2004 NISSAN 350Z flat tire

TIRE AND LOADING INFORMATION
LABELThe cold tire inflation pressure is shown on the
Tire and Loading Information label affixed to the
driver side center pillar.
AIR CONDITIONER SPECIFICATION
LABELThe air conditioner specification label is affixed
inside of the hood as shown.
STI0366
STI0325
9-12
Technical and consumer information


04.5.17/Z33-D/V5.0


trailer hitch.

To reduce the possibility of addi-
tional damage if your vehicle is
struck from the rear, where practical,
remove the hitch and/or receiver
when not in use.

After the hitch is removed, seal the
bolt holes to prevent exhaust fumes,
water or dust from entering the pas-
senger compartment.

Regularly check that all hitch mount-
ing bolts are securely mounted.
Tire pressures
When towing a trailer, inflate the vehicle tires
to the recommended cold tire pressure indi-
cated on the Tire and Loading Information
label.

Trailer tire condition, size, load rating and
proper inflation pressure should be in accor-
dance with the trailer and tire manufacturers’
specifications.Safety chainAlways use a suitable chain between your ve-hicle and the trailer. The safety chain should be
crossed and should be attached to the hitch, not
to the vehicle bumper or axle. Be sure to leave
enough slack in the chain to permit turning
corners.
Trailer lightsTrailer lights should comply with federal and/or
local regulations. When wiring the vehicle for
towing, connect the stop and tail light pickup
into the vehicle electrical circuit at a point be-
tween the sensor and stop light or light switch.Trailer brakesIf your trailer is equipped with a braking system,
make sure it conforms to federal and/or local
regulations and that it is properly installed.
WARNING
Never connect a trailer brake system
directly to the vehicle brake system.Pre-towing tips
Be certain your vehicle maintains a level
position when a loaded and/or unloaded
trailer is hitched. Do not drive the vehicle if it
has an unusual nose-up or nose-down con-dition; check for improper tongue load, over-
load, worn suspension or other possible
causes of these conditions.

Always secure items in the trailer to prevent
load shifts while driving.

Be certain your rear view mirrors conform to
all federal, state and/or local regulations. If
not, install any mirrors required for towing
before driving the vehicle.
Trailer towing tipsIn order to gain skill and an understanding of the
vehicle’s behavior, you should practice turning,
stopping and backing up in an area which is free
from traffic. Steering stability, and braking per-
formance will be somewhat different than under
normal driving conditions.

Always secure items in the trailer to prevent
load shift while driving.

Avoid abrupt starts, acceleration or stops.

Avoid sharp turns or lane changes.

Always drive your vehicle at a moderate
speed.

Always block the wheels on both vehicle and
trailer when parking. Parking on a slope is not
recommended; however, if you must do so,
and if your vehicle is equipped with automatic
9-18
Technical and consumer information


04.5.17/Z33-D/V5.0


DOT (Department Of Transportation) Quality
Grades: All passenger car tires must conform to
federal safety requirements in addition to these
grades.
Quality grades can be found where applicable
on the tire sidewall between tread shoulder and
maximum section width. For example:
Treadwear 200 Traction AA Temperature ATreadwearTreadwear grade is a comparative rating based
on tire wear rate when tested under controlled
conditions on specified government test
courses. For example, a tire graded 150 would
wear one and a half (1-1/2) times as well on the
government course as a tire graded 100. How-
ever, relative tire performance depends on actual
driving conditions, and may vary significantly
from the norm due to variations in driving habits,
service practices and differences in road char-
acteristics and climate.Traction AA, A, B and CThe traction grades, from highest to lowest, are
AA, A, B, and C. Those grades represent the
tire’s ability to stop on wet pavement as mea-
sured under controlled conditions on specified
government test surfaces of asphalt and con-crete. A tire marked C may have poor traction
performance.
WARNING
The traction grade assigned to your ve-
hicle tires is based on straight-ahead
braking traction tests, and does not in-
clude acceleration, cornering, hydro-
planing, or peak traction characteristics.Temperature A, B and CTemperature grades are A (the highest), B, and
C. They represent a tire’s resistance to heat
build-up, and its ability to dissipate heat when
tested under controlled conditions on a speci-
fied indoor laboratory test wheel. Sustained high
temperature can cause tire material to degener-
ate, reducing tire life. Excessive temperatures
can lead to sudden tire failure. Grade C corre-
sponds to a performance level which all passen-
ger car tires must meet under the Federal Motor
Vehicle Safety Standard No. 109. Grades A and
B represent higher levels of performance on
laboratory test wheels than the minimum re-
quired by law.
WARNING
The temperature grade for this tire is
established for a tire that is properly
inflated and not overloaded. Excessive
speed, underinflation, or excessive
loading, either separately or in combi-
nation, can cause heat buildup and pos-
sible tire failure.
UNIFORM TIRE QUALITY
GRADING
Technical and consumer information
9-21


