... 3-12
Secondary trunk lid release ........................................ 3-13
Fuel filler lid ......................................................................... 3-13Opener operation ......................................................... 3-13
Fuel filler cap ................................................................. 3-14
Steering wheel .................................................................... 3-15
Tilt operation .................................................................. 3-15
Extension sun visor (if so equipped) ........................... 3-16
Mirrors ................................................................................... 3-16
Inside mirror ................................................................... 3-16
Automatic anti-glare inside mirror
(if so equipped) ........................................................... 3-17
Outside mirrors ........................................................... 3-17
Soft top operation (Roadster models) ........................... 3-18
Before operating the top ............................................. 3-18
When operating the top .............................................. 3-20
Opening the top ............................................................ 3-23
Closing the top .............................................................. 3-24
If the top does not open or close electrically ........ 3-24
Care of the soft top and the vehicle body.............. 3-27


04.1.22/Z33-D/V5.0


LOCKING WITH POWER DOOR
LOCK SWITCHAll door locks will be engaged when the power
door lock switch is moved to the LOCK position
with the driver’s or front passenger’s door open.
Then close the door and all doors will be locked.Lockout protectionWhen the power door lock switch (driver or front
passenger) is moved to the LOCK position with
the key in the ignition and any door open, all
doors will lock and unlock automatically. This
helps to prevent the keys from being accidentally
locked inside the vehicle.It is possible to lock/unlock all doors (including
the rear hatch/trunk lid), release the rear
hatch/trunk lid and activate the panic alarm by
using the keyfobfrom outside the vehicle.
Before locking the doors, make sure the
key is not left in the vehicle.
The keyfobcan operate at a distance of approxi-
mately 33 ft (10 m) from the vehicle. (The
effective distance depends upon the conditions
around the vehicle.)
As many as 5 keyfobs can be used with one
vehicle. For information concerning the purchase
and use of additional keyfobs, contact your
NISSAN dealer.
The keyfobwill not function when:

the battery is discharged,

the distance between the vehicle and the
keyfobis over 33 ft (10 m).
The panic alarm and the rear hatch/trunk
lid release will not activate when the key is
in the ignition switch.
CAUTION
The following conditions or occurrences
will damage the keyfob.
Do not allow the keyfob to become
wet.

Do not drop the keyfob.

Do not strike the keyfob sharply
against another object.

Do not place the keyfob for an ex-
tended period in an area where tem-
peratures exceed 140°F (60°C).
If a keyfob is lost or stolen, NISSAN
recommends erasing the ID code of that
keyfob. This will prevent the keyfob
from unauthorized use to unlock the
vehicle. For information regarding the
erasing procedure, please contact a
NISSAN dealer.
SPA1505
REMOTE KEYLESS ENTRY
SYSTEM
3-4
Pre-driving checks and adjustments


04.1.22/Z33-D/V5.0


HOW TO USE REMOTE KEYLESS
ENTRY SYSTEM
Locking doors1. Remove the ignition key.*1 *2
2. Close all the doors.*3
3. Push the LOCK button on the keyfob.
4. All the doors will lock.
All of the doors will lock when the LOCK
button on the keyfob is pushed even
though a door remains open and/or the
ignition key is in the ONposition.5. The hazard indicator flashes twice and the
horn chirps once.

When the LOCK button is pushed with all
doors locked, the hazard indicator flashes
twice and the horn chirps once as a reminder
that the doors are already locked.
*1: Doors lock with the keyfobwhile a key is in
the ignition switch. However, the panic
alarm and the rear hatch/trunk lid release will
not activate when the key is in the ignition
switch.
*2: Doors lock with the keyfobwhile the ignition
switch is in the ON position. However, the
hazard indicator and horn will not function.
*3: Doors lock with the keyfobwhile any door is
open. However, the hazard indicator and
horn will not function.
Unlocking doors1. Push the UNLOCK button on the keyfob
once.

The driver’s door and rear hatch/trunk lid
unlock.

The hazard indicator flashes once if all doors
are completely closed with the ignition key in
any position except the ON position.

The interior light turns on and the light timeractivates for 30 seconds when the switch is
in the DOOR position with the ignition key in
any position except the ON position.
2. Push the UNLOCK button on the keyfob
again within 5 seconds.

Passenger’s door unlocks.

The hazard indicator flashes once if all doors
are completely closed.
All doors will be locked automatically unless one
of the following operations is performed within 1
minute of pressing the UNLOCK button.

Any door or rear hatch/trunk lid is opened.

