On slippery surfaces such as wet asphalt roads,
vehicle wheels may spin when the vehicle is
accelerated. This wheel spin reduces accelera-
tion, or causes the vehicle to swerve, thus
decreasing vehicle stability.
When the vehicle drive wheels begin to spin, the
traction control system (TCS) controls the en-
gine torque using an electronic control system,
and it also controls automatic control shifting if
necessary (for automatic transmission models).
This reduces spinning of the drive wheels, and
result in improved vehicle acceleration perfor-
mance. It also improves the vehicle stability by
swerving motion.

When the traction control system is operat-
ing, the slip indicator light in the meter panel
blinks.

If the slip indicator light blinks, the vehicle is
under slippery conditions. Be sure to drive
carefully. See “Slip indicator light” and “Trac-
tion control system (TCS) off indicator light”
in the “2. Instruments and controls” section.

Indicator light
If a malfunction occurs in the traction control
system, the SLIP and
indicator lights
come on in the meter panel.
As long as these indicator lights are on, the
traction control function (except the ABS) is
canceled. The vehicle will behaves like amodel without the traction control system.
WARNING
The traction control system is designed
to prevent the wheels from spinning.
However, it does not prevent vehicle
slipping or spinning due to abrupt steer-
ing operation at high speeds or by care-
less or dangerous driving techniques.
Be especially careful when driving on
slippery surfaces and always drive
safely.When driving on slippery surfaces or suddenly
avoiding obstacles on roads, the vehicle might
swerve or slip. With the vehicle dynamic control
(VDC) system, sensors detect these movements
and control the braking and engine output to
help improve vehicle stability while driving.

When the vehicle dynamic control system is
operating, the slip indicator light in the meter
panel blinks.

When only the traction control system (TCS)
portion of the vehicle dynamic control system
is operating, the slip indicator light will also
blink.

If the slip indicator light blinks, the vehicle is
under slippery conditions. Be sure to drive
carefully. See “Slip indicator light” and “Ve-
hicle dynamic control (VDC) off indicator
light” in the “2. Instruments and controls”
section.

Indicator light
If a malfunction occurs in the system, the
SLIP and
indicator lights come on in
the meter panel.
As long as these indicator lights are on, the
vehicle dynamic control function (except the
ABS) is canceled.
The VDC system uses a Brake Limited Slip
Differential (LSD) system to improve vehicle
TRACTIONCONTROL SYSTEM
(TCS) (if so equipped)VEHICLE DYNAMIC CONTROL
(VDC) SYSTEM (if so equipped)5-22
Starting and driving


04.1.22/Z33-D/V5.0


traction. The brake LSD system works when one
of the driving wheels is spinning on a slippery
surface. The brake LSD system brakes the spin-
ning wheel to distribute the driving power to the
other driving wheel.
If the vehicle is operated with the vehicle dy-
namic control system turned off, all VDC and
TCS functions will be turned off. The brake LSD
system and ABS will still operate with the VDC
system off. If the brake LSD system or the ABS
is activated, the slip indicator light will blink and
you may hear a clunk noise and/or feel a pulsa-
tion in the brake pedal. This is normal.
While the VDC system is operating, you may feel
a pulsation in the brake pedal and hear a noise or
vibration from under the hood. This is normal and
indicates that the VDC system is working prop-
erly.
The computer has a built in diagnostic feature
that tests the system each time you start the
engine and move the vehicle forward or in
reverse at a slow speed. When the self-test
occurs, you may hear a clunk noise and/or feel a
pulsation in the brake pedal. This is normal and is
not an indication of a malfunction.
WARNING

The vehicle dynamic control system
is designed to help improve driving
stability but does not prevent acci-
dents due to abrupt steering opera-
tion at high speeds or by careless or
dangerous driving techniques. Re-
duce vehicle speed and be especially
careful when driving and cornering
on slippery surfaces and always drive
carefully.

If brake related parts such as brake
pads, rotors and calipers are not
standard equipment or are extremely
deteriorated, the vehicle dynamic
control system may not operate prop-
erly and the vehicle dynamic control
off indicator light may come on.

Do not modify the vehicle’s suspen-
sion. The vehicle dynamic control
system may not operate correctly.

If suspension parts such as shock
absorbers, struts, springs and bush-ings are not standard equipment or
are extremely deteriorated, the ve-
hicle dynamic control system may not
operate properly and the vehicle dy-
namic control off indicator light may
come on.

When driving on extremely inclined
surfaces such as higher banked cor-
ners, the vehicle dynamic control sys-
tem may not operate properly and the
vehicle dynamic control off indicator
light may come on. Do not drive on
these types of roads.

