2004 NISSAN 350Z warning

Passenger’s side:
To use the cup holder, push it once
1
and pull
it out
2
until a click is heard.Avoid applying
excessive force to the cup holder.
CONSOLE BOXPushing the button
1
will open the lid slightly,
then pull up the lid manually
2. The center
console box is equipped with a cup holder
A
and a card holder
B. The cup holder
Acan be
removed by pulling it up.
WARNING
The center console box should not be
used while driving so full attention may
be given to vehicle operation.If objects (coins, etc.) fall into the rear section of
the center console box, remove the rear wall
C
of the box as shown, and pick up the objects.
CAUTION
Be careful not to pinch your fingers
when removing the rear wall
C.
SIC1974
SIC1976
SIC2218
2-32
Instruments and controls


04.5.17/Z33-D/V5.0


REAR FLOOR BOXThe rear floor box is located behind the passen-
ger’s seat. Fold the seat to use the rear floor box.
When locking or unlocking the rear floor box, use
the master key.
The rear floor box may be opened by pulling the
handle. The rear floor box light illuminates when
the box lid is opened with the headlight switch
ON.The rear floor box has another storage space
under the bottom plate.
WARNING
Keep rear floor box lid closed while
driving to help prevent injury in an acci-
dent or a sudden stop.
REAR PARCEL BOXPush the upper part of the lid to open the rear
parcel box. For models without the Navigation
system, two boxes are available.
WARNING

The rear parcel box should not be
used while driving so full attention
may be given to vehicle operation.

Keep rear parcel box lid closed while
driving to help prevent injury in an
SIC1975
SIC2377
SIC1977
Instruments and controls
2-33


04.5.17/Z33-D/V5.0


Roadster modelsNormally, one standard golf bag C can be
stowed in the trunk. Insert the top of the golf bag
into left side of the trunk
1
then put the bag
down
2.The hooks are located above the side windows
as shown in the illustration.
CAUTION:
Do not place items which are more than 2
lb (1 kg) on the hook.
POWER WINDOWS
WARNING

Make sure that all passengers have
their hands, etc. inside the vehicle
while it is in motion and before clos-
ing the windows. Use the window
lock switch to prevent unexpected
use of the power windows.

Do not leave children unattended in-
side the vehicle. They could unknow-
ingly activate switches or controls
and become trapped in a window.
Unattended children could become
involved in serious accidents.
SIC2237
SIC2378
COAT HOOK WINDOWS
Instruments and controls
2-35


04.5.17/Z33-D/V5.0


45 seconds after the ignition key is turned to the
OFF position.
Depending on the environment or driving
conditions, the auto reverse function may
be activated if an impact or load similar to
something being caught in the window
occurs.
WARNING
There are some small distances imme-
diately before the closed position which
cannot be detected. Make sure that all
passengers have their hands, etc., in-
side the vehicle before closing the win-
dow.Automatic window lowering (Roadster
models)When the soft top operating switch is pressed,
the power windows will automatically be low-
ered completely. The windows do not rise auto-
matically after the soft top open/close operation
is completed. Use the power window switches
to raise them.
AUTOMATIC ADJUSTING
FUNCTION
CAUTION
When the battery cable is removed from
the battery terminal, do not close either
of the front doors. The automatic win-
dow adjusting function will not work,
and the side roof panel/top side rail
may be damaged.
The power window has an automatic adjusting
function. When the door is being opened, the
window is automatically lowered slightly to avoid
contact between the window and the side roof
panel/top side rail. When the door is closed, the
window is automatically raised slightly.
INTERIORThe interior light has a two-position switch. (
A:
DOOR,
B: OFF)
When the switch is in the DOOR position, the
light will illuminate when a door is opened.
The light will stay on for about 30 seconds when:

The doors are unlocked by the keyfob, a key
or the power door lock switch while all doors
are closed.

The driver’s door is opened and then closed
while the key is removed from the ignition
switch.
SIC1980A
Coupe models
INTERIOR LIGHTS
Instruments and controls
2-37


04.5.17/Z33-D/V5.0


WARNING

Do not use the HomeLink
Universal
Transceiver with any garage door
opener that lacks safety stop and
reverse features as required by fed-
eral safety standards. (These stan-
dards became effective for opener
models manufactured after April 1,
1982). A garage door opener which
cannot detect an object in the path of
a closing garage door and then auto-
matically stop and reverse, does not
meet current federal safety stan-
dards. Using a garage door opener
without these features increases the
risk of serious injury or death.

During programming, your garage
door or gate may open or close.
Make sure that people and objects
are clear of the garage door or gate
that you are programming.

