2004 NISSAN 350Z lights

1. Hood (P.3-9)
2. Windshield wiper and washer
— Switch (P.2-20)
— Wiper replacement (P.8-20)
3. Interior light (P.2-37)
4. Power windows (P.2-35)
5. Towing hook installation (P.6-10)
6. Headlight, park and turn signal lights
— Switch (P.2-22)
— Bulbreplacement (P.8-25)
7. Tires
— Wheel and tires (P.8-30, P.9-9)
— Flat tire (P.6-2)
8. Outside mirrors (P.3-17)
9. Doors
— Keys (P.3-2)
— Door locks (P.3-3)
— Keyfob(P.3-4)
SSI0001
EXTERIOR FRONT0-2
Illustrated table of contents


04.5.17/Z33-D/V5.0


Coupe models1. Antenna (P.4-20)
2. Rear hatch release switch (P.3-10)
3. Rear window defroster (P.2-21)
4. High-mounted stop light (Bulb) (P.8-27)
5. Rear window wiper and washer
(P.2-21)
6. License plate lights (Bulbreplacement)
(P.8-27)
7. Rear hatch release (secondary) (P.3-10)
8. Luggage compartment light (P.2-39, P.8-27)
9. Back-up, Turn signal light (Bulbreplacement)
(P.8-27)
10. Side marker, Stop/Tail light (Bulbreplace-
ment) (P.8-27)
11. Fuel
— Fuel filler lid (P.3-13)
— Fuel recommendation (P.9-3)
SSI0002
EXTERIOR REAR
Illustrated table of contents
0-3


04.5.17/Z33-D/V5.0


Roadster models1. Antenna (P.4-20)
2. Trunk lid release switch (P.3-11)
3. Trunk light (P.2-39, P.8-27)
4. High-mounted stop light (Bulb) (P.8-27)
5. Rear window defroster (P.2-21)
6. Soft top (P.3-18)
7. Interior trunk lid release (P.3-12)
8. License plate lights (Bulbreplacement)
(P.8-27)
9. Back-up, Turn signal light (Bulbreplacement)
(P.8-27)
10. Side marker, Stop/Tail light (Bulbreplace-
ment) (P.8-27)
11. Fuel
— Fuel filler lid (P.3-13)
— Fuel recommendation (P.9-3)
SSI0003
0-4
Illustrated table of contents


04.5.17/Z33-D/V5.0


2 Instruments and controlsInstrument panel ..................................................................... 2-2
Meters and gauges ............................................................... 2-3
Speedometer and odometer ......................................... 2-4
Tachometer ........................................................................ 2-5
Engine coolant temperature gauge ............................. 2-5
Fuel gauge ......................................................................... 2-6
Engine oil pressure gauge ............................................. 2-6
Volt meter ......................................................................... 2-7
Trip computer .................................................................. 2-8
Warning/indicator lights and audible reminders ......... 2-11
Checking bulbs .............................................................. 2-11
Warning lights ................................................................ 2-11
Indicator lights ................................................................ 2-14
Audible reminders.......................................................... 2-17
Security systems.................................................................. 2-17
Vehicle security system................................................ 2-17
Nissan vehicle immobilizer system (NVIS) ............. 2-18
Windshield wiper and washer switch ............................ 2-20
Rear window wiper and washer switch
(Coupe models) .................................................................. 2-21
Rear window and outside mirror (if so equipped)
defroster switch .................................................................. 2-21Headlight and turn signal switch ................................... 2-22
Xenon headlights (if so equipped) .......................... 2-22
Headlight switch ........................................................... 2-23
Daytime running light system (Canada only) ........ 2-23
Turn signal switch ........................................................ 2-24
Instrument brightness control ................................... 2-24
Hazard warning flasher switch ....................................... 2-25
Horn ....................................................................................... 2-25
Heated seats (if so equipped) ........................................ 2-26
Vehicle dynamic control (VDC) off switch
(if so equipped) .................................................................. 2-27
Traction control system (TCS) off switch
(if so equipped) .................................................................. 2-27
Clock ..................................................................................... 2-28
Adjusting the time ........................................................ 2-28
Power outlet ........................................................................ 2-28
Storage ................................................................................. 2-29
Instrument pocket (except for navigation system
equipped models) ........................................................ 2-29
Sunglasses holder (Coupe models) ........................ 2-30
Tray .................................................................................. 2-31
Cup holders ................................................................... 2-31


04.5.17/Z33-D/V5.0


Console box .................................................................. 2-32
Rear floor box ................................................................ 2-33
Rear parcel box ............................................................ 2-33
Stowing golf bags ......................................................... 2-34
Coat hook .............................................................................. 2-35
Windows .............................................................................. 2-35
Power windows ............................................................ 2-35
Automatic adjusting function ...................................... 2-37
Interior lights ........................................................................ 2-37
Interior ............................................................................. 2-37
Map .................................................................................. 2-38
Vanity mirror light (if so equipped) ................................ 2-38Luggage compartment light (Coupe models) ............. 2-39
Trunk light (Roadster models).......................................... 2-39
HomeLink
universal transceiver (if so equipped) .... 2-39
Programming HomeLink
........................................... 2-40
Programming HomeLinkfor Canadian
customers ....................................................................... 2-41
Operating the HomeLinkuniversal
transceiver ...................................................................... 2-42
Programming trouble diagnosis ................................ 2-42
Clearing the programmed information .................... 2-42
Reprogramming a single HomeLink
button ........ 2-42
If your vehicle is stolen ............................................... 2-42