04.5.17/Z33-D/V5.0


Compact Disc (CD) player (See audio
system) ......................................................................... 4-11
Compact spare tire ................................................... 8-36
Console box................................................................ 2-32
Controls, Heater and air conditioner controls
(automatic) ..................................................................... 4-3
Coolant
Capacities and recommended fuel/
lubricants ................................................................. 9-2
Changing engine coolant .................................... 8-9
Checking engine coolant level........................... 8-8
Corrosion protection ................................................... 7-5
Cruise control............................................................. 5-15
Cup holders ................................................................ 2-31
Curtain side-impact air bag system (See
supplemental side air bag and curtain air bag
system) ......................................................................... 1-17
D
Daytime running light system ................................. 2-23
Defroster switch, Rear window and outside mirror
defroster switch ......................................................... 2-21
Dimensions and weights ............................................ 9-9
Door open warning light .......................................... 2-12
Drive belts ................................................................... 8-17
Driving
Cold weather driving ......................................... 5-24
Driving with automatic transmission........ 5-6, 5-9
Driving with manual transmission .......... 5-7, 5-12
Precautions when starting and driving ............ 5-2E
Economy, Fuel............................................................ 5-17
Elapsed time ................................................................. 2-9
Emission control information label ........................ 9-11
Emission control system warranty......................... 9-22
Engine
Before starting the engine .................................. 5-8
Break-in schedule............................................... 5-17
Capacities and recommended fuel/
lubricants ................................................................. 9-2
Changing engine coolant .................................... 8-9
Changing engine oil and filter ......................... 8-10
Checking engine coolant level........................... 8-8
Checking engine oil level ................................. 8-10
Coolant temperature gauge ............................... 2-5
Engine block heater ........................................... 5-25
Engine compartment check locations.............. 8-7
Engine cooling system ......................................... 8-8
Engine oil .............................................................. 8-10
Engine oil and oil filter recommendation......... 9-5
Engine oil viscosity ............................................... 9-5
Engine serial number ......................................... 9-11
Engine specifications ........................................... 9-8
If your vehicle overheats ...................................... 6-9
Oil pressure gauge ............................................... 2-6
Starting the engine ............................................... 5-8
Event data recorders ................................................ 9-23
Exhaust gas (Carbon monoxide).............................. 5-2
F
F.M.V.S.S. certification label................................... 9-11Filter
Air cleaner housing filter ................................... 8-18
Changing engine oil and filter ......................... 8-10
Flashers (See hazard warning flasher switch) ... 2-25
Flat tire............................................................................ 6-2
Flat tire, Low tire pressure warning system .......... 5-3
Floor mat cleaning ....................................................... 7-4
Fluid
Automatic transmission fluid (ATF) ................ 8-12
Brake and clutch fluid ....................................... 8-13
Brake fluid............................................................. 8-13
Capacities and recommended fuel/
lubricants ................................................................. 9-2
Engine coolant ....................................................... 8-8
Engine oil .............................................................. 8-10
Power steering fluid ........................................... 8-13
Window washer fluid ......................................... 8-14
FM-AM radio with Compact Disc (CD) player .... 4-9
FM-AM-SAT radio with cassette player and
Compact Disc (CD) changer ................................. 4-13
Fuel
Capacities and recommended fuel/
lubricants ................................................................. 9-2
Distance to empty ................................................. 2-9
filler cap................................................................. 3-13
filler lid ................................................................... 3-13
Fuel economy ...................................................... 5-17
Fuel octane rating ................................................. 9-3
Fuel recommendation ........................................... 9-3
Gauge ...................................................................... 2-6
Fuses ............................................................................ 8-22
Fusible links ................................................................ 8-23