The ignition switch is turned to the ON
position.
The interior light can be turned off without
waiting for 30 seconds by turning the ignition
switch to the ON position or by locking the
doors with the keyfob.
Opening the windowsPush the UNLOCK button on the keyfob and the
driver’s door will unlock.
Continue to press the UNLOCK button for 3
seconds. All the door windows will start to be
lowered.
SPA1433C
Pre-driving checks and adjustments
3-5


04.1.22/Z33-D/V5.0


10 Index
A
ABS (Anti-lock brake system)................................ 5-20
Air bag ON/OFF switch .......................................... 1-25
Air bag system
Front (See supplemental front air bag
system) .................................................................. 1-15
Side and curtain (See supplemental side air bag
and curtain side-impact air bag system) ...... 1-17
Air bag warning labels ............................................. 1-20
Air bag warning light .................................... 1-21, 2-14
Air cleaner housing filter.......................................... 8-18
Air conditioner
Air conditioner operation ..................................... 4-3
Air conditioner service ................................ 4-3, 4-6
Air conditioner specification label .................. 9-12
Air conditioning system refrigerant and lubricant
recommendations ......................................... 4-6, 9-6
Heater and air conditioner (automatic)............ 4-3
Alcohol, drugs and driving......................................... 5-5
Anchor point location, Top tether strap .............. 1-37
Antenna ........................................................................ 4-20
Anti-lock Brake System (ABS) .............................. 5-20
Anti-lock brake warning light.................................. 2-11
Appearance care
Exterior appearance care .................................... 7-2
Interior appearance care ..................................... 7-4
Audible reminders ..................................................... 2-17
Audio operation precautions ..................................... 4-7Audio system ................................................................ 4-6
Autochanger, Compact Disc (CD) ....................... 4-18
Automatic
Anti-glare inside mirror ...................................... 3-17
Automatic adjusting function
(front windows) ................................................... 2-37
Automatic passenger seatback tilt
function......................................................... 1-5, 3-22
Automatic transmission fluid (ATF) ................ 8-12
Driving with automatic transmission........ 5-6, 5-9
Transmission selector lever lock release ...... 5-12
Avoiding collision and rollover .................................. 5-5
B
Battery .......................................................................... 8-15
Battery saver system ......................................... 2-23
Battery replacement
Remote keyless entry system............................. 3-8
Before starting the engine ......................................... 5-8
Belts (See drive belts) ............................................. 8-17
Brake
Anti-lock brake system (ABS) ......................... 5-20
Brake and clutch fluid ....................................... 8-13
Brake booster ...................................................... 8-22
Brake fluid............................................................. 8-13
Brake pedal .......................................................... 8-21
Brake pedal check ............................................. 8-21
Brake system ....................................................... 5-20Parking brake check............................... 5-14, 8-21
Parking brake operation .................................... 5-14
Warning light ....................................................... 2-12
Break-in schedule ..................................................... 5-17
Brightness control, Instrument panel ................... 2-24
Bulbcheck/instrument panel.................................. 2-11
Bulbreplacement ...................................................... 8-25
C
Capacities and recommended fuel/lubricants...... 9-2
Car phone or CB radio............................................ 4-20
Cassette player (See audio system) .................... 4-17
Catalytic converter, Three way catalyst ................. 5-3
CD care and cleaning .............................................. 4-20
Child restraints ........................................................... 1-29
Installation on front passenger seat............... 1-31
Precautions on child restraints........................ 1-29
Top tether strap anchor point location ......... 1-37
Child safety ................................................................. 1-25
Chimes, Audible reminders..................................... 2-17
Circuit breaker, Fusible link .................................... 8-23
Cleaning exterior and interior .......................... 7-2, 7-4
Clock ............................................................................ 2-28
Closing the top .......................................................... 3-24
Clutch fluid.................................................................. 8-13
Coat hook.................................................................... 2-35
Cold weather driving ................................................ 5-24
Compact Disc (CD) changer operation .............. 4-18