04.5.17/Z33-D/V5.0


Combination meter:
1. Warning/Indicator lights
2. Turn signal/hazard indicator lights
3. Tachometer
4. Speedometer5. Instrument brightness control switch
(See “Headlight and turn signal switch” later
in this section.)
6. Fuel gauge
7. Engine coolant temperature gauge8. Automatic transmission position indicator or
Manual transmission shift up indicator
(See “Driving the vehicle” in the “5. Starting
and driving” section.)
9. Reset knobfor trip odometer
10. Odometer (Total/Twin trip)
11. Trip computer setting switch
(See “Trip computer” later in this section.)
12. Trip computer mode switch
(See “Trip computer” later in this section.)
SIC2233
METERS AND GAUGES
Instruments and controls
2-3


04.5.17/Z33-D/V5.0


or
Anti-lock brake warning light
Low washer fluid warning light
Malfunction indicator lamp (MIL)
Automatic transmission check warning
light (A/T models)
Seat belt warning light
Slip indicator light
or
Brake warning light
Supplemental air bag warning light
Traction control system (TCS) off indica-
tor light (if so equipped)
Charge warning light
Automatic transmission position indicator
light (A/T models)
Vehicle dynamic control (VDC) off indica-
tor light (if so equipped)
Door open warning light
Cruise main switch indicator light
(if so equipped)
Soft top indicator light (Roadster models)
Engine oil pressure warning light
Cruise set switch indicator light
(if so equipped)
Turn signal/hazard indicator lights
Low tire pressure warning light
(if so equipped)
High beam indicator light (Blue)
CHECKING BULBSApply the parking brake and turn the ignition key
to ON without starting the engine. The following
lights will come on:
,
or
,
,
The following lights come on briefly and then go
off:
,
or
,
,
,
,
,
If any light fails to come on, it may indicate a
burned-out bulb or an open circuit in the elec-trical system. Have the system repaired
promptly.
WARNING LIGHTS
or
Anti-lock brake
warning light
When the ignition switch is turned to the ON
position, the anti-lock brake warning light will
illuminate and then turn off. This indicates the
anti-lock brake system (ABS) is operational.
If the light comes on while the engine is running,it may indicate the anti-lock brake system is not
functioning properly. Have the system checked
by your NISSAN dealer.
If a malfunction occurs in the system, the anti-
lock function of the brake will cease operation
but the ordinary brakes will continue to operate.
See “Anti-lock brake system (ABS)” in the “5.
Starting and driving” section for further details.
If the light comes on while you are driving,
contact your NISSAN dealer for repair.
WARNING/INDICATOR LIGHTS
AND AUDIBLE REMINDERS
Instruments and controls
2-11


04.5.17/Z33-D/V5.0


function. Contact your NISSAN
dealer as soon as possible for tire
replacement and/or system reset-
ting.
CAUTION

The low tire pressure warning system
is not a substitute for the regular tire
pressure check. Be sure to check the
tire pressure regularly.

If the vehicle is being driven at
speeds of less than 20 MPH (32
km/h), the low tire pressure warning
system may not operate correctly.

Be sure to install the specified size
tires to the front and rear.
Low washer fluid warning light
This light comes on when the washer fluid is at a
low level. Add washer fluid as necessary. See
“Window washer fluid” in the “8. Maintenance
and do-it-yourself” section.
Seat belt warning light
The seat belt warning light and chime remind you
to fasten seat belts. The light illuminates when-
ever the ignition key is turned to ON, and will
remain illuminated until the driver’s seat belt is
fastened.
See “Seat belts” in the “1. Safety — Seats, seat
belts and supplemental restraint system” section
for precautions on seat belt usage.
Supplemental air bag warning
light
After turning the ignition key to the ON position,
the supplemental air bag warning light will illu-
minate. The supplemental air bag warning light
will turn off after about 7 seconds if the system is
operational.
If any of the following conditions occur, the
supplemental front air bag, supplemental side air
bag and curtain side-impact air bag systems,
and pre-tensioner seat belt need servicing and
your vehicle must be taken to your nearest
NISSAN dealer.

The supplemental air bag warning light re-
mains on after approximately 7 seconds.

The supplemental air bag warning light
flashes intermittently.
The supplemental air bag warning light does
not come on at all.
Unless checked and repaired, the Supplemental
Restraint System and/or the pre-tensioner seat
belt may not function properly. For additional
information, see “Supplemental restraint system”
in the “1. Safety — Seats, seat belts and supple-
mental restraint system” section.
WARNING
If the supplemental air bag warning
light is on, it could mean that the
supplemental front air bag, supplemen-
tal side air bag and curtain side-impact
air bag systems and/or pre-tensioner
seat belt system will not operate in an
accident.INDICATOR LIGHTS
Automatic transmission
position indicator light (A/T
models)
When the ignition key is turned to the ON
position, the indicator in the tachometer shows
the automatic transmission selector lever posi-
2-14
Instruments and controls


04.5.17/Z33-D/V5.0