If the tires other than the recom-
mended ones are used, the vehicle
dynamic control system may not op-
erate properly or the vehicle dynamic
control off indicator light may come
on.

The vehicle dynamic control system
is not a substitute for winter tires or
tire chains on a snow covered road.
Starting and driving
5-23


04.1.22/Z33-D/V5.0


ice and snow from the windows and wiper
blades.

a sturdy, flat board to be placed under the
jack to give it firm support.

a shovel to dig the vehicle out of snow-drifts.

extra window washer fluid to refill the reser-
voir tank.
DRIVING ON SNOW OR ICE
WARNING

Wet ice (32°F, 0°C and freezing rain),
very cold snow or ice can be slick and
very hard to drive on. The vehicle will
have a lot less traction or grip under
these conditions. Try to avoid driving
on wet ice until the road is salted or
sanded.

Whatever the condition, drive with
caution. Accelerate and slow down
with care. If accelerating or down-
shifting too fast, the drive wheels will
lose even more traction.

Allow more stopping distance underthese conditions. Braking should be
started sooner than on dry pavement.

Allow greater following distances on
slippery roads.

Watch for slippery spots (glare ice).
These may appear on an otherwise
clear road in shaded areas. If a patch
of ice is seen ahead, brake before
reaching it. Try not to brake while
actually on the ice, and avoid any
sudden steering maneuvers.

Do not use cruise control on slippery
roads.

Snow can trap dangerous exhaust
gases under your vehicle. Keep snow
clear of the exhaust pipe and from
around your vehicle.
ENGINE BLOCK HEATER (if so
equipped)An engine block heater to assist extreme cold
temperature starting is available through your
NISSAN dealer.
WARNING
Do not use your heater with an un-
grounded electrical system or two-
pronged (cheater) adapters. You can be
injured by an electrical shock if you use
an ungrounded connection.
Starting and driving
5-25


04.1.22/Z33-D/V5.0


WARNING

Properly secure all cargo to help pre-
vent it from sliding or shifting. Do not
place cargo higher than the seat-
backs. In a sudden stop or collision,
unsecured cargo could cause per-
sonal injury.

Do not load your vehicle any heavier
than the GVWR or the maximum front
and rear GAWRs. If you do, parts on
your vehicle can break, or it can
change the way your vehicle handles.
This could result in loss of control
and cause personal injury.

Overloading not only could shorten
the life of your vehicle and the tires,
but also could lead to unsafe vehicle
handling and long braking distance.
This could cause a premature tire
malfunction, which could result in a
serious accident and personal injury.
Malfunctions caused by overloading
are not covered by your warranty.Roadster model:
Do not tow a trailer with your vehicle.
Coupe model:
Your new vehicle was designed to be used
primarily to carry passengers and cargo. Re-
member that towing a trailer places additional
loads on your vehicle’s engine, drive train, steer-
ing, braking and other systems.
ANISSAN Trailer Towing Guide(US only) is
available from a NISSAN dealer. This guide
includes information on trailer towing ability and
the special equipment required for proper tow-
ing.
MAXIMUM LOAD LIMITS
Maximum trailer loadsNever allow the total trailer load to exceed 1,000
lb(454 kg). The total trailer load equals trailer
weight plus its cargo weight. Towing loads
greater than 1,000 lb(454 kg) or using improper
towing equipment could adversely affect vehicle
handling, braking and performance.
The ability of your vehicle to tow a trailer is not
only related to the maximum trailer loads, but
also the places you plan to tow. Tow weights
appropriate for level highway driving may have to
be reduced on very steep grades or in low
traction situations (for example, on slippery boat
ramps).
WARNING
Vehicle damage resulting from im-
proper towing procedures are not cov-
ered by NISSAN warranties. A NISSAN
Trailer Towing Guide (U.S. only) contain-
ing information on trailer towing ability
and the special equipment required may
be obtained from a NISSAN dealer.
TI1011M
TOWING A TRAILER
9-16
Technical and consumer information