04.5.17/Z33-D/V5.0

10-2

S
Safety
Child seat belts ................................................... 1-25
Reporting safety defects (US only)................ 9-22
Towing safety....................................................... 9-17
Seat
Belt warning light................................................ 1-23
Lever, Tilting passenger’s seat .......................... 1-7
Seat belt(s)
Child safety .......................................................... 1-25
Infants and small children ................................. 1-25
Injured persons.................................................... 1-26
Larger children .................................................... 1-26
Pre-tensioner seat belt system ....................... 1-19
Precautions on seat belt usage ...................... 1-23
Pregnant women ................................................. 1-26
Seat belt cleaning ................................................. 7-5
Seat belt extenders ............................................ 1-28
Seat belt maintenance ...................................... 1-29
Seat belts ............................................................. 1-23
Three-point type.................................................. 1-26
Seat(s)
Heated seats........................................................ 2-26
Seats ........................................................................ 1-2
Ventilated net seats .............................................. 1-6
Secondary rear hatch release ................................ 3-10
Secondary trunk lid release .................................... 3-13
Security system, Vehicle security system ........... 2-17
Security systems (Nissan Vehicle Immobilizer
System), Engine start ............................................... 2-18
Servicing air conditioner ................................... 4-3, 4-6
Shift lock release ....................................................... 5-12
ShiftingAutomatic transmission .............................. 5-6, 5-9
Manual transmission ................................. 5-7, 5-12
Side air bag system (See supplemental side air bag
and curtain air bag system) .................................... 1-17
Soft top
Soft top care and cleaning ................................. 7-2
Soft top indicator light ........................... 2-16, 3-22
Soft top operation .............................................. 3-18
Care of the soft top and the vehicle body... 3-27
If the top does not open or close
electrically ............................................................. 3-24
Spark plugs................................................................. 8-17
Speed, Average speed............................................... 2-9
Speed, Speed indicator ............................................. 2-8
Speedometer ................................................................ 2-4
Starting
Before starting the engine .................................. 5-8
Jump starting .......................................................... 6-7
Precautions when starting and driving ............ 5-2
Push starting .......................................................... 6-9
Starting the engine ............................................... 5-8
Steering
Power steering fluid ........................................... 8-13
Power steering system ...................................... 5-19
Tilting steering wheel......................................... 3-15
Stopwatch ..................................................................... 2-9
Storage ........................................................................ 2-29
Stowing golf bags ..................................................... 2-34
Sun visor, Extension ................................................. 3-16
Sunglasses holder .................................................... 2-30
Supplemental air bag warning labels................... 1-20
Supplemental air bag warning light .......... 1-21, 2-14
Supplemental restraint system............................... 1-10Precautions on supplemental restraint
system.................................................................... 1-10
Supplemental side and curtain air bag
system .......................................................................... 1-17
Switch
Hazard warning flasher switch ........................ 2-25
Headlight switch ................................................. 2-23
Ignition switch ........................................................ 5-6
Ignition switch automatic transmission
models ............................................................ 5-6, 5-9
Ignition switch manual transmission
models .......................................................... 5-7, 5-12
Power door lock switch....................................... 3-4
Rear window and outside mirror defroster
switch..................................................................... 2-21
Traction control system (TCS) off switch .... 2-27
Turn signal switch .............................................. 2-24
Vehicle dynamic control (VDC) off switch ... 2-27
T
Tachometer.................................................................... 2-5
Temperature gauge, Engine coolant temperature
gauge .............................................................................. 2-5
Theft (Nissan Vehicle Immobilizer System), Engine
start ............................................................................... 2-18
Three way catalyst ....................................................... 5-3
Tilting passenger’s seat ............................................. 1-7
Tilting steering wheel ............................................... 3-15
Tire
Flat tire ..................................................................... 6-2
Low tire pressure warning system........... 5-3, 6-2
Pressure indicator............................................... 2-10
Pressure, Low tire pressure warning light ... 2-13


04.5.17/Z33-D/V5.0

10-5

FUEL RECOMMENDATION:Use unleaded premium gasoline with an octane
rating of at least 91 AKI (Anti-Knock Index)
number (Research octane number 96).
If premium gasoline is not available, unleaded
regular gasoline with an octane rating of 87 AKI
number (Research octane number 91) may be
temporarily used, but only under the following
precautions:

Have the fuel tank filled only partially with
unleaded regular gasoline, and fill up with
unleaded premium gasoline as soon as pos-
sible.

Avoid full throttle driving and abrupt accelera-
tion.
However, for maximum vehicle perfor-
mance, the use of unleaded premium gaso-
line is recommended.
CAUTION
Using a fuel other than that specified
could adversely affect the emission con-
trol systems, and may also affect war-
ranty coverage.
Under no circumstances should aleaded gasoline be used, since this will
damage the three way catalyst.
For additional information, see “Capacities and
recommended fuel/lubricants” in the “9. Techni-
cal and consumer information” section.
ENGINE OIL RECOMMENDATION:
API Certification Mark

API grade SG/SH, Energy ConservingI&II
or API grade SJ or SL, Energy Conserving

ILSAC grade GF-I, GF-II & GF-III

SAE 5W-30 viscosity oil is preferred for all
ambient temperatures. SAE 10W-30 viscos-
ity oil may be used for ambient temperatures
above 0°F (−18°C).
See “Capacities and recommended fuel/
lubricants” in the “9. Technical and consumer
information” section for engine oil and oil filter
recommendation.COLD TIRE INFLATION
PRESSURES:See Tire and Loading Information label affixed to
the driver’s side center pillar.
NEW VEHICLE BREAK-IN
PROCEDURES
RECOMMENDATION:During the first 1,200 miles (2,000 km) of ve-
hicle use, follow the recommendations outlined
in the “Break-in schedule” information found in
the “5. Starting and driving” section of this
Owner’s Manual. Follow these recommenda-
tions for the future reliability and economy of
your new vehicle.
GAS STATIONINFORMATION


04.5.17/Z33-D/V5.0