Your vehicle’s engine should be
turned off while programming the
HomeLink
Universal Transceiver.
PROGRAMMING HomeLinkTo program your HomeLink
Transceiver to op-
erate a garage door, gate, or entry door opener,
home or office lighting, you need to be at the
same location as the device. Note: Garage door
openers (manufactured after 1996) have “rolling
code protection”. To program a garage door
opener equipped with “rolling code protection”;
you will need to use a ladder to get up to the
garage door opener motor to be able to access
the “smart or learn” program button.
1. To begin, press and hold the 2 outer
HomeLink
buttons (to clear the memory)
until the indicator light blinks slowly (after 20
seconds). Release both buttons.
2. Position the end of the hand-held transmitter
1-3 inches away from the HomeLink
sur-
face.
SIC2247
2-40
Instruments and controls


04.5.17/Z33-D/V5.0


You can only drive your vehicle using the master
or valet keys which are registered to the Nissan
Vehicle Immobilizer System (NVIS) components
in your vehicle. These keys have a transponder
chip in the key head.
The master key can be used for all the locks.
The valet key cannot be used for the rear floor
box lock. To protect belongings when you leave
a key with someone, give them the valet key only.
Never leave these keys in the vehicle.
A key number plate is supplied with your keys.
Record the key number and keep it in a safe
place (such as your wallet), not in the vehicle.NISSAN does not record any key numbers so it
is very important to keep track of your key
number plate.
A key number is only necessary when you have
lost all keys and do not have one to duplicate
from. If you still have a key, this key can be
duplicated by your NISSAN dealer.
Nissan Vehicle Immobilizer System (NVIS) KEY -
Master and Valet keys:
As many as 5 keys can be used with one vehicle.
New keys must be registered to the NVIS com-
ponents in your vehicle by your NISSAN dealer.
At this time, you should bring all NVIS keys that
you have to your NISSAN dealer for registration.
This is because the registration process will
erase all memory of the NVIS components.
CAUTION
Do not allow the NVIS key, which con-
tains an electrical transponder, to come
in contact with salt water. This could
cause the system to malfunction.
WARNING

Always have the doors locked while
driving. Along with the use of seat
belts, this provides greater safety in
the event of an accident by helping to
prevent persons from being thrown
from the vehicle. This also helps keep
children and others from uninten-
tionally opening the doors, and will
help keep out intruders.

Before opening any door, always
look for and avoid oncoming traffic.

Do not leave children unattended in-
side the vehicle. They could unknow-
ingly activate switches or controls.
Unattended children could become
involved in serious accidents.
SPA1379C
KEYSDOORS3-2
Pre-driving checks and adjustments


04.5.17/Z33-D/V5.0


Keep pressing the UNLOCK button until the
windows are fully open.
To stop lowering the windows, release the UN-
LOCK button.
To start lowering the windows again, press the
UNLOCK button again for 3 more seconds.Releasing the rear hatch/trunk lid1. Push the HATCH/TRUNK button on the key-
fobfor longer than 0.5 seconds with the key
removed from the ignition key cylinder.
2. The rear hatch (Coupe) or trunk lid (Road-
ster) opens.Using the panic alarmIf you are near your vehicle and feel threatened,
you may activate the alarm to call attention as
follows:
1. Push the PANIC button on the keyfob for
longer than 0.5 secondswith the key
removed from the ignition key cylinder.
2. The theft warning alarm and headlights will
stay on for 30 seconds.
3. The panic alarm stops when:

It has run for 30 seconds, or
The LOCK or the UNLOCK button is
pressed, or

The PANIC or the HATCH/TRUNK button is
pushed on the keyfobfor longer than 0.5
seconds.3-6
Pre-driving checks and adjustments


04.5.17/Z33-D/V5.0


1. Pull the hood lock release handle
1
located
below the instrument panel; the hood will
then spring up slightly.
2. Raise the lever
2
at the front of the hood
with your fingertips and raise the hood.
3. Insert the assist bar into the slot
3
in the
front edge of the hood.
4. When closing the hood, reset the assist bar
to its original position, then slowly close the
hood and make sure it locks into place.
WARNING

Make sure the hood is completely
closed and latched before driving.
Failure to do so could cause the hood
to fly open and result in an accident.

If you see steam or smoke coming
from the engine compartment, to
avoid injury do not open the hood.
WARNING
Do not drive with the rear hatch open.
This could allow dangerous exhaust
gases to be drawn into the vehicle. See
“Precautions when starting and driving”
in the “5. Starting and driving” section
for exhaust gas.
SPA1506
HOODREAR HATCH (Coupe models)
Pre-driving checks and adjustments
3-9


04.5.17/Z33-D/V5.0