04.1.22/Z33-D/V5.0


DOT (Department Of Transportation) Quality
Grades: All passenger car tires must conform to
federal safety requirements in addition to these
grades.
Quality grades can be found where applicable
on the tire sidewall between tread shoulder and
maximum section width. For example:
Treadwear 200 Traction AA Temperature ATreadwearTreadwear grade is a comparative rating based
on tire wear rate when tested under controlled
conditions on specified government test
courses. For example, a tire graded 150 would
wear one and a half (1-1/2) times as well on the
government course as a tire graded 100. How-
ever, relative tire performance depends on actual
driving conditions, and may vary significantly
from the norm due to variations in driving habits,
service practices and differences in road char-
acteristics and climate.Traction AA, A, B and CThe traction grades, from highest to lowest, are
AA, A, B, and C. Those grades represent the
tire’s ability to stop on wet pavement as mea-
sured under controlled conditions on specified
government test surfaces of asphalt and con-crete. A tire marked C may have poor traction
performance.
WARNING
The traction grade assigned to your ve-
hicle tires is based on straight-ahead
braking traction tests, and does not in-
clude acceleration, cornering, hydro-
planing, or peak traction characteristics.Temperature A, B and CTemperature grades are A (the highest), B, and
C. They represent a tire’s resistance to heat
build-up, and its ability to dissipate heat when
tested under controlled conditions on a speci-
fied indoor laboratory test wheel. Sustained high
temperature can cause tire material to degener-
ate, reducing tire life. Excessive temperatures
can lead to sudden tire failure. Grade C corre-
sponds to a performance level which all passen-
ger car tires must meet under the Federal Motor
Vehicle Safety Standard No. 109. Grades A and
B represent higher levels of performance on
laboratory test wheels than the minimum re-
quired by law.
WARNING
The temperature grade for this tire is
established for a tire that is properly
inflated and not overloaded. Excessive
speed, underinflation, or excessive
loading, either separately or in combi-
nation, can cause heat buildup and pos-
sible tire failure.
UNIFORM TIRE QUALITY
GRADING
Technical and consumer information
9-21


04.1.22/Z33-D/V5.0


Reporting safety defects (US only)................ 9-22
Towing safety....................................................... 9-17
Seat
Belt warning light................................................ 1-23
Lever, Tilting passenger’s seat .......................... 1-7
Seat belt(s)
Child safety .......................................................... 1-25
Infants and small children ................................. 1-25
Injured persons.................................................... 1-26
Larger children .................................................... 1-26
Pre-tensioner seat belt system ....................... 1-19
Precautions on seat belt usage ...................... 1-23
Pregnant women ................................................. 1-26
Seat belt cleaning ................................................. 7-5
Seat belt extenders ............................................ 1-28
Seat belt maintenance ...................................... 1-29
Seat belts ............................................................. 1-23
Three-point type.................................................. 1-26
Seat(s)
Heated seats........................................................ 2-26
Seats ........................................................................ 1-2
Ventilated net seats .............................................. 1-6
Secondary rear hatch release ................................ 3-10
Secondary trunk lid release .................................... 3-13
Security system, Vehicle security system ........... 2-17
Security systems (Nissan Vehicle Immobilizer
System), Engine start ............................................... 2-18
Servicing air conditioner ................................... 4-3, 4-6
Shift lock release ....................................................... 5-12
Shifting
Automatic transmission .............................. 5-6, 5-9
Manual transmission ................................. 5-7, 5-12
Side air bag system (See supplemental side air bag
and curtain air bag system) .................................... 1-17Soft top
Soft top care and cleaning ................................. 7-2
Soft top indicator light ........................... 2-16, 3-22
Soft top operation .............................................. 3-18
Care of the soft top and the vehicle body... 3-27
If the top does not open or close
electrically ............................................................. 3-24
Spark plugs................................................................. 8-17
Speed, Average speed............................................... 2-9
Speed, Speed indicator ............................................. 2-8
Speedometer ................................................................ 2-4
Starting
Before starting the engine .................................. 5-8
Jump starting .......................................................... 6-7
Precautions when starting and driving ............ 5-2
Push starting .......................................................... 6-9
Starting the engine ............................................... 5-8
Steering
Power steering fluid ........................................... 8-13
Power steering system ...................................... 5-19
Tilting steering wheel......................................... 3-15
Stopwatch ..................................................................... 2-9
Storage ........................................................................ 2-29
Stowing golf bags ..................................................... 2-34
Sun visor, Extension ................................................. 3-16
Sunglasses holder .................................................... 2-30
Supplemental air bag warning labels................... 1-20
Supplemental air bag warning light .......... 1-21, 2-14
Supplemental restraint system............................... 1-10
Precautions on supplemental restraint
system.................................................................... 1-10
Supplemental side and curtain air bag
system .......................................................................... 1-17Switch
Hazard warning flasher switch ........................ 2-25
Headlight switch ................................................. 2-23
Ignition switch ........................................................ 5-6
Ignition switch automatic transmission
models ............................................................ 5-6, 5-9
Ignition switch manual transmission
models .......................................................... 5-7, 5-12
Power door lock switch....................................... 3-4
Rear window and outside mirror defroster
switch..................................................................... 2-21
Traction control system (TCS) off switch .... 2-27
Turn signal switch .............................................. 2-24
Vehicle dynamic control (VDC) off switch ... 2-27
T
Tachometer.................................................................... 2-5
Temperature gauge, Engine coolant temperature
gauge .............................................................................. 2-5
Theft (Nissan Vehicle Immobilizer System), Engine
start ............................................................................... 2-18
Three way catalyst ....................................................... 5-3
Tilting passenger’s seat ............................................. 1-7
Tilting steering wheel ............................................... 3-15
Tire
Flat tire ..................................................................... 6-2
Low tire pressure warning system........... 5-3, 6-2
Pressure indicator............................................... 2-10
Pressure, Low tire pressure warning light ... 2-13
Uniform tire quality grading .............................. 9-21
Tires
Spare tire .............................................................. 8-36
Tire chains ............................................................ 8-34