04.1.22/Z33-D/V5.0


G
Garage door opener, HomeLink
Universal
Transceiver .................................................................. 2-39
Gas cap ....................................................................... 3-13
Gauge ............................................................................. 2-3
Engine coolant temperature gauge .................. 2-5
Engine oil pressure gauge .................................. 2-6
Fuel gauge .............................................................. 2-6
Odometer ................................................................ 2-4
Speedometer .......................................................... 2-4
Tachometer ............................................................. 2-5
Trip computer ......................................................... 2-8
Volt meter ................................................................ 2-7
General maintenance .................................................. 8-2
Golf bag stowing....................................................... 2-34
H
Hatch, Rear hatch........................................................ 3-9
Hazard warning flasher switch............................... 2-25
Head restraints ............................................................. 1-9
Headlights
Bulbreplacement ............................................... 8-26
Headlight switch ................................................. 2-23
Xenon headlights ................................................ 2-22
Heated seats .............................................................. 2-26
Heater
Engine coolant heater ....................................... 5-25
Heater and air conditioner (automatic)............ 4-3
HomeLink
Universal Transceiver ......................... 2-39
Hood release ................................................................ 3-9
Horn .............................................................................. 2-25How to stop alarm, Vehicle security .................... 2-18
I
Ignition switch ............................................................... 5-6
Automatic transmission models................ 5-6, 5-9
Key positions .......................................................... 5-7
Manual transmission models .................. 5-7, 5-12
Immobilizer system .................................................... 2-18
Indicator lights............................................................ 2-14
Inside
Automatic anti-glare mirror............................... 3-17
Mirror...................................................................... 3-16
Inspection/maintenance (I/M) test ........................ 9-22
Instrument brightness control ................................ 2-24
Instrument panel........................................................... 2-2
Interior light replacement......................................... 8-27
Interior lights ............................................................... 2-37
Interior trunk lid release ........................................... 3-12
J
Jump starting................................................................. 6-7
K
Keyless entry (See remote keyless entry
system) ........................................................................... 3-4
Keys................................................................................. 3-2L
Labels
Air bag warning labels ...................................... 1-20
Air conditioner specification label .................. 9-12
Emission control information label ................. 9-11
Engine serial number ......................................... 9-11
F.M.V.S.S. certification label ............................ 9-11
Tire and loading information label .................. 9-12
Vehicle identification number (VIN)................ 9-10
License plate, Installing front license plate......... 9-13
Light
Air bag warning light ......................................... 1-21
Bulbreplacement ............................................... 8-25
Headlight switch ................................................. 2-23
Headlights Bulbreplacement .......................... 8-26
Interior lights ........................................................ 2-37
Replacement ........................................................ 8-25
Vanity mirror light ................................................ 2-38
Warning/indicator lights and audible
reminders .................................................. 2-11, 2-14
Xenon headlights ................................................ 2-22
Lights, Exterior and interior light replacement ... 8-27
Loading information (See vehicle loading
information) ................................................................. 9-14
Lock
Door locks ............................................................... 3-2
Power door lock .................................................... 3-2
Rear floor box ...................................................... 2-33
Rear hatch lock...................................................... 3-9
Top latch lever ..................................................... 3-21
Trunk lid lock........................................................ 3-11
Low tire pressure warning light ............................. 2-13
Low tire pressure warning system ................. 5-3, 6-2


04.1.22/Z33-D/V5.0

10-3

Luggage compartment light.................................... 2-39
M
Maintenance
Battery ................................................................... 8-15
General maintenance ........................................... 8-2
Inside the vehicle................................................... 8-3
Maintenance precautions .................................... 8-5
Maintenance requirements.................................. 8-2
Outside the vehicle............................................... 8-2
Seat belt maintenance ...................................... 1-29
Under the hood and vehicle ............................... 8-4
Malfunction indicator lamp (MIL) ........................... 2-15
Meters and gauges ..................................................... 2-3
Meters and gauges, Instrument brightness
control .......................................................................... 2-24
Mirror
Automatic anti-glare inside mirror .................. 3-17
Inside mirror ......................................................... 3-16
Outside mirror control ....................................... 3-17
Outside mirrors ................................................... 3-17
N
Net, Ventilated net seats ........................................... 1-6
New vehicle break-in ................................................ 5-17
Nissan Vehicle Immobilizer System ...................... 2-17
Engine start............................................................. 5-7
O
Obtaining an air bag ON/OFF switch ................. 1-25Odometer ....................................................................... 2-4
Oil
Capacities and recommended fuel/
lubricants ................................................................. 9-2
Changing engine oil and filter ......................... 8-10
Checking engine oil level ................................. 8-10
Engine oil .............................................................. 8-10
Engine oil pressure gauge .................................. 2-6
Engine oil viscosity ............................................... 9-5
Opening the top ........................................................ 3-23
Outside mirror control .............................................. 3-17
Outside mirrors .......................................................... 3-17
Overheat, If your vehicle overheats ......................... 6-9
Owner’s Manual/Service Manual order
information................................................................... 9-24
P
Parking
Brake check ......................................................... 8-21
Parking brake check .......................................... 5-14
Parking brake operation .................................... 5-14
Parking on hills .................................................... 5-14
Parking/parking on hills ........................................... 5-18
Phone, Car phone or CB radio ............................. 4-20
Power
Power door lock .................................................... 3-2
Power outlet ......................................................... 2-28
Power steering fluid ........................................... 8-13
Power steering system ...................................... 5-19
Power windows................................................... 2-35
Pre-tensioner seat belt system .............................. 1-19
Precautions
Audio operation ..................................................... 4-7Braking precautions ........................................... 5-20
Child restraints .................................................... 1-29
Cruise control ...................................................... 5-15
Maintenance ........................................................... 8-5
Seat belt usage ................................................... 1-23
Supplemental restraint system ........................ 1-10
When starting and driving .................................. 5-2
Push starting ................................................................. 6-9
R
Radio ............................................................................... 4-6
Car phone or CB radio ..................................... 4-20
FM-AM radio with cassette player and Compact
Disc (CD) changer ............................................. 4-13
FM-AM radio with Compact Disc (CD)
player ........................................................................ 4-9
Readiness for inspection/maintenance (I/M) test
(US only)...................................................................... 9-22
Rear floor box ............................................................. 2-33
Rear hatch ..................................................................... 3-9
Rear parcel box ......................................................... 2-33
Rear power point....................................................... 2-28
Rear window and outside mirror defroster
switch ........................................................................... 2-21
Registering your vehicle in another country ....... 9-10
Remote keyless entry system ................................... 3-4
Reporting safety defects (US only) ...................... 9-22
Rollover........................................................................... 5-5
S
Safety
Child seat belts ................................................... 1-25