04.1.22/Z33-D/V5.0

10-5

Tire pressure ........................................................ 8-30
Tire rotation .......................................................... 8-34
Types of tires ....................................................... 8-33
Wheel/tire size ....................................................... 9-9
Wheels and tires ................................................ 8-30
Top
If the top does not open or close
electrically ............................................................. 3-24
Soft top operation .............................................. 3-18
Top latch lever ..................................................... 3-21
Top tether strap child restraint........................ 1-36
Towing
Tow truck towing ................................................ 6-10
Towing a trailer.................................................... 9-16
Towing load/specification chart ...................... 9-16
Towing safety....................................................... 9-17
Traction control system (TCS)............................... 5-22
Traction control system (TCS) off switch ........... 2-27
Trailer towing .............................................................. 9-16
Transceiver, HomeLink
Universal
Transceiver .................................................................. 2-39
Transmission
Automatic transmission fluid (ATF) ................ 8-12
Driving with automatic transmission........ 5-6, 5-9
Driving with manual transmission .......... 5-7, 5-12
Transmission selector lever lock release ...... 5-12
Transmitter (See remote keyless entry system) ... 3-4
Traveling or registering your vehicle in another
country ......................................................................... 9-10
Trip computer ............................................................... 2-8
Trip odometer ............................................................... 2-9
Trunk
Interior trunk lid release .................................... 3-12
Secondary trunk lid release ............................. 3-13Turn signal switch ..................................................... 2-24
U
Underbody cleaning .................................................... 7-3
Uniform tire quality grading .................................... 9-21
Up-shift indicator (M/T models) ............................ 5-13
Up-shift indicator setting (rpm) (M/T models) ... 2-10
V
Vanity mirror light ...................................................... 2-38
Vehicle
Dimensions and weights ..................................... 9-9
Identification number (VIN)............................... 9-10
Loading information............................................ 9-14
Recovery (freeing a stuck vehicle) ................. 6-12
Security system ................................................... 2-17
Vehicle dynamic control (VDC) off switch ... 2-27
Vehicle dynamic control (VDC) system ........ 5-22
Ventilated net seats..................................................... 1-6
Ventilators ...................................................................... 4-2
Volt meter ...................................................................... 2-7
W
Warning labels, Air bag warning labels .............. 1-20
Warning light
Air bag warning light .............................. 1-21, 2-14
Anti-lock brake warning light ........................... 2-11
Brake warning light ............................................ 2-12
Door open warning light ................................... 2-12
Low tire pressure warning light ...................... 2-13Warning lights ............................................................ 2-11
Warning, Hazard warning flasher switch ............ 2-25
Warning, Low tire pressure warning
system.................................................................... 5-3, 6-2
Warning, Warning/indicator lights and audible
reminders ..................................................................... 2-11
Warranty, Emission control system warranty ..... 9-22
Washer switch
Rear window wiper and washer switch........ 2-21
Windshield wiper and washer switch ........... 2-20
Washing ......................................................................... 7-2
Waxing............................................................................ 7-3
Weights (See dimensions and weights) ............... 9-9
Wheel/tire size.............................................................. 9-9
Wheels and tires ....................................................... 8-30
Cleaning aluminum alloy wheels ....................... 7-4
Window washer fluid ............................................... 8-14
Window(s)
Automatic adjusting function ........................... 2-37
Cleaning................................................................... 7-3
Power windows................................................... 2-35
Windshield wiper and washer switch .................. 2-20
Wiper
Rear window wiper and washer switch........ 2-21
Windshield wiper and washer switch ........... 2-20
Wiper blades ....................................................... 8-19
X
Xenon headlights....................................................... 2-22


04.1.22/Z33-D/V5.0

10-6