04.1.22/Z33-D/V5.0

10-4

Tire pressure ........................................................ 8-30
Tire rotation .......................................................... 8-34
Types of tires ....................................................... 8-33
Wheel/tire size ....................................................... 9-9
Wheels and tires ................................................ 8-30
Top
If the top does not open or close
electrically ............................................................. 3-24
Soft top operation .............................................. 3-18
Top latch lever ..................................................... 3-21
Top tether strap child restraint........................ 1-36
Towing
Tow truck towing ................................................ 6-10
Towing a trailer.................................................... 9-16
Towing load/specification chart ...................... 9-16
Towing safety....................................................... 9-17
Traction control system (TCS)............................... 5-22
Traction control system (TCS) off switch ........... 2-27
Trailer towing .............................................................. 9-16
Transceiver, HomeLink
Universal
Transceiver .................................................................. 2-39
Transmission
Automatic transmission fluid (ATF) ................ 8-12
Driving with automatic transmission........ 5-6, 5-9
Driving with manual transmission .......... 5-7, 5-12
Transmission selector lever lock release ...... 5-12
Transmitter (See remote keyless entry system) ... 3-4
Traveling or registering your vehicle in another
country ......................................................................... 9-10
Trip computer ............................................................... 2-8
Trip odometer ............................................................... 2-9
Trunk
Interior trunk lid release .................................... 3-12
Secondary trunk lid release ............................. 3-13Turn signal switch ..................................................... 2-24
U
Underbody cleaning .................................................... 7-3
Uniform tire quality grading .................................... 9-21
Up-shift indicator (M/T models) ............................ 5-13
Up-shift indicator setting (rpm) (M/T models) ... 2-10
V
Vanity mirror light ...................................................... 2-38
Vehicle
Dimensions and weights ..................................... 9-9
Identification number (VIN)............................... 9-10
Loading information............................................ 9-14
Recovery (freeing a stuck vehicle) ................. 6-12
Security system ................................................... 2-17
Vehicle dynamic control (VDC) off switch ... 2-27
Vehicle dynamic control (VDC) system ........ 5-22
Ventilated net seats..................................................... 1-6
Ventilators ...................................................................... 4-2
Volt meter ...................................................................... 2-7
W
Warning labels, Air bag warning labels .............. 1-20
Warning light
Air bag warning light .............................. 1-21, 2-14
Anti-lock brake warning light ........................... 2-11
Brake warning light ............................................ 2-12
Door open warning light ................................... 2-12
Low tire pressure warning light ...................... 2-13Warning lights ............................................................ 2-11
Warning, Hazard warning flasher switch ............ 2-25
Warning, Low tire pressure warning
system.................................................................... 5-3, 6-2
Warning, Warning/indicator lights and audible
reminders ..................................................................... 2-11
Warranty, Emission control system warranty ..... 9-22
Washer switch
Rear window wiper and washer switch........ 2-21
Windshield wiper and washer switch ........... 2-20
Washing ......................................................................... 7-2
Waxing............................................................................ 7-3
Weights (See dimensions and weights) ............... 9-9
Wheel/tire size.............................................................. 9-9
Wheels and tires ....................................................... 8-30
Cleaning aluminum alloy wheels ....................... 7-4
Window washer fluid ............................................... 8-14
Window(s)
Automatic adjusting function ........................... 2-37
Cleaning................................................................... 7-3
Power windows................................................... 2-35
Windshield wiper and washer switch .................. 2-20
Wiper
Rear window wiper and washer switch........ 2-21
Windshield wiper and washer switch ........... 2-20
Wiper blades ....................................................... 8-19
X
Xenon headlights....................................................... 2-22


04.1.22/Z33-D/V5.0

10-6
